M.I.B III (MB Intelligent BIOS III) Menu
This page displays the information of clock speeds and enables you to set the
memory voltage for your system. The clock speeds are determined by the kind of
processor installed in your system.
Main Advanced
M.I.B III (MB Intelligent BIOS III)
CPU Frequency
CPU Ratio
Intel(R) Celeron(R) CPU J1800 @ 2.41GHz
CPU Speed
Memory Frequency
Total Memory
Memory Voltage Control
CPU Frequency (83.3 MHz)
This item shows the frequency of CPU reference clock.
CPU Ratio (29)
This item shows the max CPU ratio supported.
Intel(R) Celeron(R) CPU J1800 @ 2.41 GHZ
This is display-only field and displays the information of the CPU installed in your
computer.
CPU Speed (2.41 GHz)
This item shows the CPU speed.
Memory Frequency (1333 MHz)
This item shows the memory frequency.
Total Memory (2048 MB (LPDDR3))
This item shows the total memory.
44
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
