Page 1: Installation Manual
ESPRIT 718 728L 728 738 748 748ES 718 728L 728 738 748 748ES Installation Manual IM8 960715-0000... - Page 2 Requirements and guidelines for U.L. INSTALLATIONS UL listed in accordance with standard UL1023 (Household Burglar - Alarm System Units), standard UL985 (Household Fire Warning Units) and UL1635 (Digital Alarm Communicator System Units). UL has only evaluated the 718, 728L, 728, 738 and 748 for compatibility with the Ademco model 685, FBI model CP220FB, SUR-GUARD SG-MLR2-D6 and Silent Knight model 9000.
-
Page 3: Table Of Contents
TABLE OF CONTENTS REQUIREMENTS AND GUIDELINES FOR U.L., ULC AND AUSTEL INSTALLATION TABLE OF CONTENTS ..............INTRODUCTION . - Page 4 KEYSWITCH/PUSH BUTTON ARMING/DISARMING ....... . . ZONE BYPASSING ..............MANUAL .
- Page 5 Zone restore transmission............Zones with EOL resistors.
-
Page 6: Introduction
Every effort has been made to ensure that your distributor's staff has received complete training from Paradox Security Systems so that you receive prompt and effective service. -
Page 7: Features
ATZ simplifies the task of meeting the zone requirements of any application and, at the same time, reduces installation costs. Zoning - The Paradox innovation - the "Old-fashioned" Way "Advanced Technology Zoning"... -
Page 8: Features
FEATURES (continued) Streamlined Keypad / PC Programming, User-friendly Operation The reduced number of steps required to program Esprit panels via a keypad speeds up installation. End-user access to most system functions calls for just one touch of the keypad. Strategic System Partitioning ( 728 , 738 , 748 , 748ES ) Each control panel can be used to monitor two distinct security systems, as well as common areas. -
Page 9: Specifications
Digital Communicator: Compatible with most telecommunication standards world wide. Reporting formats: Pulse: Ademco slow (10BPS), Silent Knight fast, Sescoa (20 BPS) Radionics, Radionics with parity (40 BPS), 1400Hz - 1800Hz (20 BPS) DTMF: Contact ID, Ademco Express, “No handshake” DTMF format. (Pager) Optional SIA format (Standard on 708 ) True Dial tone detection and telephone line monitoring. -
Page 10: Basic Installation
LOCATION AND MOUNTING The printed circuit board, mounting hardware and keypad should be removed from the packaging inside the panel box. Press the five white nylon mounting studs into cabinet from the back prior to mount- ing the cabinet. Before mounting the circuit board on the back of the cabinet, pull all cables into cabinet and prepare them for connection. -
Page 11: Telephone Line Connection
TELEPHONE LINE CONNECTION Connect the incoming telephone company wires into " " and " ". Wires should then be run from " 1" RING and " 1" to the installation's phone system. POWERING UP THE UNIT GENERAL When keypads are installed far from the control panel, a keypad should be temporarily connected close to the panel to conduct "power-up"... -
Page 12: Advanced Technology Zoning
The system hardware will recognize the following conditions for each zone: ADVANCED TECHNOLOGY ZONE connection, 2 zone resistors (without EOL), tamper recognition (N.C. contacts) address 208, key [ ] = "on" See "Tamper/wire Fault Definitions key [10] = " and Options key [11] = address 210, key [8] = "on"... - Page 13 SINGLE ZONE connection with 1 green (1K ) EOL resistor, tamper recognition (N.C. contacts) address 208, key [ ] = "off " key [10] = See "Tamper/wire Fault Definitions " and Options key [11] = address 210, key [8] = "off" Tamper fault transmits separate code, see Figure 3 (UL / ULC configuration) ADVANCED TECHNOLOGY ZONE connection, 2 zone with zone resistors, 1 green (1K...
