Digital Equipment STARION 200i Service Maintenance Manual

Pc family
Table of Contents

Advertisement

Quick Links

STARION 200i/300i
Copyright Digital Equipment Corporation
All rights reserved
Service
Maintenance
Manual
PC Family
EK-A0851-SV. A01
S
T
A
R
I
O
N
2
0
0
i
3
0
0
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STARION 200i and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Equipment STARION 200i

  • Page 1 Service Maintenance Manual STARION 200i/300i PC Family EK-A0851-SV. A01 Copyright Digital Equipment Corporation All rights reserved...
  • Page 2 No responsibility is assumed for the use or reliability of software or equipment that is not supplied by Digital Equipment Corporation or its affiliated companies. Restricted Rights: Use, duplication, or disclosure by the U.S. Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013.
  • Page 3: Table Of Contents

    Digital STARION 200i/300i PC Table of Contents Table of Contents REVISION HISTORY ..........................7 PREFACE ..............................9 CHAPTER 1 PRODUCT DESCRIPTION.................... 11 ..........................11 RODUCT NTRODUCTION ........................ 13 RODUCT ODELS NFORMATION CHAPTER 2 SYSTEM UTILITIES& CONFIGURATION..............15 ............................15 YSTEM TILITIES Before Using System Utilities and Video Drivers...................
  • Page 4 Table of Contents Digital STARION 200i/300i PC Recommended Virus Detection and Cleanup Software ................38 MCS Logistics Engineering - Nijmegen...
  • Page 5 Digital STARION 200i/300i PC Table of Contents ECO/FCO I ..........................39 NFORMATION BIOS version information........................39 ....................39 NLOCKING AND EMOVING THE OVER ..........................41 OMPUTER OMPONENTS ............................42 XPANSION LOTS ........................44 OGIC OARD UMPERS Main Logic Board Jumper Settings ......................44 Main Logic Board Jumper Locations......................
  • Page 6 Table of Contents Digital STARION 200i/300i PC APPENDIX A SERVICES NOTES ......................85 Modem Settings ............................85 Telecommunications Software Settings ....................85 Sound Card Settings..........................86 Disabling Fax/Modem/Sound Board Features ..................86 APPENDIX B USEFUL INFORMATION ....................87 ..........................87 ELATED DOCUMENTATION ........................87 ULLETIN OARDS DOCUMENT FEEDBACK........................89 PERSONAL NOTES ..........................91...
  • Page 7: Revision History

    Digital STARION 200i/300i PC Revision History Revision History Revision of Date Description of change EK-A0851-SV First release of the Service Manintenance Manual describing the STARION 200i/300i series computer. MCS Logistics Engineering - Nijmegen...
  • Page 9: Preface

    Preface Preface The Digital STARION 200i/300i PC Family Service Maintenance Manual is a troubleshooting guide that can be used for reference when servicing the STARION 200i/300i line of PC’s. Digital Equipment Corporation reserves the right to make changes to the Digital STARION 200i/300i series without notice.
  • Page 11: Chapter 1 Product Description

    Chapter 1 Product Description Product Introduction The Digital STARION 200i/300i computers are high-performance, multi-media, personal computers featuring the latest in computing technology. They can be used as stand-alone computers, as clients, or as servers in a network environment. Developed using the following state-of-the-art technology, these computers are the most value packed full-profile desktop computers in their class.
  • Page 12 Product Description Digital STARION 200i/300i PC ◊ Support Sound Blaster™ and Sound Blaster Pro™ sound standards MCS Logistics Engineering - Nijmegen...
  • Page 13: Product Models Information

    Digital STARION 200i/300i PC Product Description Product Models Information STARION 200i/300i Models Product Model Memory Cache CD-ROM STARION 200i FR-901AA-A4 8MB 540MB None Dual-Speed STARION 300i FR-901AA-A5 8MB 840MB None Dual-Speed MCS Logistics Engineering - Nijmegen...
  • Page 15: Chapter 2 System Utilities& Configuration

