Summary of Contents for Reliable i300
- Page 1 Professional Iron System Instruction Manual...
- Page 2 USER INSTRUCTIONS i300 Thank you for purchasing the Reliable™ i300 series iron system. Please follow the instructions carefully. With proper care and maintenance, your steamer will provide years of dependable service. Remove the ironing station from its packing and make sure all packing parts have been taken off (including the protection bags).
- Page 3 COMPONENTS: Safety cap Wand to hold mono-hose up Iron button Boiler button Light for low water Temperature regulating knob Steam button...
-
Page 4: Technical Data
Adjustable iron thermostat set from 60°C to 215°C Bimetallic safety iron thermostat with manual reset at 275°C Full aluminium-plated heating element at 800W – 120V Boiler power i300: 700W Working pressure i300: 2,5 bar Tank nominal capacity of model i300: 1.4 litres TROUBLESHOOTING PROBLEM EXPLANATION SOLUTION... - Page 5 There is 1) The steam knob (where supplied) 1) Open the steam knob anticlockwise. no steam might be closed coming out of the 2) The iron switch might be off 2) After the iron switch comes on, wait for 4 iron? minutes so that the iron plate gets hot.
- Page 6 SPARE PARTS LIST i300 ITEM CODE DESCRIPTION Q.TY AST114 FAIRLEAD FOR HEATING ELEMENT FOR IRONING BOARD CD338/1 NUT FOR WAND HOLDER CD338/2 WASHER FOR WAND HOLDER CD338/3 WAND SUPPORT CD339/023 BOILER CD343/700 COPPER HEATING ELEMENT V120 W700 CD342 TEFLON O-RING FOR THE HEATING ELEMENT...
- Page 7 ITEM CODE DESCRIPTION Q.TY FS200/120 IRON PLATE FS003 ADJUSTABLE THERMOSTAT FS004 THERMOSTAT 271 MANUAL RESET FS005 CORK HANDLE FS006 BRACKET FOR STEAM IRON FS007 CAP FOR STEAM IRON FS009 WIRING FOR STEAM IRON FS011 INSERT FPR HANDLE 121 MM. FS012 FIXING SCREW M4*22 FS014 BACK HANDLE SCREW...
- Page 8 PARTS DRAWING...
- Page 9 WIRING DIAGRAM...
- Page 10 WATER LEVEL STICK...
- Page 12 www.reliablecorporation.com...
