Enpirion EN6360QI 8A DC/DC
Converter w/Integrated Inductor
Introduction
Thank you for choosing Altera Enpirion power products!
• The EN6360QI features integrated inductor, power MOSFETS, Controller,
bulk of the compensation Network, and protection circuitry against system
faults. This level of integration delivers a substantial reduction in footprint
and part count over competing solutions. However, the evaluation board is
not optimized for minimum footprint; rather for ease of evaluation through
programming options, clip leads, test points etc.
• The EN6360QI features a customer programmable output voltage by
means of a resistor divider. The resistor divider allows the user to set the
output voltage to any value within the range 0.6V to (V
Figure -1. The Dropout voltage is ~0.1*I
shipped is populated with a single R
R
resistors can be chosen by jumper settings to achieve several output
B
voltages.
• The EN6360QI includes the bulk of the compensation network internally.
However, an external phase-lead (zero) capacitor and resistor is required
as part of the feedback. This network is shown in Figure -1. Appropriate
component values allow for optimum compensation for a given Input
voltage and choice of loop bandwidth. The equations in Figure 1 provide
the details to calculate the component values.
• A footprint is provided for an SMC connector (not populated) for S_IN. A
clock source may be applied to S_IN to synchronize the device switching
frequency to the external source. Please see the datasheet for the
frequency lock frequency range. S_OUT will output a clock signal
synchronous with the switching frequency. S_OUT of one EN6360QI may
be connected to S_IN of another EN6360QI device.
• Jumpers are provided for logical programming of the following signals:
o ENABLE (ENA)
Enable may also be controlled using an external switching source
by removing the jumper and applying the enable signal to the
connector middle pin and ground.
o Master/Slave ternary input (M/S)
o Enable Pre-Bias Input (SEL)
o Jumpers are also provided for getting various output voltages.
®
Enpirion
Power Evaluation Board User Guide

Evaluation Board

A
Page 1 of 9
www.altera.com/enpirion
EN6360QI PowerSoC
-V
IN
. The evaluation board, as
LOAD
, and four possible R
). See
DROPOUT
resistors. The
B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Enpirion EN6360QI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Altera Enpirion EN6360QI

  • Page 1: Evaluation Board

    Converter w/Integrated Inductor Evaluation Board Introduction Thank you for choosing Altera Enpirion power products! • The EN6360QI features integrated inductor, power MOSFETS, Controller, bulk of the compensation Network, and protection circuitry against system faults. This level of integration delivers a substantial reduction in footprint and part count over competing solutions.
  • Page 2 VIN or logic High. WARNING: complete steps 1 through 4 before applying power to the EN6360QI evaluation board. STEP 1: Set the “ENA” jumper to the Disable Position. Page 2 of 9 www.altera.com/enpirion...
  • Page 3 To pull this pin low, put the jumper between the middle and right pins just as shown in Figure 2 for the ENABLE pin. Page 3 of 9 www.altera.com/enpirion...
  • Page 4 Now enable the pulse generator output. S_OUT should be locked to S_IN with a fixed delay. Sweep the clock frequency and note the lock range at both extremes. ALWAYS power down device before changing board level components! Page 4 of 9 www.altera.com/enpirion...
  • Page 5 ® Enpirion Power Evaluation Board User Guide EN6360QI PowerSoC Figure 4: Evaluation Board Layout Assembly Layer. Page 5 of 9 www.altera.com/enpirion...
  • Page 6 Short across R9 TP14 TP15 TP13 1206 1206 TP16 when all other TP11 TP12 VOUT PGND PGND routing completed 1206 TP32 TP17 TP18 TP20 BF_IN 04693 TP28 TP19 VOUT 04694 TP21 TP22 Figure 5: Evaluation Board Schematic Page 6 of 9 www.altera.com/enpirion...
  • Page 7: Input And Output Capacitors

    Output ripple and load transient deviations are conveniently measured at TP19. For more accurate ripple measurement, please refer to Enpirion App Note regarding this subject (www.altera.com/enpirion). 4. The board includes a pull-up for the POK signal and ready to monitor the power OK status.
  • Page 8: Bill Of Materials

    RES 150K OHM 1/8W 0.1% 0805 SMD RES 100K OHM 1/8W 0.1% 0805 SMD RES 4.42K OHM 1/8W 1% 0805 SMD TP1-TP5, TP13-TP16, TP21, TP22, TP28 TEST POINT SURFACE MOUNT EN6360QI 10A QFN TRANSIENT VOLTAGE SUPPRESSOR, 6.5V, BIDIRECTIONAL, SMT Page 8 of 9 www.altera.com/enpirion...
  • Page 9: Contact Information

    Altera warrants performance of its semiconductor products to current specifications in accordance with Altera's standard warranty, but reserves the right to make changes to any products and services at any time without notice. Altera assumes no responsibility or liability arising out of the application or use of any information, product, or service described herein except as expressly agreed to in writing by Altera.