    System Utilities& Configuration System Utilities This chapter describes how to use the utilities and video drivers supplied with the STARION 200i/300i computer. These utilities and drivers have been factory installed on the hard disk drive. You may use the video utilities to change video graphics settings of the monitor.
  • Page 16: Phlash .Exe

    ♦ A diskette copy of the BIOS upgrade diskette NOTE PHLASH utilities are not shipped with STARION 200i/300i computers. However, they are available on the Digital Bulletin Board System. Creating a Crisis Recovery Diskette Turn on the computer and allow the POST to complete.
  • Page 17 Digital STARION 200i/300i PC Utilities & Configuration Insert a blank formatted diskette into drive A. MCS Logistics Engineering - Nijmegen...
  • Page 18: Using A Crisis Recovery Diskette

    Utilities & Configuration Digital STARION 200i/300i PC On drive A, make a directory for the files previously copied. For example, from the DOS prompt enter: A:MD UPGRADE. Return to the hard disk drive and copy the files. From the DOS prompt, enter: C:MAKECRD.
  • Page 19 Digital STARION 200i/300i PC Utilities & Configuration If POST detects an error, refer to Chapter 4, “Troubleshooting” to identify and determine how to correct the problem. After the problem has been resolved, restart the computer. MCS Logistics Engineering - Nijmegen...
  • Page 20: Ultilities And Video Drivers

    Utilities & Configuration Digital STARION 200i/300i PC At the MS-DOS prompt, type: A:\UPGRADE\PHLASH. A screen appears on the monitor warning that the computer's BIOS is about to be erased. Press [Enter] to continue. Press [Esc] to cancel. If [Enter] is pressed, PHLASH.EXE automatically updates the computer's BIOS.
  • Page 21: Windows Video Drivers

    Digital STARION 200i/300i PC Utilities & Configuration Windows Video Drivers The computer comes with the required Windows video display driver pre-installed at the factory. However, if the hard disk drive becomes corrupted, you might need to re-load the Windows video driver that has been provided on the Windows video driver diskette that is made using "Program Disks"...
  • Page 22: Using The S3Refrsh Utility

    Utilities & Configuration Digital STARION 200i/300i PC Using the S3refrsh Utility S3refrsh.EXE is an MS-DOS-based utility that works in conjunction with Galileo to set the video controller monitor resolution and refresh rates. This utility has been pre-installed and configured at the factory to meet most monitor resolution needs.
  • Page 23: Running The Bios Setup Ultility

    Digital STARION 200i/300i PC Utilities & Configuration Running the BIOS setup Ultility The BIOS Setup utility enables to select and permanently store information about the computer's hardware and software in the battery-backed memory of the CMOS RAM. This information takes effect each time the computer boots and can be changed each time setup is runned.
  • Page 24: Bios Setup Utility Options

    Utilities & Configuration Digital STARION 200i/300i PC BIOS Setup Utility Options The following topics list the BIOS options that can be updated or modified by using the BIOS Setup utility, according to the various sub-menus under which they appear. NOTE In some cases, options might be listed in a different order than they actually appear in the sub-menus.
  • Page 25 Digital STARION 200i/300i PC Utilities & Configuration Write 0 to 4095 Displays the number of cylinders that have their write timing precomp None changed. MCS Logistics Engineering - Nijmegen...
  • Page 26: Memory And Cache

    Comments Internal cache Enabled Enables or disables the computer's internal cache. Disabled External Enabled External cache is not present or upgradeable on STARION 200i/300i cache Disabled systems. System BIOS Not user The main logic board reserves an area of DRAM, called "shadow selectable, memory"...
  • Page 27 Digital STARION 200i/300i PC Utilities & Configuration Video BIOS Enabled The main logic board reserves an area of DRAM, called "shadow shadow Disabled Memory", for a copy of video BIOS ROM. This DRAM is write- protected and has the same addresses as the video BIOS ROM locations.
  • Page 28: Boot Options