-
Page 14: Tamper/Wire Fault Definitions And Options
Tamper/wire Fault Definitions and Options When using 2 zone resistors, the panel offers four possible definitions for line/tamper wiring recognition, independent of zone definition. "Tamper/wire” disabled (Address 208, Key [10] "off", Key [11] "off") Tamper/wiring failure recognition is disabled. (Also disables ATZ zone doubling for software versions prior to 0.98.) "Trouble"... -
Page 15: Guidelines For Smoke Detector Location
GUIDELINES FOR SMOKE DETECTOR LOCATION Smoke Detection. Where to locate Smoke Detectors in Existing Construction. The major threat from fire in a family living unit is at night when everyone is asleep. The principal threat to persons in sleeping areas comes from fires in the remainder of the unit; therefore, smoke detector(s) are best located between the bedroom areas and the rest of the unit. -
Page 16: User/Keypad Functions
INTRODUCTION The Esprit 's innovative keypads take a new approach to security features and functions. Each numeral on the keypad from 1 to 12 represents an actual zone. When the [2 ] key flashes, (depending on the model number of the control) the same numerals represent a second set of 12 zones, zones 13 to 24. (The [2 ] key will first light up to indicate that one or more of these zones (13-24) are open. -
Page 17: Fast "Stay" Arming
Fast "stay" arming key [11] Fast "stay" arming is enabled at address 208 (key [8] "on"). When activated, no "ready" light is required, however "stay" zones must be closed to arm the system. Pressing [ ] (key [11]) for 2 seconds auto- STAY matically "stay"... -
Page 18: Arming/Disarming
Panel "A" Partition Zones "B" Partition Zones Total Possible Zones 748, 748ES 1-6, 13-18, 13 = (Keypad 1) 7-12, 19-24, 19 = (Keypad 2) 1-6, 13(Keypad 1) 7-12, 19 (Keypad 2) 1-6 (See note) 7 (Keypad 1), 8 (Keypad 2) Notes re: 728 (also see page 27) The designation for zones 1, 2, 3,4,5 and 6 can be changed to zones 7, 8, 9,10,11 and 12 respectively so that they form part of partition “B”. -
Page 19: Keyswitch/Push Button Arming/Disarming
KEYSWITCH/PUSH-BUTTON ARMING/DISARMING (PS1) In parallel to keypads, a keyswitch or push button can be used to arm/disarm the system. (The Esprit PS1 can be installed in bedrooms or any other desired location.) Keyswitch/push button operation is enabled/disabled at address 206, key [3] "on". Keyswitch can activate "regular" or "stay" arming, based on the definition assigned at address 206, key [2]. -
Page 20: Trouble Display/Monitoring
TROUBLE DISPLAY/MONITORING Trouble status is continuously monitored by the panel. It can recognize and display 10 different trouble conditions on the keypad or in Espload , and report 8 to the central station. (To send "trouble status reports" to the central, 2-digit trouble report codes should be programmed.) When trouble conditions occur, the [ ] key illuminates and if "trouble warning"... -
Page 21: End-User Programming
Telephone line monitor Key [10] Telephone line cannot be found for 30 seconds. "Telephone line monitor" is enabled at address 206. This trouble condition can also trigger an alarm when the system is armed, if activated at address 206. It will also be stored in "event list". -
Page 22: Special Timing Functions
"NO MOVEMENT" If a time is programmed at address 253, and a report code is entered at address 190 (SECTION 32), the panel will send a report to the central if no movement takes place in the protected area for a designated time period. -
Page 23: Installer Programming
ESPLOAD Esprit control panels can be programmed remotely with Espload upload/download software or on site with Espload and a ADP-1 adapter. Contact your local Paradox Distributor for your free copy of Espload software. KEYPAD To program Esprit panels via the keypad, first complete the programming work sheets and follow the pro- gramming procedure. -
Page 24: Installer Code
All report codes are preceded by a system account code to ensure correct identification of active zone(s) in a partitioned system. If partitioning is deactivated, or you are using Esprit 718 or 728L, the same value should be programmed for both account numbers. To program account codes for System "A"... -
Page 25: Reporting Codes
