  • Page 2 The XRAY We have made every effort to make these instructions and Set-Up T1R has the racing pedigree of the XRAY T1 family and can be Book as easy to understand as possible. However, if you have any...

  • Page 3: Table Of Contents

    ALU SUSP . ADJUSTABLE BULKHEAD FRONT LEFT The XRAY T1R comes partially preassembled. Before starting assembly, disassemble the chassis parts, noting the position and orientation of the parts, particularly the bulkheads. Keep the parts, including the screw hardware, close at hand. In the assembly steps that follow, each section...
  • Page 4 1. FRONT & REAR DIFFERENTIAL 305050 305040 305010 309070 309370 309442 305082 305050 305090 305082 309020 305020 305050 30 5010 ALU DIFF LONG OUTPUT SHAFT - HARD COATED 30 5090 BALL STEEL 2.4 MM (24) 30 5020 ALU DIFF SHORT OUTPUT SHAFT - HARD COATED 30 9020 BALL-BEARING MR85ZZ 5x8x2.5 (2) 30 5040...

  • Page 5: Front & Rear Differential

    FRONT & REAR DIFFERENTIAL 1 1 . Hold the short diff shaft with the installed pulley facing up. Place a #309020 (BB 5x8) ball-bearing on the center stub, atop the other bearing. 2 2 . . Put a very thin coat of grease on the side of a #305082 diff washer, and place it on 309020 the long diff shaft.
  • Page 6 2. REAR TRANSMISSION 309358 302042 302070 309319 309054 305000 303151 307311 303015 305441 309452 309035 309045 305570 309319 309415 305514 305431 309336 302042 301117 309343 303025 30 2042 LOWER SUSPENSION HOLDER INTEGRATED ( SET 12) 30 9336 HEX SCREW SH M3x12 (10) 30 2070 ECCENTRIC NYLON HUB FOR BULKHEAD + COVERS (4+2) 30 9343...

  • Page 7: Rear Transmission

    REAR TRANSMISSION 1 1 . . Insert the layshaft through the upper ball-bearing in the right rear bulkhead until the shoulder on the layshaft rests against the outside of the bearing. 309452 2 2 . . Slide the collar over the layshaft, with the tapered end toward the bearing. P 2x10 3 3 .
  • Page 8 3. REAR SUSPENSION 309333 309334 303097 302611 309351 303231 309335 303222 307454 302662 303350 309054 305240 305320 309452 305310 309425 309351 307320 305230 30 2611 ADJ. TURNBUCKLE L/R 35 MM - SPRING STEEL (2) 30 7320 REAR PIVOT PIN FOR C-HUB - SPRING STEEL (2) 30 2662 BALL JOINT 5 MM - OPEN (6) 30 7454...

  • Page 9: Rear Suspension

    REAR SUSPENSION To install a snap ring: To remove a snap ring: Place the hex portion of the wheel axle flat on a table. Place the hex portion of the wheel Put one end of the snap ring into the groove on the axle flat on a table.
  • Page 10 4. FRONT TRANSMISSION 302025 305431 302070 302042 302015 309336 309358 305000 309054 302151 309343 307214 30 2042 LOWER SUSPENSION HOLDER INTEGRATED ( SET 2+1+1) 30 2015 ALU SUSP . ADJUSTABLE BULKHEAD FRONT RIGHT 30 2070 ECCENTRIC COMPOSITE HUB FOR BULKHEAD + COVERS (4+2) 30 2025 ALU SUSP .

  • Page 11: Front Transmission

    FRONT TRANSMISSION The left and right front lower arms are mirror images. 309358 Thread a #309358 (SB M4x8) downstop adjustment screw into the hole at the rear of SB M4x8 each front lower arm. The screws must protrude 1.6 mm below the arms, and must be accessible from the tops of the arms for adjustment.
  • Page 12 5. FRONT SUSPENSION 302284 302260 309335 309336 307454 307454 302097 309336 302290 307220 309333 302282 302611 309351 302662 309336 309425 305230 309054 302250 309054 305240 305320 309452 305310 30 2097 COMPOSITE SHOCK TOWER FRONT 30 5320 DRIVE SHAFT - 51 MM - SPRING STEEL (2) 30 2250 COMPOSITE STEERING BLOCK RIGHT FOR C-HUB SUSP .

