- Page 1 VHF RT2047 SAILOR COMPACT 2000 PROGRAMME ENGLISH...
- Page 2 The SAILOR RT2047 VHF radiotelephone has been designed to be used with the SAILOR Compact 2000 module pro- gramme. The SAILOR RT2047 can either be installed and operated as an independent unit, or in combination with other elements of the Compact 2000 module programme.
- Page 3 NOTE: 1. The distress call should be repeated from time-to-time until an answer is heard. 2. If no reply is heard on channel 16, the call should be repeated on any other available channel. 3. Speak slowly, pronouncing each word distinctly. PRIVATE CHANNELS There is standard provision for the programming of up to 20 private...
- Page 4 CONTROLS SCAN Turns the set on or off Selects scanning programme. SCAN Increases volume progressively in 16 steps. Adds a channel to the scanning table. SCAN DELETE Reduces volume progressively in 16 steps. Deletes a channel from the scanning table. SCAN Increases squelch sensitivity progressively in 8 steps, PROG...
- Page 10 CHANNEL APPLICATION AND FREQUENCY TABLE SIMPLEX DUPLEX FREQUENCIES FREQUENCIES SIMPLEX DUPLEX FREQUENCIES FREQUENCIES • • • • Tx: 156.050 MHz Tx: 156.025 MHz Tx: 156.050 MHz Tx: 156.025 MHz • • • • Rx: 160.650 MHz Rx: 160.650 MHz Rx: 160.625 MHz Rx: 160.625 MHz Tx: 156.100 MHz Tx: 156.075 MHz...
- Page 11 QUICK SELECT CHART Distress and Call Channel Channel Selection US-mode (Channel Required in the USA) SHIFT Reduced Power SHIFT D.W. Dual Watch SHIFT SCAN Select Scanning Programme e g 3 SHIFT SCAN Add a Channel to Scanning Programme SHIFT Start Scanning STOP SCAN DELETE...
- Page 12 SAILOR SAILOR • Porsvej 2 • PO Box 7071 • DK-9200 Aalborg SV • Denmark ® Phone: +45 9634 6100 • Fax: +45 9634 6101 • Telex: 69789 ECI DK E-mail: sailor@sailor.dk • Web: www.sailor.dk...
Need help?
Do you have a question about the VHF RT2047 and is the answer not in the manual?
Questions and answers
Hvor stor sikring på 12v forsyning. VHF RT 2047.
The appropriate fuse size for the 12V supply of the Sailor VHF RT2047 should be based on its maximum current consumption of 6 amps during transmission. A fuse rated slightly above 6 amps, such as 7A or 8A, would be appropriate to protect the circuit while allowing normal operation.
