Charging the batteries

The Entice can be equipped with two dry 12 Volt batteries of maximum 73Ah. At daily use the dry batteries need
no other maintenance than regular charge. The capacity of the batteries at 5 hours discharge is 70 Ah, at 20
hours discharge 75Ah.
The scooter is equipped with 2 Trojan type SG 70 B batteries. The battery connector type on the cable is Alex
PVC, dimensions 40 x 20 mm.
Because the batteries are probably empty or partly charged when they arrive, it is of great importance to first fully
charge the batteries. The scooter is fitted with a charger, standard delivered. If the batteries are charged using the
below procedure, you will gain maximum lifetime, power and reach of the batteries.
1. Turn off the power of your scooter
2. Put the power support cable in a wall socket
3. Put the battery charge cable into the tiller (turn away the round cover) (picture 40).
4. When the battery charger is turned on the scooter will be charged. During charge the progress indicator
will blink. A RED light means the charger is in use, a WHITE light means the scooter is being charged
and a GREEN light means the scooter is fully charged.
The Entice can not be driven electrically with a plug in the charge socket. If the range of the Entice is strongly
decreasing, the batteries need replacement. In this case you need to contact your dealer. It is not allowed to
replace the batteries yourself. When a battery is leaking contact dealer immediately! Please consider the following
when changing batteries: see that the connectors do not contact with each other. Make sure when connecting the
batteries the connectors are correctly poled (++ and --). The Entice comes with a battery charger. If any problems
occur please contact your dealer. It is not allowed to open the charger. The charge socket is indicated with a
symbol on the tiller (picture 40a). The charger connection is indicated on the charger with a symbol (picture 40b):
Picture 40
Rood
Picture 40a
Picture 40c
Excel Entice
Picture 40b
Pagina 14
