Page 1 WORKSHOP MANUAL TRACTOR L3200 KiSC issued 12, 2006 A...
Page 2 TO THE READER This Workshop Manual has been prepared to provide servicing personnel with information on the mechanism, service and maintenance of KUBOTA Tractor L3200. It is divided into three parts, “General”, “Mechanism” and “Servicing” for each section. General Information on the tractor identification, the general precautions, maintenance check list, check and maintenance and special tools are described.
Page 3 L3200, WSM SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS SAFETY FIRST This symbol, the industry’s “Safety Alert Symbol”, is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to repair or use this unit.
Page 4 L3200, WSM SAFETY INSTRUCTIONS SAFETY STARTING • Do not start the engine by shorting across starter terminals or bypassing the safety start switch. • Do not alter or remove any part of machine safety system. • Before starting the engine, make sure that all shift levers are in neutral positions or in disengaged positions.
Page 5 L3200, WSM SAFETY INSTRUCTIONS VENTILATE WORK AREA • If the engine must be running to do some work, make sure the area is well ventilated. Never run the engine in a closed area. The exhaust gas contains poisonous carbon monoxide.
Page 6: Safety Decals
L3200, WSM SAFETY INSTRUCTIONS SAFETY DECALS The following safety decals are installed on the machine. If a decal becomes damaged, illegible or is not on the machine, replace it. The decal part number is listed in the parts list. KiSC issued 12, 2006 A...
Page 7 L3200, WSM SAFETY INSTRUCTIONS KiSC issued 12, 2006 A...
Page 8 L3200, WSM SAFETY INSTRUCTIONS KiSC issued 12, 2006 A...
Page 9 L3200, WSM SAFETY INSTRUCTIONS KiSC issued 12, 2006 A...
Page 10 L3200, WSM SAFETY INSTRUCTIONS KiSC issued 12, 2006 A...
Page 11 L3200, WSM SAFETY INSTRUCTIONS KiSC issued 12, 2006 A...
Page 12: Specifications
L3200, WSM SPECIFICATIONS SPECIFICATIONS Model L3200 Rear Mount Type ROPS Mid Mount Type ROPS (For France, Germany, United (For Spain, Portugal, Italy, Greece) Kingdom) PTO power 21.3 kW (28.6 HP) Maker KUBOTA Model D1703-MA-E2A Type Vertical, water-cooled, 4-cycle diesel Number of cylinders 87 ×...
Page 13 L3200, WSM DIMENSIONS DIMENSIONS KiSC issued 12, 2006 A...
Page 14 L3200, WSM DIMENSIONS KiSC issued 12, 2006 A...
Page 15 GENERAL KiSC issued 12, 2006 A...
Page 16: Table Of Contents
GENERAL CONTENTS 1. TRACTOR INDENTIFICATION............... G-1 2. GENERAL PRECAUTIONS ................G-2 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING .. G-3 [1] WIRING ..................... G-3 [2] BATTERY....................G-5 [3] FUSE......................G-5 [4] CONNECTOR .................... G-5 4. LUBRICANTS, FUEL AND COOLANT ............G-6 5.
Page 17: Tractor Indentification
L3200, WSM G GENERAL 1. TRACTOR INDENTIFICATION (1) Tractor Identification Plate (3) Engine Serial Number (2) Tractor Serial Number W1010590 KiSC issued 12, 2006 A...
Page 18: General Precautions
Screws, bolts and nuts should be installed in their original position to prevent reassembly errors. • When special tools are required, use KUBOTA genuine special tools. Special tools which are not frequently used should be made according to the drawings provided.
Page 19: Handling Precautions For Electrical Parts And Wiring
L3200, WSM G GENERAL 3. HANDLING PRECAUTIONS FOR ELECTRICAL PARTS AND WIRING To ensure safety and prevent damage to the machine and surrounding equipment, heed the following precautions in handling electrical parts and wiring. IMPORTANT • Check electrical wiring damage loosened connection every year.
Page 20 L3200, WSM G GENERAL • Securely clamp, being careful not to damage wiring. (1) Clamp (3) Clamp • Wind Clamp Spirally (4) Welding Dent (2) Wire Harness W10114580 • Clamp wiring so that there is no twist, unnecessary sag, or excessive tension, except for movable part, where sag be required.
Page 21: Battery
L3200, WSM G GENERAL [2] BATTERY • Take care not to confuse positive and negative terminal posts. • When removing battery cables, disconnect negative cable first. When installing battery cables, check for polarity and connect positive cable first. • Do not install any battery with capacity other than is specified (Ah).
Page 22: Lubricants, Fuel And Coolant
10W-40 27.5 L Transmission case 7.3 U.S.gals. KUBOTA UDT or SUPER UDT fluid* 6.1 Imp.gals. 4.5 L KUBOTA UDT or SUPER UDT fluid* or SAE80, Front axle case 4.8 U.S.qts. 90 gear oil 3.9 Imp.qts. Greasing Place No. of greasing points...