    Utilities & Configuration Digital STARION 200i/300i PC Memory and Cache (continued) Menu Fields Settings Comments Cache video Enabled This option enables the video BIOS to be cached in the internal cache BIOS Disabled and external cache (if installed). This increases computer performance because video BIOS instructions can be executed in cache instead of RAM.
  • Page 29 Digital STARION 200i/300i PC Utilities & Configuration Summary Enabled Enabling this option causes the computer to display configuration screen Disabled parameters (in the form of a summary screen) during boot. MCS Logistics Engineering - Nijmegen...
  • Page 30: Keyboard Features

    Utilities & Configuration Digital STARION 200i/300i PC Keyboard Features Menu Fields Settings Comments Numlock Auto Turns Numlock on or off each time the computer boots. Key click Disabled Enables or disables the audible key click feature. Enabled Keyboard 2/sec Sets the number of times a second to repeat a keystroke while the key is held down.
  • Page 31: Advanced Chipset Control

    Digital STARION 200i/300i PC Utilities & Configuration Integrated Peripherals (continued) Menu Fields Settings Comments Serial port 1 Auto Enables or disables onboard serial port 1 at the specified address. Disabled Select Auto unless interrupts IRQ4 and/or IRQ3 are allocated as a 3F8, IRQ 4 computer resource.
  • Page 32 Utilities & Configuration Digital STARION 200i/300i PC VGA feature Enabled connector Disabled MCS Logistics Engineering - Nijmegen...
  • Page 33: Security Options

    Digital STARION 200i/300i PC Utilities & Configuration Advanced Chipset Control (continued) Menu Fields Settings Comments Monitor type Auto Set to Color or Mono if auto-detection fails. Mono Color Auto Onboard VGA Enabled Disabled Security Options Menu Fields Settings Comments Not user...
  • Page 34: Power Options

    Utilities & Configuration Digital STARION 200i/300i PC Security Options (continued) Menu Fields Settings Comments Diskette access Supervisor Controls who has access to diskette drives. If Supervisor is User selected, access to the diskette drive is limited to the supervisor, who must enter his or her password.
  • Page 35 Digital STARION 200i/300i PC Utilities & Configuration System Disabled After a set period of computer inactivity, the BIOS places the suspend timer 1 hour computer in a suspend state (maximum power savings), that is, the 1.5 hours Energy Star-compatible monitor, hard disk, CPU and fan are shut off.
  • Page 36 Utilities & Configuration Digital STARION 200i/300i PC Power Options (continued) Menu Fields Settings Comments Suspend Lock When enabled, the system locks the keyboard and the mouse until the system power-on password is entered. Quick suspend Disabled Selects the key combination used to put the system in suspend mode.
  • Page 37: Chapter 3 Service Procedures

    Digital STARION 200i/300i PC Service Procedures Chapter 3 Service Procedures Safety Requirements WARNING Static electricity collects on non-conductors such as paper, cloth, or plastic. A static discharge can be damaging even though you often cannot see or feel it. The following safety precautions must be observed to insure product and personal safety and prevent damage to circuit boards and/or components: ♦...
  • Page 38: Recommended Tools

    Service Procedures Digital STARION 200i/300i PC Recommended Tools The following tools are needed for servicing Digital PC systems. Note that test equipment must be in calibration. ♦ Multimeter (4 1/2 digit) ♦ A philips screwdriver ♦ An antistatic wrist strap Other Materials Needed Cleaning agent should be an all purpose cleaner that is used in-house.
  • Page 39: Eco/Fco Information

