Altera EP2AGX45 Device Handbook

Arria ii series fpga development board. volume 1: device interfaces and integration
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This section provides a complete overview of all features relating to the Arria
device family, the industry's first cost-optimized 40 nm FPGA family. This section
includes the following chapters:
Chapter 1, Overview for the Arria II Device Family
■
Chapter 2, Logic Array Blocks and Adaptive Logic Modules in Arria II Devices
■
■
Chapter 3, Memory Blocks in Arria II Devices
■
Chapter 4, DSP Blocks in Arria II Devices
■
Chapter 5, Clock Networks and PLLs in Arria II Devices

Revision History

Refer to each chapter for its own specific revision history. For information on when
each chapter was updated, refer to the Chapter Revision Dates section, which appears
in this volume.