  • Page 13: Front Suspension

    FRONT SUSPENSION To install a snap ring: To remove a snap ring: Place the hex portion of the wheel axle flat on a table. Place the hex portion of the Put one end of the snap ring into the groove on the wheel axle flat on a table.

  • Page 14: Adj. Steering Rod L/R 35 Mm - Spring Steel

    6. STEERING 309343 309334 301167 306500 309335 302662 307454 302580 309336 309010 302582 302501 302630 307454 309319 309334 302662 302501 309010 302611 309336 307454 309336 FACTORY PREASSEMBLED 30 2501 DUAL-ACKERMANN CENTRAL SERVO SAVER (SET) 30 9319 UNIVERSAL SET OF PLASTIC SHIMS 30 2580 COMPOSITE SERVO HORN - KO, JR, AIRTRONICS, MULTIPLEX 30 9334...

  • Page 15: Steering

    STEERING 1 1 . . Attach the left and right steering rods to the servo saver. Pass a #309336 (SH M3x12) screw upward through the following parts: LEFT 309336 STEERING ROD • #307454 pivot ball SH M3x12 61mm • steering rod inner ball joint (on long end) SERVO LINK •...
  • Page 16 E-CLIP 3 (10) Properly functioning shocks are very important to the performance of your car. This XRAY shock set contains parts to build four externally-adjustable or non-adjustable shocks. Both adjustable and non-adjustable shocks feature XRAY's unique keying system that positively locks the pistons to the shock rods.

  • Page 17: Shock Absorbers

    SHOCK ABSORBERS 1 1 . . Insert the larger #308071 (O 5x1) O-ring onto the shock body, until it seats around the shock body extension. 2 2 . . Lubricate the small #308070 (O 3.1x1.6) O-ring with a drop or two of shock oil. Taking care not to rip or damage the O-ring, 308071 slide it over the end of the shock rod.

  • Page 18: Rear Final Assembly

    30 9452 PIN 2x10 (10) 30 7464 PIVOT BALL 5.8 MM DOUBLE BEVEL SHOULDERS (10) 30 8300 XRAY SHOCK ABSORBER-SET 4-STEP (2) 30 9335 HEX SCREW SH M3x10 (10) 30 9336 HEX SCREW SH M3x12 (10) Assemble TWO rear body posts by performing the following steps.

  • Page 19: Front Final Assembly

    HEX SCREW SH M3x12 (10) 30 9345 HEX SCREW SFH M3x10 (10) 30 8300 XRAY SHOCK ABSORBER-SET 4-STEP (2) 1 1 . . Place a #309393 (N M3) nut into the hex recess atop the #301201 lower bumper. 309393 2 2 . . Place the lower bumper onto the front of the chassis.

  • Page 20: Final Assembly

    9. FINAL ASSEMBLY 306105 FROM SERVO 309400 309334 306105 306210 309402 309332 309345 305793 306400 309346 30 5793 SPUR GEAR 93T / 48 30 9334 HEX SCREW SH M3x8 (10) 30 6105 COMPOSITE BATTERY HOLDERS FOR 2 x 3 BAT. - COMPLETE SET 30 9345 HEX SCREW SFH M3x10 (10) 30 6210...

  • Page 21: Accessory Assembly

    ACCESSORY ASSEMBLY 306310 309317 309334 309310 803001 NOT INCLUDED TIRES & INSERTS NOT INCLUDED 30 5720~34 PINION GEAR ALU HARD COATED 48P (OPTION) 30 9334 HEX SCREW SH M3x8 (10) 30 6310 ANTENNA (2) 30 9400 BODY CLIP (8) 30 9310 WHEEL MOUNTING HARDWARE (4+4) 80 3001 HUDY 24 MM WHEELS STARBURST - WHITE (4)
  • Page 22 ACCESSORY ASSEMBLY The XRAY T1R Raycer is a competition racecar, and therefore does not come supplied with tires and inserts. Check with racers at tracks you attend to determine the best tire/insert combinations. TIRES AND INSERTS NOT INCLUDED Use your own tires and inserts to prepare the wheels: 1 1 .
  • Page 23 IMPORTANT NOTES: • This product is not suitable for children except under the direct supervision • Regularly check the charger for potential hazards such as damage to the cable, of an adult. plug, casing or other defects. Ensure that any damage is rectified before using •...