    Digital STARION 200i/300i PC Service Procedures ECO/FCO Information BIOS version information Refer to the Digital DECpc Bulletin Board Support (telephone number: 1- 508- 496- 8800) for the latest information on BIOS upgrades. NOTE This BBS is NOT a source for technical support. For advice, please call the Digital Equipment Service Representative: 1-800-354-9000.
  • Page 40: Figure 3 - 1 Unlocking The Cover

    Service Procedures Digital STARION 200i/300i PC Unlocking and Removing the Cover (continued) DEC00529-2 Figure 3 - 1 Unlocking the Cover DEC00530-2 Figure 3 - 2 Release Cover Figure 3 - 3 Removing the Cover DEC00531-2 MCS Logistics Engineering - Nijmegen...
  • Page 41: Computer Components

    Digital STARION 200i/300i PC Service Procedures Computer Components Legend Description Power supply Main logic board 3½-inch diskette drive CD-ROM drive Front internal drive bay Riser card; supports up to three expansion boards: 2 PCI and 1 ISA or 2 ISA and 1 PCI...
  • Page 42: Expansion Slots

    Service Procedures Digital STARION 200i/300i PC Expansion Slots The STARION 200i/300i Desktop PC riser card contains four slots for installing: ♦ Two ISA expansion boards and one PCI expansion board or ♦ One ISA expansion board and two PCI expansion boards The computer's ISA expansion slots support industry-standard full-length 16-bit expansion boards.
  • Page 43: Figure 3 - 5 Expansion Slots

    Digital STARION 200i/300i PC Service Procedures Figure 3 - 5 Expansion Slots MCS Logistics Engineering - Nijmegen...
  • Page 44: Main Logic Board Jumpers

    Service Procedures Digital STARION 200i/300i PC Main Logic Board Jumpers Jumper pins allow to set specific computer parameters. They are set by changing the pin location of jumper blocks. Note that the square pin of each jumper block is pin 1. A jumper block is a small plastic-encased conductor (shorting plug) that slips over the pins.
  • Page 45: Main Logic Board Jumper Locations

    Digital STARION 200i/300i PC Service Procedures Main Logic Board Jumper Locations Figure 3 - 6 Main Logic Board Jumper Locations MCS Logistics Engineering - Nijmegen...
  • Page 46: Computer Memory Configurations

    Service Procedures Digital STARION 200i/300i PC Computer Memory Configurations Adding more memory allows the computer to run larger, more complicated software and to run it faster. The computer comes with 8 MB of memory hardwired to the main logic board. Additional memory can be installed, to a maximum of 128 MB, using the two SIMM sockets on the main logic board.
  • Page 47: Figure 3 - 7 Simm Socket Locations

    Digital STARION 200i/300i PC Service Procedures Figure 3 - 7 SIMM Socket Locations MCS Logistics Engineering - Nijmegen...
  • Page 48: Part Removal And Replacement

    Service Procedures Digital STARION 200i/300i PC Part Removal and Replacement Opening the Device Bay & Power Supply Subassembly The device bay & power supply subassembly has to be opened in order to install, removeand/or connect certain components and peripheral devices.
  • Page 49: Figure 3 - 9 Opening The Device Bay & Power Supply Subassembly

    Digital STARION 200i/300i PC Service Procedures Figure 3 - 9 Opening the Device Bay & Power Supply Subassembly MCS Logistics Engineering - Nijmegen...
  • Page 50: Removing The 3½-Inch Diskette Drive

    Service Procedures Digital STARION 200i/300i PC Removing the 3½-Inch Diskette Drive To remove the 3½-inch diskette drive: Turn off the computer. Disconnect external devices, ac power and monitor power. Unlock and remove cover. Remove two screws securing the right side of diskette drive to chassis.
  • Page 51: Removing The Main Logic Board

    Digital STARION 200i/300i PC Service Procedures Removing the Main Logic Board To remove the main logic board: Turn off the computer. Disconnect external devices, ac power and monitor power. Unlock and remove cover. Remove all connectors. Remove all expansion boards.
  • Page 52: Removing The Power Supply

