INSTALLATION
SECTION 3
Plumbing
Fit an isolation valve in the cold mains supply
preceding the installation point of the
handyman unit to allow the unit to be serviced.
Turn the temperature Control so that it is set to
'MIN'.
Remove the front cover by unscrewing the
screw at the bottom of the unit and lifting the
cover, complete with control knob, off the
handwash unit.
Place the handwash unit on the wall, ensuring
it is level, and mark the location of the fixing
screws through the backplate.
The following procedure assumes installation
onto a sound masonry surface, if installing
onto other surfaces the procedure and fixings
may need to be modified.
Carefully drill the holes using a 5.5mm
masonry drill-bit and insert the rawl plugs into
the holes.
Place the unit on the wall and secure it using
the screws provided.
Run the water supply to the unit using 15mm
copper or stainless pipe and flush the
pipework for several seconds to remove any
flux and debris within the pipe, before
connecting to the unit.
Connect the mains water supply to the blue
water inlet on the handwash unit using the
compression nut and olive provided. Take
care not to use excessive force when
tightening the compression nut.
5:18 PM Page 5
Fit the swivel arm to the end outlet of the
handwash unit.
With the unit fully plumbed in turn on the
mains water supply and check the system for
leaks.
SECTION 4
Electricity Supply
Warning this appliance must be earthed!
The unit is suitable for connection to
~230-240V/50Hz supply only
The wiring must conform to with I.E.E. wiring
regulations. If in doubt seek professional advice.
The unit may be supplied from a ring circuit
via a fused spur with a double pole linked
isolating switch fitted with a 13A fuse. The
supply cable should be 3 core and of 1.5
–2.5mm diameter.
The cable should be routed to the handwash
unit so that it enters either via the cable entry
point at the top right hand side of the unit or
through the break-out hole at the rear of the
unit.
The cable grommet should be inserted at the
entry point and the wire routed into the unit.
Connect the Live wire to the terminal
marked L.
Connect the Neutral wire to the terminal
marked N.
Connect the Earth wire to the terminal
marked E.
Ensure that the terminal screws are fully tightened
and good electrical continuity is achieved.
INSTALLATION
Secure the cable to the unit using the cable SECTION 7
Operation
clamp.
Do no switch on the electricity supply to Switch on
the unit! 1) Turn on the electricity supply at the isolating
2) Turn the temperature control knob anti-
SECTION 5
Final Assembly
Ensuring the temperature control knob is set to
'MIN', place the cover carefully onto the 3) After a few seconds the water should run
handwash unit and secure using the fixing
screws.
4) If the temperature is required to be increased
SECTION 6
Commissioning
Turn the temperature control knob 5) To reduce the water temperature turn the
anti-clockwise to its 'MAX' setting and allow
water to flow through the unit until a
continuous stream of water, free of air bubbles Do not under any circumstances restrict or
is achieved. cover the sprayhead or try to prevent water
exiting the handwash unit as this will cause
the safety cut-out to operate.
Switch on the electrical supply at the isolating
switch. The Power indicator should light.
Turn off
After a few seconds check that the water from 1) To turn the unit off, turn the temperature
the unit is beginning to get warm. Adjust the
temperature control clockwise and check that
after a few seconds the water becomes
hotter.
Turn off the unit by turning the temperature 2) Switch off the electricity supply at the
control knob fully clockwise. Switch off the
electricity supply at the isolation switch
Note: variation in water temperature is
achieved by varying the flow of water through
the unit, hence for higher temperatures you
will notice a reduction in the flow of water
from the handwash unit.
switch. The power indicator should light.
clockwise to its 'MAX' position – indicating
maximum water flow.
warm, ready for use.
turn the knob slowly clockwise, wait a few
seconds until the water temperature
stabilises and adjust again if necessary.
knob anti-clockwise.
knob fully clockwise until the water stops
flowing. Note: some water may continue
to drip from the unit for a few minutes
as excess water drains from the unit.
isolating switch.
