Para obtener un ejemplar en Español de este
Manual del propietario, visite www.heatnglo.com.
Model:
ST-36TVB-IPI
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe
installation and operation.
Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13
Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com.
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
A CO detector shall be installed in the room where the appliance
is installed.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
1
Advertisement
Table of Contents
Related Manuals for Heat & Glo ST-36TVB-IPI
Summary of Contents for Heat & Glo ST-36TVB-IPI
- Page 1 Installation and service of this appliance should be performed by qualifi ed personnel. Hearth & Home Technologies suggests NFI certifi ed or factory trained professionals, or technicians supervised by an NFI certifi ed professional. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 2: Congratulations
BTUH: 00,000 00,000 00,000 00,000 MIN. MIN. INPUT INPUT BTUH: BTUH: 00,000 00,000 00,000 00,000 Serial Serial ORIFICE ORIFICE SIZE: SIZE: #XXXXX #XXXXX #XXXXX #XXXXX XXXXXXXX XXXXXXXX (Serie): (Serie): Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 3: Table Of Contents
I. Air Shutter Setting ......39 Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 4 C. Contact Information ......46 = Contains updated information. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 5: Limited Lifetime Warranty
3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645F 02-18-13 Page 1 of 2 Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 6 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645F 02-18-13 Page 2 of 2 Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 7: Listing And Code Approvals
A 110-120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 8: User Guide
- A decorative fi rescreen. - Adjustable safety gate. DECORATIVE DOORS (NOT SHOWN) SECTION 2.D. FIXED GLASS ASSEMBLY (NOT SHOWN) SECTION 14.H. MANTEL HEARTH CLEAR SPACE SECTION 2.C. Figure 2.1 General Operating Parts Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 9: Clear Space
For more information refer to the instructions supplied with erate fi replace with fi xed glass assembly removed. your decorative door or front. E. Fixed Glass Assembly See Section 14.G. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 10: Lighting Instructions (Ipi)
For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 11: After Fireplace Is Lit
Some optional control systems available with IPI models may allow pilot fl ame to continually? remain lit. In a standing pilot system the pilot will always stay on. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 12: Maintenance And Service
• Carefully set fi xed glass assembly in place on fi replace. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 13: Maintenance Tasks-Qualifi Ed Service Technician
• Remove all foreign objects. • Verify unobstructed air circulation. Burner Ignition and Operation Frequency: Annually Figure 3.1 IPI Pilot Flame Patterns Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 14: Installer Guide
(SECTION 8B) CEILING FIRESTOP ON FLOOR OF ATTIC (SECTION 8B) OPTIONAL WALL SWITCH GAS LINE (SECTION 11) HEARTH EXTENSION SURROUND MANTEL AND MANTEL LEG (SECTION 5.D) Figure 4.1 Typical System Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 15: Design And Installation Considerations
DO NOT use this appliance if any part has been under water. Call a qualifi ed technician to inspect the appliance and to replace any part of the control system and/or gas control which has been under water. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 16: Negative Pressure
Recommended Recommended Location Location Marginal Location Location Recommended Location NOT Recommended Windward Leeward Multi-level Roofs Figure 4.2 Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 17: Framing And Clearances
MINIMUM CLEARANCE 36 in. 914 mm MINIMUM CLEARANCE 36 in. 914 mm Figure 5.1 Appliance Locations Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 18: Constructing The Appliance Chase
(Height) (Depth) (Width) Inches 38-1/8 31-5/8 Millimeters 1092 * Adjust framing dimensions for interior sheathing (such as sheetrock). ** See pipe manufacturer’s installation instructions. Figure 5.2 Clearances to Combustibles Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 19: Mantel And Wall Projections
Non-Combustible Mantel Projection TO CEILING MAX. MIN. AIR SPACE REQUIRED Figure 5.6 Non-Combustible Zone MEASUREMENTS FROM TOP EDGE OF THE OPENING Figure 5.4 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 20: Termination Locations
Over 16/12 to 18/12 ..........7.0 Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 21: Vent Information And Diagrams
fi re. 45 DEGREES OFFSETS EXCEEDING ELBOW 45 DEGREES ADAPT HORIZONTAL LIMITATIONS 90 DEGREES ELBOW Note: Maximum horizontal distance is 50% vertical vent height. Figure 7.3 Proper Use of Elbows Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 22: Vent Clearances And Framing
2 in. (51 mm) above insulation. Attic shields must meet specifi ed clearance and be se- cured in place. Use B-vent manufacturer’s fi restops to provide adequate clearances. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 23: Appliance Preparation