    Service Procedures Digital STARION 200i/300i PC Removing the Power Supply To remove the power supply: Perform the steps necessary to open the device bay and power supply subassembly. Remove power supply, IDEand diskette cabling from main logic board noting their proper orientation.
  • Page 53: Removing The Riser Card & Bracket

    Digital STARION 200i/300i PC Service Procedures Removing the Riser Card & Bracket To remove the riser card and bracket: Turn off the computer. Disconnect external devices, ac powerand monitor power. Unlock and remove cover. Remove all expansion boards. Carefully lift riser card and bracket from computer.
  • Page 54: Removing Expansion Boards

    Service Procedures Digital STARION 200i/300i PC Removing Expansion Boards To remove an expansion board: Turn off the computer. Disconnect external devices, ac power and monitor power. Unlock and remove cover. Remove screw from metal filler plate. Gently pull board outward.
  • Page 55: Removing A 3½-Inch Mass Storage Device (Internal Drive Bay)

    Digital STARION 200i/300i PC Service Procedures Removing a 3½-Inch Mass Storage Device (Internal Drive Bay) The following procedures describe how to remove a 3½-inch mass storage device into the Slimline internal device bay: Open the device bay and power supply subassembly.
  • Page 56: Installation Procedures

    Installation Procedures Installing a Higher Performance CPU. The STARION 200i/300i main logic board is equipped with a Pentium processor installed in a ZIF socket. To install a higher performance CPU: Turn off the computer, is connect external devices, ac power and monitor power.
  • Page 57: Figure 3 - 16 Installing A Higher Performance Cpu

    Digital STARION 200i/300i PC Service Procedures Figure 3 - 16 Installing a Higher Performance CPU MCS Logistics Engineering - Nijmegen...
  • Page 58: Installing The Cpu Voltage Regulator

    Service Procedures Digital STARION 200i/300i PC Installing the CPU Voltage Regulator The STARION Desktop PC computer's CPU requires a separate voltage regulator in order to operate correctly. If a new CPU is installed, a new voltage regulator might also be required. If this is the case, the new voltage regulator will be included in the CPU upgrade kit.
  • Page 59: Replacement Procedures

    Digital STARION 200i/300i PC Service Procedures Replacement Procedures Replacing the Real-Time Clock (RTC) The STARION Desktop PC computer RTC integrates a battery with the computer clock and retains any setup information when it is turned off. If the computer ever fails to retain the correct date, time, or configuration settings when it is turned on, the computer’s RTC must be replaced.
  • Page 60: Figure 3 - 18 Replacing The Real Time Clock

    Service Procedures Digital STARION 200i/300i PC Figure 3 - 18 Replacing the Real Time Clock MCS Logistics Engineering - Nijmegen...
  • Page 61: Connecting Diskette And Ide Devices

    Digital STARION 200i/300i PC Service Procedures Connecting Diskette and IDE Devices To connect diskette drives, perform the following: Open the device bay and power supply subassembly. Connect supplied ribbon cable to appropriate device. NOTE If only one IDE device is installed, make sure to use the ribbon cable connector furthest from the main logic board connector.
  • Page 62: Connecting Diskette Drives

    Service Procedures Digital STARION 200i/300i PC Connecting Diskette Drives Legend Diskette Drive Component Power supply Power connections Diskette drive connections Main logic board diskette drive connection Diskette drives Figure 3 - 19 Diskette Drive Data Cable Connections MCS Logistics Engineering - Nijmegen...
  • Page 63: Connecting Ide Devices

    Digital STARION 200i/300i PC Service Procedures Connecting IDE Devices Legend IDE Device Component Power supply Power connections IDE hard disk drive connections Main logic board IDE drive connections IDE hard disk drive IDE CD-ROM drive Figure 3 - 20 IDE Drive Data Cable Connections...
  • Page 65: Chapter 4 Troubleshooting

