Specifications; Troubleshooting - Stanley FATMAX BC8S Instruction Manual

CHARGING WITH THE TERMINAL RINGS
1. Disconnect AC power cord from AC power outlet
2. Disconnect the Battery Clamps, Terminal Rings or DC Accessory Plug from the battery charger's Double Barrel Charger Connector.
3. With the terminals rings properly connected to the battery posts, connect the terminal ring connector with the unit's Double Barrel
Charger Connector (male-to-female and female-to-male) and position it as far away from the battery as possible.
4. Insert the AC plug of the battery charger into a (powered) standard North American 120 volt 60Hz outlet. The Power LED will light
green to indicate the unit is in standby mode and ready to use.
Note:
If the Power LED does not come on, check connection with the AC outlet. Make sure the AC outlet is functional.
5. When the charger is properly connected, choose the following operation mode for the battery to be charged by pressing the Mode
Selector Button.
• Motorcycle Mode, suitable for most small vehicles like motorcycles.
• Vehicle Mode, for most automobiles.
The corresponding mode LED (Motorcycle Mode or Vehicle Mode) will light green. The charging process will start automatically after a
few seconds and the Charging LED ( ) will light yellow to indicate the unit is in charging mode.
Notes:
If the terminal rings are incorrectly connected with regard to polarity, the Reverse Polarity/Fault LED ( ) will light. Unplug the charger; then
remove the terminal rings. Reconnect the terminal rings properly.
If the Charging LED did not come on, check the connection to the battery. If the terminal rings are properly connected, the battery may be in fault
condition. Manufacturer suggests to have the battery tested by a qualified battery service technician.
6. When the battery is fully charged, the charger will automatically go into Float Charge Mode and the Charged LED ( ) will light. In
this mode, the charger monitors the battery voltage and charges as necessary to assure the battery maintains full capacity. The
charger remains in Float Charge Mode as long as the charger is connected to the battery and the charger is plugged into a functioning
AC outlet.
When disconnecting charger, disconnect AC cord, remove the terminal rings from battery posts.
Charging Using the DC Accessory Plug
WARNING: NEVER connect this unit to a positive grounded vehicle using the 12 Volt DC Accessory Plug.
1. Disconnect AC power cord from AC power outlet
2. Disconnect the Battery Clamps, Terminal Rings or DC Accessory Plug from the battery charger's Double Barrel Charger Connector.
3. Insert the double barrel tip of the 12 Volt DC Accessory Plug cable into the double barrel tip of the Double Barrel Charger Connector
(male-to-female and female-to-male).
4. Insert the grooved tip of the 12 volt DC accessory plug into the vehicle's 12 volt DC accessory outlet.
5. Insert the AC plug of the battery charger into a (powered) standard North American 120 volt 60Hz outlet. The Power LED will light
green to indicate the unit is in standby mode and ready to use.
Note:
If the Power LED does not come on, check connection with the AC outlet. Make sure the AC outlet is functional.
6. When the charger is properly connected, choose the following operation mode for the battery to be charged by pressing the Mode
Selector Button.
• Motorcycle Mode, suitable for most small vehicles like motorcycles.
• Vehicle Mode, for most automobiles.
The corresponding mode LED (Motorcycle Mode or Vehicle Mode) will light green. The charging process will start automatically after a
few seconds and the Charging LED ( ) will light yellow to indicate the unit is in charging mode.
Notes:
If the Charging LED did not come on, check the connection to the vehicle's DC accessory outlet. Rotate the adapter slightly to make sure there is
good contact. If it is properly connected, the battery may be in fault condition. Manufacturer suggests to have the battery tested by a qualified
battery service technician.
Some vehicles require that the ignition be turned to the ACC (accessory) position to activate the DC accessory outlet. If your vehicle ignition is
required to be turned to the ACC position, be sure all the vehicle accessories (i.e. heater, fan, radio, TV, lights... etc) are turned off. If not turned
off, the charger might not be able to charge the battery.
7. When the battery is fully charged, the charger will automatically go into Float Charge Mode and the Charged LED ( ) will light. In
this mode, the charger monitors the battery voltage and charges as necessary to assure the battery maintains full capacity. The
charger remains in Float Charge Mode as long as the charger's 12 Volt DC Accessory Plug is connected to the vehicle's 12 volt DC
accessory outlet and the unit is plugged into a functioning AC outlet.
When disconnecting charger, disconnect AC cord, and then remove the 12 volt DC accessory plug from the vehicle accessory outlet.

TROUBLESHOOTING

Unit Not Charging
• Check that the charger is properly connected to a live 120 volt AC outlet.
• If the battery to be charged has fallen below 2 volts, the battery cannot be recharged with this unit.
CARE AND MAINTENANCE
Storage
• Store the unit in a clean, dry, cool place when not in use.
• Clean the unit casing and cords (as necessary) with a dry (or slightly damp) cloth. Ensure that unit is completely disconnected from
battery and power source before cleaning.
BC8S_BC8A10_ManualENSP_061714.indd 8-9
8
• To maintain the operating condition and maximize the life of the charger cords, always coil them loosely for storage. Do not wrap them
around the unit or crimp them with a tight band.
Fuse Replacement (DC Accessory Plug)
1. Remove plug from accessory outlet. Remove the grooved cap by turning counter clockwise and lifting off.
2. Remove center pin and spring. Remove fuse.
3. Replace fuse with same type and size fuse (10 amp).
4. Replace center pin and spring inside plug.
5. Replace gold cap by turning clockwise.
ACCESSORIES
Recommended accessories for use with this unit may be available from the manufacturer. If you need assistance regarding accessories,
please contact the manufacturer at 1-877-571-2391.
WARNING: The use of any accessory not recommended for use with this appliance could be hazardous.
SERVICE INFORMATION
Whether you need technical advice, repair, or genuine factory replacement parts, contact the manufacturer at 1-877-571-2391.
ONE-YEAR LIMITED WARRANTY
The manufacturer warrants this product against defects in materials and workmanship for a period of ONE (1) YEAR from the date of
retail purchase by the original end-user purchaser ("Warranty Period").
If there is a defect and a valid claim is received within the Warranty Period, the defective product can be replaced or repaired in the
following ways: (1) Return the product to the manufacturer for repair or replacement at manufacturer's option. Proof of purchase may
be required by manufacturer. (2) Return the product to the retailer where product was purchased for an exchange (provided that the
store is a participating retailer). Returns to retailer should be made within the time period of the retailer's return policy for exchanges
only (usually 30 to 90 days after the sale). Proof of purchase may be required. Please check with the retailer for their specific return policy
regarding returns that are beyond the time set for exchanges.
This warranty does not apply to accessories, bulbs, fuses and batteries; defects resulting from normal wear and tear, accidents; damages
sustained during shipping; alterations; unauthorized use or repair; neglect, misuse, abuse; and failure to follow instructions for care and
maintenance for the product.
This warranty gives you, the original retail purchaser, specific legal rights and you may have other rights which vary from state to state or
province to province. This product is not intended for commercial use.
Please complete the Product Registration Card and return within 30 days from purchase of the product to: Baccus Global LLC, 595 S.
Federal Highway, Suite 210, Boca Raton, FL 33432. Baccus Global LLC, toll-free number: (877) 571-2391.

SPECIFICATIONS

Input: 120VAC , 60Hz, 1.8A
Output: 12VDC, 2A, 8A
Imported by Baccus Global LLC, 595 S. Federal Highway, Suite 210, Boca Raton, FL 33432 • (877) 571-2391
RD061714
9
