Kubota L3540 Workshop Manual page 72

L3540, L4240, L5040, L5240, L5740, WSM
Engine Hook 1
Application: Use to fix the engine when hooking, instead of the original hook with hook 2 as a set.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
C10
R9
R10
G-50
G GENERAL
17 mm (0.67 in.)
9 mm (0.35 in.)
129 mm (5.08 in.)
10.8 to 11.2 mm (0.426 to 0.440 in.)
40 mm (1.6 in.)
20 mm (0.79 in.)
39 mm (1.5 in.)
20 mm Hole (0.79 in. Hole)
8.50 to 8.80 mm Drilled hole
(0.335 to 0.346 in. Drilled hole)
20 mm Spot-faced hole 1 mm deep
(0.79 in. Spot-faced hole 0.04 in.
deep)
20 mm (0.79 in.)
140 mm (5.51 in.)
15 mm (0.59 in.)
175 mm (6.89 in.)
Chamfer 10 mm (0.39 in.)
Radius 9.0 mm (0.35 in.)
Radius 10 mm (0.39 in.)
W1018612
KiSC issued 04, 2010 A
