monolith MLS50 Operating Instructions And Warranty

Warranty Card – Strip Cut Paper Shredder
Strip Cut Paper Shredder MLS50/ 09/2009
Please complete this warranty card and enclose it with
the machine, together with your proof of purchase.
Customer data:
Surname, first name:
Street, number:
Postcode, town: Country:
Telephone number with international dialling code:
Description of fault:
Date of purchase:
Date/signature:
Note:
When claiming on the warranty, the warranty card and the proof of purchase must be included with the
machine as well as a detailed description of the fault wherever possible. Warranty cards sent separately
afterwards will not be accepted.
Customer service:
monolith Service Hotline: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR)
Service fax number: +49 (0) 6151 / 10 19 019
E-mail: info@monolithshop.de
Service address: Kentner Spedition, password: monolith, Industriestr. 40 G, D-44892 Bochum
Helpline No.: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR) • Model Number: MLS50
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
Helpline No.: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR) • Model Number: MLS50
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
MLS50 Strip Cut
Paper Shredder
MLS50 / 09/2009
AFTER SALES SUPPORT
HELPLINE NO: 0 808 / 1 01 22 42 (UK)
1 800 / 65 50 09 (IR)
WEB SUPPORT: www.monolithshop.de
MODEL NUMBER: MLS50
Operating Instructions and Warranty
Contents
1.
Description of MLS50 components 3
2. Technical Data 3
3. Before using your shredder 4
4. Key to warning symbols 4
5.
Electrical safety instructions 5
6. Operation 6
7. Protecting the motor 6
8. Clearing a paper jam 6
9. The shredder does not switch itself off automatically 7
10. Maintenance and care
7
11. Storage 7
12. Disposal 7
13. Terms of guarantee 8
14. Guarantee card 9
Information on safety instructions
All safety instructions and other important information are highlighted in grey.
The item has safety features.
However, to avoid damage or injury, read the safety instructions carefully and
only use the shredder as described in this guide.
Keep the guide for future reference.
If you are giving the machine to someone else, please keep this guide with the
product.
Helpline No.: 0 808 / 1 01 22 42 (UK), 1 800 / 65 50 09 (IR) • Model Number: MLS50 2
monolith GmbH • Schwarze Horn 1 • D-45127 Essen • www.monolithshop.de
1. Description of MLS50 components
3
2
5
4
1
1 Retractable bar for attachment to Mains cable
3
a waste bin
Paper sensor
4
Sliding switch
2
5 Paper feed slot
(ON/AUTO/FWD/REV)
2. Technische Daten MLS 50
Model MLS 50
Working width 218 MM (A4)
Cutting capacity per cycle Up to a maximum of 5 sheets (80 g/m 2 )
Speed 2.5 m per minute
Cutting process Ribbon cut
Particle size 7 mm cut width
Position contact sensors 27.5 mm to 37.5 mm
Automatic start/stop function Yes
REV/FWD reverse function Yes
Nominal operating period 2 minutes
Nominal rest period
60 minutes
Noise level 73 DB
Nominal voltage 220 – 240 V ~ 50 Hz
Power rating 115 Watt/0.5 A
Safety class II
Dimensions (W x D x H) 314 x 115 x 76 mm
