Summary of Contents for Jet-tech 737E
- Page 1 JET TECH TECHNICAL MANUAL 737E VER1.02 2015/12...
- Page 2 Richard M. Hiller Special Projects Manager richard@mvpgroupcorp.com service @mvpgroupcorp.com Tools Metric (inches) (mm) 3.18 Some of the tools you will need 5/32 3.97 to repair and service the 737e. 3/16 4.76 13/64 5.16 7/32 5.56 Volt Meter 15/64 6.05 Temperature meter Allen Keys (Metric) 6.35...
- Page 3 Top of 737e 20732 20067 20173 20713 20714 20104 20715 20716 20718...
- Page 4 Wash Cycles Cycle Start 4m 3m 2m Display ON/OFF Drain Unused Touch-Pad Final Rinse Probe temperature probe Wash Tank Temperature probe rinse booster Power line L1 Power line L2 Door switch signal Water level signal Booster Heat Power Line L2 Wash Wash Heat Incoming Water (chemicals)
- Page 5 ELECTRONIC BOARD PROGRAMMING START MENU ACCESS Level 1 Level 1 access will allow you to change the first 4 settings. TURN THE MACHINE ON AND OFF BY PRESSING BUTTON A. (IF THE MACHINE IS ALREADY ON, TURN IT OFF BY PRESSING BUTTON A) PRESS BUTTON B SEVEN (7) TIMES WITHIN (10) SECONDS FROM TURNING OFF MACHINE.
- Page 6 ∗DEFAULT 0 = FILTERED ∗DEFAULT 0°C DON’T MODIFY DON’T MODIFY DON’T MODIFY DON’T MODIFY DON’T MODIFY DON’T MODIFY DRAIN PUMP CYCLE MODEL (DISPLAY) (DISPLAY) 727E / 737E 120 + 180 + 240 sec 757E 70 + 120 + 180 + 240 sec...
- Page 7 Level 2 Level 2 access will allow you to change all 14 settings. TURN THE MACHINE ON AND OFF BY PRESSING BUTTON A. (IF THE MACHINE IS ALREADY ON, TURN IT OFF BY PRESSING BUTTON A) PRESS BUTTON B SEVEN (7) TIMES WITHIN (10) SECONDS FROM TURNING OFF MACHINE.
-
Page 8: Error Codes
A-02 A-03 CARL VUOT MAX FILL TIME MAX DRAIN TIME MIN 1 MIN MIN 1 MIN MAX 20 MIN MAX 20 MIN DEFAULT 10 MIN DEFAULT 2 MIN Error Codes ntcb Booster temperature probe faulty or not connected properly E-01 ntcu Tank temperature probe faulty or not connected properly E-02... - Page 9 Level 3 Level 3 access will allow you test different components. TURN THE MACHINE ON AND OFF BY PRESSING BUTTON A. (IF THE MACHINE IS ALREADY ON, TURN IT OFF BY PRESSING BUTTON A) PRESS BUTTON C SEVEN (7) TIMES WITHIN (10) SECONDS FROM TURNING OFF MACHINE.
-
Page 14: Parts List
TANK AT 50 12027 CONNECTOR 17025 RIGHT LAT.PANEL AT 50 12028 17026 LEFT LAT.PANEL AT 50 12030 TUBE 17027 PANEL JET-TECH 737 NSF 12035 TUBE 17056 FLASK MANOMETER 737 NSF 12037 TUBE 20017 FIXING CABLE ST 16 12038 FILTER 20050... - Page 15 20589 FILTER FOR AUT.DET.DOSER 5X7 60200 N UT 20692 MAGNETIC SWITCH E5121VDA0196 60201 N UT 20693 MAGNET M302NCBCNC42 60202 N UT 20707 SUPPORT FOR ELECTRONIC CARD 60208 N UT 20713 ELECTRONIC CARD POWER 60210 N UT 8M A 20714 ELECTR.CARD CONTROL AND VIEW 60212 N UT 20715...
- Page 16 Jet Tech Systems, within the continental United States of America or Canada; provided that: prior authorization for this labor was approved by Jet-Tech Systems, the service work was performed by an authorized Jet Tech service agency; and that this agency installed an original and genuine Jet Tech part in the machine.
- Page 17 SERVICE CALL REGULATIONS JET TECH ware washers are warranted as specified in the MANUFACTURERS LIMITED WARRANTY. Upon receiving the demand for repairs on a unit, we will create a work order or Warranty Authorization which will have all the pertinent information. We will send this form to you as a purchase order for service.
- Page 18 COVER PAGE 2 CONTACT 3 TOP OF DISHWASHER 4 ELECTRONICS 5 PROGRAMMING 6 PROGRAMMING (CONT) 7 PROGRAMMING (CONT) 8 PROGRAMMING (CONT) 8 ERROR CODES 9 LEVEL 3, TESTING 10 EXPLODED VIEW 11 EXPLODED VIEW (CONT) 12 EXPLODED VIEW (CONT) 13 EXPLODED VIEW (CONT) 14 PARTS LIST 15 PARTS LIST (CONT) 16 WARRANTY...
