Summary of Contents for Axio MET AX-18B

  • Page 1 AX-18B INSTRUCTION...

  • Page 2: Table Of Contents

    Contents 1. General instructions .................... 3 1.1. Precautions safety measures ................3 1.2. Protection mechanisms ..................5 2. Description ...................... 6 2.1. Instrument Familiarization ................. 6 2.2. LCD Display ....................6 2.3. Keypad ......................7 3. Function description ................... 8 3.1.

  • Page 3: General Instructions

    1. General instructions This instrument complies with IEC 1010-1 (61010-1@IEC: 2001), CAT. II 1000V and CAT. III 600V overvoltage standards. See Specifications. To get the best service from this instrument, read carefully this user's manual and respect the detailed safety precautions. International symbols used on the Meter and in this manual are explained in chapter 1.1.3 1.1 Precautions safety measures 1.1.1 Preliminary...
  • Page 4 • Verify a Meter's operation by measuring a known voltage. Do not use the Meter if it operates abnormally. Protection may be impaired. When in doubt, have the Meter serviced. • Uses the proper terminals, function, and range for your measurements. •...

  • Page 5: Protection Mechanisms

    Caution: refer to the instruction manual. Incorrect use may result in damage to the device or its components. AC (Alternating Current) DC (Direct Current) AC or DC Earth ground Double insulated Fuse Conforms to European Union directives 1.1.4 Instructions • Remove test leads from the Meter before opening the Meter case or battery cover. When servicing the Meter, use only specified replacement parts.

  • Page 6: Description

    2. Description 2.1 Instrument Familiarization 1) LCD display 2) Keypad 3) Rotary switch 4) Terminals 5) Battery cover 2.2 LCD Display 1) Indicator for AC voltage or current 2) Indicates negative readings 3) Indicator for DC voltage or current 4) The meter is in the Autorange mode in which the meter automatically selects the range with the best resolution.

  • Page 7: Keypad

    8) The meter is in Data Hold mode. 9) The meter is in Relative Measurement mode. 10) Display maximum data 11) Display minimum data 12) Low battery indication (Note: When this symbol appears, it means that the battery needs to be replaced.) 13) Measurement units 14) This symbol means that the input is too large for the selected range.

  • Page 8: Function Description

    3. Function description 3.1 General Functions 3.1.1 DATA HOLD mode Data Hold mode makes the meter stop updating the display. Enabling Data Hold function in autorange mode makes the meter switch to Manual ranging mode, but the full-scale range remains the same.

  • Page 9: Measurement Functions

    To enter and exit the relative measurement mode: 1) With the Meter in the desired function, touch the test leads to the circuit on which you want future measurement to be based. 2) Press REL key to store the measured value and activate the relative measurement mode. The difference between the reference value and subsequent reading is displayed.
  • Page 10 The Meter's resistance ranges are 600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, 6.000MΩ and 60.00MΩ. To measure resistance: 1) Set the rotary switch to Ω Ω Ω Ω range. 2) Connect the black and red test leads to the COM and VΩ terminals respectively. 3) Connect the test leads to the circuit being measured and read the displayed value.
  • Page 11 3.2.4 Continuity Check To avoid electrical shock and/or damage to the instrument, disconnect circuit power and discharge all high-voltage capacitors before testing for Continuity. To test for continuity: 1) Set the rotary switch to Ω Ω Ω Ω range. 2) Press the SELECT key twice to activate Continuity Check. 3) Connect the black and red test leads to the COM and Ω...
  • Page 12 1) With the meter in the desired function (AC Voltage or AC Current), press the Hz/DUTY key. 2) Read the frequency of the AC signal on the display. 3) To make a duty cycle measurement, press the Hz/DUTY key again. 4) Read the percent of duty cycle on the display..
  • Page 13 The Meter's current ranges are 600.0µA, 6000µA, 60.00mA, 600.0mA, 6.000A and 10.00A. To measure current: 1) Turn off power to the circuit. Discharge all high voltage capacitors. 2) Set the rotary switch to the µA, mA or A range. 3) Press the SELECT key to select DCA or ACA measuring mode. 4) Connect the black test lead to the COM terminal and the red test leads to the mA terminal for a maximum of 600mA.

  • Page 14: Technical Specifications

    • Scroll through the list of installed devices till you locate the Ports (Com and LPT) entry. Click the plus (+) beside this entry to view the installed ports, If no errors occur, the Sunplus USB to Serial COM Port (COM x) will appear, COM x is just the proper port, here x is a specific number. 6) Select the default sampling rate or you can select other desired sampling rate.
  • Page 15 4.2.1 Voltage DCV: Range Resolution Accuracy 600mV 0.1mV ±(0.5% of rdg +8 digits) 10mV ±(0.8% of rdg +5 digits) 600V 100mV 1000V ±(1.0% of rdg +10 digits) ACV: Range Resolution Accuracy ±(3.0% of rdg + 3 digits) 600mV 0.1mV Manual Range only ±(1.0% of rdg + 3 digits) 10mV 600V...
  • Page 16 4.2.3 Resistance Range Resolution Accuracy 600.0Ω 0.1Ω ±(0.5% of rdg+3 digits) 6.000kΩ 1Ω 60.00kΩ 10Ω ±(0.5% of rdg+2 digits) 600.0kΩ 100Ω 6.000MΩ 1kΩ ±(1.5% of rdg+3 digits) 60.00MΩ 10kΩ Overload Protection: 250V dc or 250V ac rms 4.2.4 Diode Test Range Resolution Accuracy...

  • Page 17: Maintenance

    Overload Protection: 250V dc or 250V ac rms 4.2.8 Current DCA: Range Resolution Accuracy 600µA 0.1µA ±(1.5% of rdg+3 digits) 6000µA 1µA 60mA 0.01mA ±(1.8% of rdg+5 digits) 600mA 0.1mA ±(2.0% of rdg+5 digits) 10mA ACA: Range Resolution Accuracy 600µA 0.1µA ±(1.8% of rdg+5 digits) 6000µA...

  • Page 18: Fuse Replacement

    To clean the terminals: Turn the meter off and remove all test leads. Shake out any dirt that may be in the terminals. Soak a new swab with a cleaning and oiling agent (such as WD-40). Work the swab around in each terminal. The oiling agent insulates the terminals from moisture- related contamination.

  • Page 19: Accessories

    6. Accessories Delivered with the multimeter: ¥User's manual One piece ¥Test leads One piece ¥"K" type Thermocouple One piece ¥Capacitor test lead One piece PC-Link software CD One piece...
