WARRANTY This instrument is warranted to be free from defects in material and workmanship for a period of one Lear. Any instrument found defective within one year from the delivery date and returned to the factory with transportation charges prepaid, will be repaired, adjusted, or replaced at no charge to the original purchaser.
l. Remove the test lead and test probe from the circuit under test before you open the case or battery door. m. Do not operate meter with the battery door, portions of the case or the test probe removed or loosened.
Page 4
SYMBOLS AC (Alternating Current) DC (Direct Current) DC or AC (alternating current or direct current) Caution, risk of danger, refer to the operating manual before use. Caution, risk of electric shock Earth (ground) Terminal Fuse Conforms to European Union directives The equipment is protected throughout by double or reinforced insulation Diode Continuity test...
SPECIAL MARKS For your safety, there are some marks on the panel. Be cautioious. The max. voltage the meter can measure is 600V DC or AC. The max. current the meter can measure is 200mA DC or AC The meter complies with CAT II 600 FEATURES Dsiplay: 3 ½...
Page 6
2kΩ,20kΩ.200kΩ, 2MΩ ±(1.0% + 2) 20MΩ ±(2.0% + 2) Open circuit voltage ≈ 1.5V; Test current ≈ 0.5mA 20mA ±(1.2% + 3) 200mA 20mA ±(1.5% + 5) 200mA If R <about 50Ω, the built0in buzzer sounds INSTRUCTION 1. Display 3 ½ digits LCD with max. reading 1999 Buton To enable the flashlight function, Press and hold down this button.
Page 7
This button can also be used to arouse the meter from Sleep. 4. Function Switch The switch is used for selecting the desired function. To preserve the battery’s life, set the switch to “OFF” position when the meter is not in use. 5.
Page 8
Measuring AC Voltage • Set the function switch to position, • Press the button to select AC range, the display shows • Connect the test probe and black test lead cross the source or load to be measured. • The display will show the reading. Note: Input impedance: about 10MΩ...
Page 9
Measuring Resistance • Set the function switch to Ω position. • Connect the test probe and the black test lead across the load to be measured. • Read the reading on the LCD Note: If the resistance is more than 1MΩ, it may take several seconds to stabilize the reading. It is normal for high resistance measurement.
• Connect the black test lead to the ground terminal of the circuit to be measured, the test probe to the desired test point of the circuit. • If the level of the test point is more than or equal to 2.3±0.2V, the LCD will show and the voltage value, meanwhile the meter will sound discontinuously.
Page 11
TIP: If the test lead in the case is not put to a correct position, the back cover can not be installed. ACCESSORIES Bartery: 1 piece Manual: 1 piece DISPOSAL OF THIS ARTICLE Dear Customer If you at some point intend to dispose of this article, then please keep in mind that many of its components consist of valuable materials, which can be recycled.
