Page 2
I.General His is equipped with the LCD display of text height 18.9 mm, is a 3 ¾ digital multimeter which has the merits of clear Reading, stable performance and high reliability. It could be used to measure DC voltage, AC voltage, DC current, AC current, resistance , capacity, frequency/duty cycle, diode and make on and off test.
Page 3
Before the replacement, the test leads must leave the measuring point and ensure there is no any signal at the input terminal. 5. Don’t use other unconfirmed or disapproved battery to replace the battery inside the meter. Only the battery of the same model or same electrical specification can be replaced. Before the replacement, the test leads must leave the measuring point and ensure there is no any signal at the input terminal.
Page 4
Warning! High Voltage! Danger! Ground DCA & ACA In accordance wiyh the instructions Double Insulation of European Trade Union Battery Undervoltage Fuse IV. Instrument Panel & Button Function Description 1. Instrument Model Number 2. LCD Display: Display the measured data and unit. 3.
Page 5
5.3. Voltage, Diode, Resistance, Capacity, Frequency, Buzzer, Temperature and “+” Input terminal with current less than 200mA. V. Other Functions Automatic Power off During measurement, the meter will automatically shut down (enter sleeping mode) to save power if function buttons and knob switch are not operated in 15 minutes. In auto power off mode, press any function buttons or rotate the knob switch, the instrument will get into the auto power on mode (working mode);...
Page 6
2. Technical Properyty: 2.1. Accuracy: ± (% reading + digits), at (23±5)°C, Relative humidity <75%, One year calibration guarantee since the time dispatched from the factory. 2.2. Technical Specifications: 2.2.1. DCV 1. Turn the knob switch to Range 2. The initiate state of the meter is in automatic range status, which shows “AUTO” symbol. 3.
Page 7
4. Make the test leads connected to the testing point. The voltage of the point where the red pen is contacted will be displayed on the screen. Caution: 1. Don’t measure voltage over 600V. Otherwise, there is a danger of meter being damaged. 2.
Page 8
Range Accuracy Resolutin 400µA 0.1µA 4000µA 1µA ±(1.0% + 10 d) 40mA 10µA 400mA 100µA ±(1.2% + 10 d) 10mA Max measurement voltage drop: Full Range mA is 0.4V, A is 100mV; Max input current : 10A (less than 15 seconds); Overload Protection: 0.4A/250V restorable fuse, 10A/250V fuse.
Page 9
Overload Protection: 0.4A/250V restorable fuse; 10A/250V fuse Frequency Response: 10A Range (50~200) Hz 2.2.5. Resistance (Ω) 1. Insert the black meter pen into “COM” terminal and red one into terminal. 2. Rotate the Range to “Ω” gear. Cross connect the test leads to the tested resistor. 3.
Page 10
2.2.6. Diode and Continuity Test 1. Insert the black meter pen to “COM” terminal and the red one to terminal. (The polarity of red test lead is “+”) 2. Rotate the Range to “ ” gear. Press „SELECT” button to select the Diode measurement mode.
Page 11
Caution: 1. Fully discharge the tested capacitor in case it damages the meter. 2. When measuring in-line capacitor, the power should be turned off and all capacitors should be discharged completely. 3. It takes about 30 seconds to input stable reading at 100uF Range. Range Accuracy Resolution...
Page 12
Range Accuracy Resolution 0.001Hz 10Hz 0.01Hz 100Hz 0.1Hz 1kHz ±(0.5% + 10 d) 10kHz 10Hz 100kHz 100Hz 1MHz 1kHz 30MHz 10kHz 0.1 – 99.9% For your reference 0.1V Input Sensitivity: > 0.7V RMS Overload Protection: 250V DC or AC Peak Value 2.2.9.
Page 13
VII. Instrument Maintenance This is a precision instrument and the user shall not modify the electric circuit at will. 1. Keep the instrument away from water, dust and shock. 2. Do not store and operate the meter under the condition of high temperature, high humidity, combustible, explosive and strong magnetic place.
Page 14
This Instruction is subjected to change without any further notice. The content of this Instruction is considered correct, and in case readers find any errors and missing parts, please contact the manufacturer. The Company shall not be held liable for any accidents and hazards resulted from the mal- operations by the user.
