American Dynamics AD2150 User Manual

FEATURES
•
32 video inputs by five video
outputs
•
Can be ordered as a
standalone unit or with a
choice of user interfaces:
AD2088 Keyboard, ADTTE
Keyboard or Excalibur GUI
•
Integral Manchester code
distributor
•
Provides fixed and variable-
speed pan/tilt and dome
control
•
Integral menu-driven setup
•
PC programming package
supplied
•
Three flexible RS-232
inputs, expandable to 12
•
On-screen display includes
video input number and
title, monitor status, and
time & date
•
Individual monitor tours
•
24 universal tours
•
35 event timers
•
Eight salvos
•
Automatic alarm call-up of
up to 128 alarm inputs
•
Five alarm display modes
•
Five alarm clearance
methods
•
System partitioning of
inputs, outputs, and
keyboards
•
Rack mount kit included
•
Common Form C relay
output
AD2150 SERIES
SYSTEM V MATRIX SWITCHER/
CONTROLLER SYSTEM
The microprocessor based AD2150 is a compact,
self-contained, video matrix switcher/controller
system perfectly suited for small to medium size
CCTV installations such as industrial sites, office
buildings and schools. The AD2150 allows a single
operator to easily manage a CCTV system consisting
of up to 32 video inputs and five video outputs. The
video inputs can include fixed cameras, dome
cameras, pan/tilts, motorized lenses, and auxiliary
outputs. The video outputs can include up to five
monitors, VCRs, or video accessories.
Each of the system's monitors is capable of operator-
defined camera tours. Each monitor is also capable
of displaying any of 24 universal tours.
The AD2150 is supplied with a choice of user
interfaces (the ADTTE keyboard, the AD2088
keyboard, or the Excalibur GUI). The unit has four
Manchester code outputs, three RS-232 ports, eight
programmable alarm inputs, and one alarm output.
These standard features can be expanded with the
addition of peripheral devices.
The system has selectable on-screen displays that
insert date, time, video input number, 16-character
video input title and monitor status.
www.americandynamics.net