REPORTING CODES: (Addresses 088-193) SECTION 07- 33 DIRECT ADDRESS OR STREAMLINED PROGRAMMING General The panel can report information regarding system and "protected area" status to the central monitoring station, when reporting is activated at address 206. All data to be communicated should be assigned a 2-digit hexa reporting code, consisting of numbers from 0-15. -
Page 26: Special Codes
Special codes (Addresses 184-193) SECTION 31 - 33 These codes are assigned to report 10 special status conditions. Panic 1 Panic alarm will be reported to the central. (keys [1] and [3] pressed for 2 seconds) Panic 2 Panic alarm will be reported to the central. (keys [4] and [6] pressed for 2 seconds) Panic 3 Panic alarm will be reported to the central. -
Page 27: Programmable Output (Pgm) Type And Options
PROGRAMMABLE OUTPUT (PGM) TYPE AND OPTIONS Program type (Address 195) SECTION 33 Each PGM output can be programmed as normally open (N.O.) or normally closed (N.C.). Regular N.O. - solid state switch momentarily conducts to negative (30mA) upon an event or events. Regular N.C. -
Page 28: Tlm Options
If partitioning is enabled (Address 206, key [8] "on") Address 200: Lighted keys indicate which user codes are assigned to System "A". Address 202: Lighted keys indicate which user codes are assigned to System "B". Address 204: Lighted keys indicate which user codes can "bypass" zones. TLM options (Address 206, key [2 ] and key [1]) -
Page 29: Silent Alarm
Notes re: 728 The designation for zones 1, 2, 3, 4, 5 and 6 can be changed to zones 7, 8, 9, 10, 11 and 12 respectively so that they form part of system “B”. Zones 1 and 2 will be swapped with zones 7 and 8. Zones that are not selected (light "on") are common to both systems and will be armed only if the panel is fully armed. -
Page 30: Answering Machine Override
*This feature is useful for PBX systems, which do not provide a dial tone. You can program the dialing sequence required to get a line on a PBX system, and this sequence will be added before the central station number. If there is a time delay between dialing and getting a line, this can be programmed into the dialing sequence using the [ ] ("pause") key. -
Page 31: Enable Keypad Panic Signals
Enable keypad Panic signals (Address 208) Key [1] "on" = Panic 1 (keys [1] and [3]) enabled Key [2] "on" = Panic 2 (keys [4] and [6]) enabled Key [3] "on" = Panic 3 (keys [7] and [9]) enabled Keypad Panic options (Address 208) Key [4] "off "... -
Page 32: Zone 6 Disabled
Zone disabled (Address 210, key [1]) Used in conjunction with zone 3 (zone 12 for software versions prior to 0.98) when programmed as a fire zone. Key = "on": burglar alarm zone associated with fire zone is disabled so that a wire fault on the fire zone (fire trouble) will not cause an alarm on the associated burglar zone. -
Page 33: Zone Definition
Keypad 1 zone supervision (Address 210, key [11]) Keypad 2 zone supervision (Address 210, key [12]) (“on” = enabled) (“off” = disabled) When activating zone supervision for only one keypad, by turning “on” either key [11] or [12], the other keypad zone supervision “activation”... -
Page 34: System Times
Bypass-enabled (Addresses 236, 238) "Bypass-enabled" zones (keys "on") are zones that can be bypassed during "manual bypass" arming, "away" arming and auto zone shut-down. The fire zone cannot be bypassed. Note: If a zone should not be bypassed, turn "off" its corresponding zone key. System Assignment (Addresses 240, 242) Zones selected at these addresses are no longer "common zones", if partitioning is activated. -
Page 35: Installer Lock
In all cases, the warranty does not cover malfunctions arising from installer error or failure to follow installation/operation instructions, nor does it apply to damages due to causes beyond the control of Paradox Security Systems, such as lightning, exces- sive voltage, mechanical shock or water damage. -
Page 36: Fcc Compliance
The telephone company may ask that you disconnect this equipment from network until problem is corrected or until you are sure that the equipment is not malfunctioning. POINT OF CONTACT Paradox U.S. 1717 Minnesota Avenue Winter Park, Florida... -
Page 37: Industry Canada Attachment Limitation Notice
ESPRIT 708/ 718/728L/ 728/738/ 748/ 748ES ATTACHMENT LIMITATION NOTICE The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. -
Page 38: Index
INDEX About this manual ......4 "No movement" report..... 20 AC .