(see Figure 9.2). • Insert narrow end of handle through tab and into upper slot of door. • Check handle operation. Pull handle out to open, and in to close. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 24: Securing And Leveling The Appliance
It is acceptable to use plumber strap to secure the unit to the framing if necessary. Figure 9.4 Proper Positioning, Leveling And Securing of an Appliance Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 25: Installing Vent Pipe
• Connect vent sections per vent manufacturer’s installation instructions. • Maintain all clearances to combustibles. Maintain specifi ed slope (if required). • Improper support may allow vent to sag or separate. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 26: Gas Information
fl exible gas connector are connected to the 1/2 in. (13 mm) control valve inlet. • If substituting for these components, please consult local codes for compliance. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 27: Electrical Information
Verify proper operation after servicing. WARNING! Risk of Shock! Replace damaged wire with type 105° C rated wire. Wire must have high temperature insulation. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 28 MODULE 3 VAC ORANGE TRANSFORMER 3V WHITE GROUND TO FIREPLACE CHASSIS PLUG-IN BLACK BATTERY PACK BLACK TEMP SENSOR VALVE WIRE ASSEMBLY Figure 12.1 Intellifi re Ignition Wiring Diagram with Wall Switch Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
- Page 29 TRANSFORMER 3V WHITE GROUND TO FIREPLACE CHASSIS PLUG-IN BLACK BATTERY PACK PLUG IN BLACK TEMP SENSOR VALVE REMOTE RECEIVER Figure 12.2 Intellifi re Ignition Wiring Diagram with Remote Receiver Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 30: Junction Box Installation
Ensure that a Romex connector is NOTICE: DO NOT wire 110-120 VAC to wall switch. used to attach the electrical wires to the junction box. Figure 12.3 Junction Box Detail Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 31: Finishing
Figure 13.2 Step 3. Crease fl aps on left and right sides of splatter guard using the scored line as the guide. See Figure 13.3. Figure 13.5 Top slot Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 32 Carefully grab splatter guard on or near the vertical center on the left and right sides. Pull outward gently, but fi rmly, Figure 13.8 Opening Lower Access Panel taking care not to tear or remove the inserted tabs. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 33: Mantel And Wall Projections
0 in. Figure 13.13 Minimum Vertical and Maximum Horizontal Dimensions of Non-Combustibles High Temperature Sealant (300° F/149° C min.) Top and Side Seal Joint Figure 13.15 Noncombustible Facing Diagram Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 34: Doors
Finishing material between 1 and 2 inches thick. Finishing materials 1 inch maximum thick. Stop fi nishing material fl ush with appliance opening. Figure 13.19 Operable hinge door Figure 13.17 Overlap Fit Door Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 35: Elevated Hearth Systems
Note 1. Add dimensions to Rough Opening Height (Figure 5.2). Note 2. Verify Marble Cut Lengths on site prior to cutting. Note 3. Dimensions assume use of a 3/4 in. Hearth Pad. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 36: Appliance Setup
The embers provided should be enough for 3 to 5 applications. DO NOT PLACE EMBERS IN THE CIRCLED AREAS PILOT LOCATED HERE Figure 14.1 Placement of Embers Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 37: Install The Log Assembly
Mate the notch on the end of log # 1 with the hump on top of log A. Set the other end of Log #1 onto the smooth area on top of Log C. 2128-935 Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 38 The bottom end of log #3 should come in contact with the far left grate tine. Mate the bottom of log # 3 with the indentations on Log D and the top of Log #2. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 39: Fixed Glass Assembly
• Make sure all sides are replaced properly. AIR SHUTTER OPEN CLOSED LATCHES (BOTH BOTTOM AND TOP) GLASS ASSEMBLY Figure 14.2 Fixed Glass Assembly Figure 14.3 Air Shutter Air Shutter Settings Burner 1/8 in. Fully open Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... -
Page 40: Troubleshooting
Verify module is securely grounded to metal chassis of appliance. d. Module voltage output / Valve/Pilot Verify battery voltage is at least 2.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 2.7. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 41 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
-
Page 42: 16 Reference Materials
FRONT VIEW RIGHT SIDE LEFT SIDE Appliance Dimensions Table Location Inches Millimeters Location Inches Millimeters 4-1/4 42-1/2 1080 24-1/8 33-1/2 21-5/16 34-5/8 2-1/8 4-1/8 1-1/2 Figure 16.1 Appliance Dimensions Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13... - Page 43 5890485, 5941237, 6006743, 6019099, 6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7098269, 7258116, 7470729, 8147240 or other U.S. and foreign patents pending. 2000-945B Printed in U.S.A. - Copyright 2013 Heat & Glo • ST-36TVB-IPI • 2134-900 Rev. i • 3/13...
