ECS BAT-I2 User Manual page 9

Table of Motherboard Components
LABEL
1. ATX_PWR
2. CPU_FAN
3. CLR_CMOS
4. DIMM1
5. CASE
6. COM1~2
7. LDC
8. LPT
9. SYS_FAN
10. F_PANEL
11. DISP_BRT
12. LVDS
13. BKLT_PWR
14. LCD_PWR
15. BZ
16. MINIPCIE
17. SATA_PWR
18. F_AUDIO
19. SATA1~2
20. F_USB1~2
21. ATX19V
COMPONENTS
Standard 24-pin ATX power connector (optional)
4-pin CPU cooling fan connector
Clear CMOS jumper
204-pin DDR3 SDRAM SO-DIMM
Case open header
Onboard serial port headers
Debug card header
Onboard parallel port header
4-pin system cooling fan connector
Front panel switch/LED header
LVDS brightness control header (optional)
LVDS connector (optional)
Backlight power jumper (optional)
LVDS select jumper (optional)
Buzzer
mini PCIE (half card) slot
SATA power connector (optional)
Front panel audio header
Serial ATA 3Gb/s connectors
Front panel USB 2.0 headers
4-pin +19V power connector (optional)
BAT-I2 USER MANUAL
5
