To identify the position and function of the
fuses, refer to the information provided under the
lid of the box and on the attached wiring diagram;
the reference letters in the figure correspond to
those shown in the diagram.
Remember that the fuse box contains three spare
fuses.
WARNING
Never replace a fuse with a rating other
than that precribed, in order to avoid
damage to the electrical equipment of
the motorcycle. This could lead to a fire
with subsequent risk of serious burns,
6
as well as damage to the motorcycle.
MAINTENANCE
F1
- 166 -
F2 F3 F4 F5
10A 10A 15A
6
F6 F7
