Dynaflite Bird of Time Instruction Manual

Unlimited class 3-meter arf sailplane
Hide thumbs Also See for Bird of Time:
Table of Contents

Advertisement

Quick Links

READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT
CONTAINS IMPORTANT INSTRUCTIONS AND WARNINGS CONCERNING THE
ASSEMBLY AND USE OF THIS MODEL.
Wingspan: 117 in. [2972mm]
Wing Area: 1050 sq in [67.73 dm
Weight: 60 oz [1700 g]
Wing Loading: 8.2 oz/sq ft [25.0 g/dm
Length: 49 in. [1245mm]
Radio: 2-Channel with 2 servos
Dynaflite
®
guarantees this kit to be free from defects in both material and workmanship at the
date of purchase. This warranty does not cover any component parts damaged by use or
modification. In no case shall Dynaflite's liability exceed the original cost of the
purchased kit. Further, Dynaflite reserves the right to change or modify this warranty without
notice. In that Dynaflite has no control over the final assembly or material used for final
assembly, no liability shall be assumed nor accepted for any damage resulting from the use by
the user of the final user-assembled product. By the act of using the user-assembled product,
the user accepts all resulting liability. If the buyer is not prepared to accept the liability
associated with the use of this product, the buyer is advised to return this kit
immediately in new and unused condition to the place of purchase.
Entire Contents © Copyright 2003
™
2
]
]
2
WARRANTY
Instruction Manual
DYFZ5000 for DYFA0500 V1.0
™
P .O. Box 788
Urbana, IL 61803
(217) 398-8970
productsupport@dynaflite.com