    Refer to the documentation supplied with additional options when experiencing problems with specific installed options. Initial Troubleshooting Follow these general procedures to troubleshoot the STARION 200i/300i computers: ♦ Press [Ctrl] + [Alt] + [Del]. If the computer fails to boot, turn it off, wait until all hard disk drives spin down completelyand then turn it back on.
  • Page 66: Beep Codes

    Troubleshooting Digital STARION 200i/300i PC Beep Codes When POST finds an error and cannot display a message, the computer's speaker emits a series of beeps to indicate the error. For example, video failure or configuration error is indicated by a 1 - 2 beep code (a burst of three beeps , one long beep followed by two short beeps).
  • Page 67: Post And Boot Messages

    Digital STARION 200i/300i PC Troubleshooting POST and Boot Messages The POST displays messages to alert to errors in hardware, softwareand firmware or to provide operating information about the computer. Each time the POST displays a message on the screen, the computer's speaker beeps twice. If an error occurs before the monitor is initialized, specific beep codes sound to alert to a problem.
  • Page 68 Troubleshooting Digital STARION 200i/300i PC Keyboard Keyboard and/or keyboard Check the keyboard connection. If the connection controller error controller failed. is secure, the keyboard or keyboard controller Keyboard error might have failed. If the problem persists, replace Keyboard the defective keyboard and/or controller.
  • Page 69 Digital STARION 200i/300i PC Troubleshooting POST and Boot Error Messages (continued) Message Problem Solution Monitor type Monitor type has been Run the BIOS Setup utility and set the correct does not match incorrectly specified. monitor type. CMOS - Run SETUP...
  • Page 70: Post And Boot Informational Messages

    Troubleshooting Digital STARION 200i/300i PC POST and Boot Informational Messages Message Description nnnn Cache SRAM Passed Where nnnn is the amount of computer cache (in kilobytes) that tested successfully. Entering SETUP BIOS Setup utility runs. Extended RAM Passed Where nnnn is the amount of extended memory (in kilobytes) that tested successfully.
  • Page 71 Digital STARION 200i/300i PC Troubleshooting Computer Troubleshooting (continued) Problem Possible Cause Action Computer Expansion board installed Remove expansion board and reinstall. operates incorrectly. incorrectly after installing Did not run ICU to configure Run the ICU to properly configure expansion optional expansion board before board and then reboot the computer.
  • Page 72 Troubleshooting Digital STARION 200i/300i PC Computer Troubleshooting (continued) Problem Possible Cause Action Computer does Operating system software is not Install the appropriate operating system. not boot from installed on the IDE hard disk drive. an IDE hard disk drive IDE hard disk drive is not...
  • Page 73 Digital STARION 200i/300i PC Troubleshooting Computer does SCSI device jumpers incorrectly Refer to the supplied SCSI device kit installation not recognize an set. instructions. internal or external SCSI SCSI cable not terminated. Terminate each end of the SCSI bus. device SCSI device not plugged in.
  • Page 74 Troubleshooting Digital STARION 200i/300i PC Computer Troubleshooting (continued) Problem Possible Cause Action Computer does Operating system software is not Install the appropriate operating system on the not boot from installed on the SCSI hard disk SCSI hard disk drive. drive.
  • Page 75: Isk Drive

    Digital STARION 200i/300i PC Troubleshooting Disk Drive Troubleshooting Problem Possible Cause Action IDE/SCSI hard Incorrect disk drive jumper Refer to the supplied kit installation instructions. disk drive settings. cannot read or Loose or incorrectly installed Make sure all cables are correctly installed.
  • Page 76: Cd-Rom Troubleshooting

    Troubleshooting Digital STARION 200i/300i PC Monitor Troubleshooting (continued) Problem Possible Cause Action Distorted,- Monitor incorrectly adjusted. Adjust accordingly. rolling/or Monitor signal cable incorrectly Straighten any bent connector pins and then flickering screen display- installed. reconnect. wrong/uneven color Computer was turned on before...
  • Page 77: Qap Lus /Fe Error Messages

