- Page 1 DIMPLEX IL095 INSTANT INLINE UNVENTED WATER HEATER Installation and User Guide IMPORTANT: This booklet should be left with the user after installation and demonstration. It should be kept in a safe place, as you may need to refer to it for general instructions...
-
Page 2: Table Of Contents
Commissioning your IL095 ........ -
Page 3: How To Install Your Il095
HOW TO INSTALL YOUR IL095 WARNING: ALL WIRING AND INSTALLATION MUST BE SUPERVISED BY A SUITABLY QUALIFIED PERSON. WARNING: DO NOT INSTALL THIS UNIT WHERE IT MAY BE SUBJECTED TO FREEZING CONDITIONS. BEFORE YOU START Check that the mains electric is capable of supplying the required current. - Page 4 Deciding the wiring route You have a choice of whether to feed the electric cable through the side or through the back of the unit. If it going through the side of the unit, cut out the plastic lug to expose the grommet (diagram 2). If is going through the back of the unit, cut through the grommet on the backplate with a sharp knife (Take Care!).
- Page 5 Fitting the attachments If the unit is to supply a shower, you will also need a “Dimplex Mixer Unit”. Available in chrome/white finish and suitable for surface or concealed pipe entry (see page 9).
- Page 6 9.5kW and 10.8kW IL095: A standard 45 amp cord operated isolator switch is recommended. 12.0kW IL095: A pull cord isolator switch is not available for this model. A double pole 50 amp isolator switch is required. This must be mounted out of reach of the shower cubicle or bath.
-
Page 7: Commissioning Your Il095
ALL exposed metal parts of ALL other appliances in the room. COMMISSIONING YOUR IL095 CHECKING FOR LEAKS Let the water run through the unit for a few seconds. Check that no pipe joints leak. -
Page 8: How To Use Your Il095
It is important to clean the shower spray plate regularly (see page 7). In order for the IL095 to function correctly, the “Dimplex Mixer Kit” must be used. The kit comes complete with full accessories including a 3 position multi-function shower... -
Page 9: What To Do If Things Go Wrong (1) Self Help
Please Note:- The fitting of Spare Parts must be supervised by a suitably qualified person. Chrome and White Shower Mixer Unit Complete with full accessories Including 3 position multi-function handset For further details, including a comprehensive list off accessories and spare parts, contact Dimplex Customer Services 0845 6000 5111... -
Page 10: What To Do If Things Go Wrong (2) Professional Service
(diagram 11). Before you do this you must remove the cause of the problem The flow switch is not working Contact Dimplex Water too cold The power select screw is set to Change the power select screw to - neon light on “LO”... -
Page 11: How Your Il095 Works
HOW YOUR IL095 WORKS Water comes in through the inlet, via a flow switch. The flow switch measures how much water is passing through the unit. If it detects more than the preset level of:- 2.7 litres/minute for the 9.5kW model and 3.3 litres/minute for the 10.8kW and 12.0kW models The units heating elements are switched on. -
Page 12: Guarantee And Contact Details
GUARANTEE AND CONTACT DETAILS DIMPLEX UK LIMITED MILLBROOK HOUSE, GRANGE DRIVE, HEDGE END, SOUTHAMPTON SO30 2DF We offer a technical advisory service on the telephone: RING 0845 6000 5111 (A4) Leaflet No. 579-2152-17A...