    Digital STARION 200i/300i PC Troubleshooting QAPlus/FE Error Messages Component Messages Solution Arithmetic Function Failed Reset CPU General Functions Failed Replace CPU Exception Interrupt in Protected Mode Refresh Failure Logic Functions Failed Butterfly Cylinder Access Test Failed Low-level format hard disk...
  • Page 79: Chapter 5 Device Mapping

    Digital STARION 200i/300i PC Device Mapping Chapter 5 Device Mapping This section provides a series of tables listing mapping and address information related to computer memory and various main logic board devices (keyboard controller, interrupt controller, DMA controller, etc.). The computer's memory and address locations are allocated at the factory to operate within a standard PC environment.
  • Page 80: I/O Address Map

    Device Mapping Digital STARION 200i/300i PC I/O Address Map Range (hexadecimal) Function 000 - 00F DMA controller one 020 - 021 Interrupt controller one 040 - 043 Interval timer 060 - 06F Keyboard controller 070 - 07F Real-time clock (RTC), NMI...
  • Page 81: Computer Interrupt Levels

    Digital STARION 200i/300i PC Device Mapping Computer Interrupt Levels Interrupt Number Interrupt Source IRQ0 Timer tick IRQ1 Keyboard controller IRQ2 Cascade interrupt IRQ3 Modem IRQ4 COM1 IRQ5 LPT2 IRQ6 Diskette drive (if enabled) IRQ7 LPT1, LPT3 (if enabled) IRQ8 Real Time Clock (RTC)
  • Page 83: Chapter 6 Pass / Fail Criteria

    Digital STARION 200i/300i PC Pass / Fail Criteria Chapter 6 Pass / Fail criteria As Final Acceptance Test the following tests should be run to meet the Pass/Fail criteria: Successful Completion of the POST tests. Successful Completion of the following QAPLUS/fe module tests (one pass): ♦...
  • Page 85: Appendix A Services Notes

    Service Notes Appendix A Services Notes This appendix contains the current Service Notes for the STARION 200i/300i product line. Modem Settings The modem must be configured to operate using a specific serial (COM) port and interrupt request line (IRQ). This is done using the board's JB2 jumper block, containing jumpers J1 through J10.
  • Page 86: Sound Card Settings

    Service Notes Digital STARION 200i/300i PC Sound Card Settings Sound card settings are defined using the board's JB1 jumper block, containing jumpers J1 through J14. Factory-default settings are given in Bold Italics. I/O Address IRQ Setting DMA Channel Jumpers Jumpers...
  • Page 87: Appendix B Useful Information

    Digital STARION 200i/300i PC Useful Information Appendix B Useful Information Related documentation Document Titles Order’s STARION 200i/300i Quick Reference Guide EK-A0856-RG STARION Desktop PC Quick Setup Guide ER-901A2-IA STARION Desktop PC Quick Setup Guide ER-901A2-UA ISA Configuration Utility (ICU) User's Guide...
  • Page 89: Document Feedback

    Digital STARION 200i/300i PC Document Feedback Document Feedback If you have comments on the contents or layout of this document we highly appreciate your feedback. We will do our best to make this document a valuable support to your service efforts for Digital.
  • Page 91: Personal Notes

    Personal Notes...
  • Page 92 Personal Notes...
  • Page 93 Personal Notes...
  • Page 94 Personal Notes...
  • Page 95: Readers Comments

    READERS COMMENTS Digital STARION 200i/300i Service Maintenance Manual EK-A0851-SV Rev A01 This form is for documents only. Commitments submitted on this form are used at Digital’s direction. Did you find errors in this manual? If so, specify by page..................................
  • Page 96 ....................................Name ................................Title ................................Company ..............Dept ................ Address ................................. City ..............State ................ Country .................................