Page 23: Tightening Torques
L3200, WSM G GENERAL 5. TIGHTENING TORQUES [1] GENERAL USE SCREWS, BOLTS AND NUTS Screws, bolts, nuts and whose tightening torque are not specified in this Workshop Manual should be tightened according to the table below. Indication on top of...
Page 24: Maintenance
L3200, WSM G GENERAL 6. MAINTENANCE Period Indication on hour meter Refer After -ence since Item page every 1 Engine oil Change G-11 100Hr every 2 Engine oil filter Replace G-11 200Hr Hydraulic oil every Replace G-13 filter 200Hr Transmission...
Page 25 L3200, WSM G GENERAL Period Indication on hour meter Refer After -ence since Item page every 20 Toe-in Adjust G-25 200Hr Engine valve every Adjust 1-S11 clearance 800Hr every G-27, 22 Cooling system Flush 2 years every G-27, 23 Coolant...
Page 26: Check And Maintenance
L3200, WSM G GENERAL 7. CHECK AND MAINTENANCE CAUTION • Be sure to check and service the tractor on a flat place with engine shut off, the parking brake on and chock the wheels. [1] DAILY CHECK To prevent trouble from occurring, it is important to know the condition of the tractor. Check the following items before starting.
Page 27: Check Points Of Initial 50 Hours
Then, replenish the engine oil up to the prescribed level. IMPORTANT • To prevent serious damage to the engine, replacement element must be highly efficient. Use only a KUBOTA genuine filter. (1) Engine Oil Filter Cartridge W1026738 KiSC issued 12, 2006 A...
Page 28 3. Drain the transmission fluid. 4. After draining, screw in the drain plugs (1). 5. Fill with the new KUBOTA SUPPER UDT fluid up to the upper line of the gauge (2). 6. After running the engine for a few minutes, stop it and check the fluid level again, if low, add fluid prescribed level (A).
Page 29: Replacing Hydraulic Oil Filter
11.Make sure that the transmission fluid doesn’t leak through the seal of the filter. IMPORTANT • To prevent serious damage to the hydraulic system. Use only a genuine KUBOTA filter or its equivalents. (1) Drain Plug A : Oil level is acceptable within this (2) Oil Gauge range.
Page 30 5. Fill with the new oil up to the check plug (3) port. 6. After filling, reinstall the check plug (3) and filling port plug. IMPORTANT • Use KUBOTA SUPER UDT fluid or SAE 80, 90 gear oil. Refer to “LUBRICANTS, FUEL AND COOLANT”. (See page G-7.) 4.5 L...
Page 31: Clutch Pedal Free Travel
L3200, WSM G GENERAL Clutch Pedal Free Travel Adjustment 1 1. Stop the engine and remove the key. 2. Slightly depress the clutch pedal and measure free travel at top of pedal stroke. 3. If adjustment is needed, loosen the lock nut (1), and turn the turnbuckle (2) to adjust the clutch pedal free play within factory specification.
Page 32: Check Points Of Every 50 Hours
L3200, WSM G GENERAL [3] CHECK POINTS OF EVERY 50 HOURS Greasing 1. Apply a grease to the following position as figures. NOTE • Apply a small amount of multipurpose grease to the following points every 50 hours. If you operated the machine in extremely wet and muddy conditions, lubricate grease fittings more often.
Page 33 L3200, WSM G GENERAL Checking Engine Start System CAUTION • Do not allow anyone near the tractor while testing. • If the tractor does not pass the test do not operate the tractor. Preparation before testing 1. Place all control levers in the "NEUTRAL" position.
Page 34: Check Point Of Every 100 Hours
L3200, WSM G GENERAL [4] CHECK POINT OF EVERY 100 HOURS Changing Engine Oil 1. See page G-6. W1033621 Cleaning Air Cleaner Element 1. Remove the element (1). 2. Clean the element : • When dry dust adheres to the element, blow compressed air from the inside turning the element.
Page 35 L3200, WSM G GENERAL Cleaning Fuel Filter This job should not be done in the field, but in a clean place. 1. Loosen and remove the filter bowl, and rinse the inside with a suitable cleaning fluid. 2. Take out the element and dip it in the kerosene to rinse.
Page 36 L3200, WSM G GENERAL Checking Fuel Line CAUTION • Stop the engine when attempting the check and change prescribed below. • Remember to check the fuel line periodically. The fuel line is subject to wear and deterioration over time, fuel may leak out onto the running engine, causing a fire.
Page 37 L3200, WSM G GENERAL Parking Brake Cable CAUTION • Stop the engine and remove the key, then chock the wheel before checking brake pedals. 1. Check and adjust brake pedals as shown above. 2. Release parking brake lever (1). Confirm that there is the same free play in right and left parking brake links (2).
Page 38 L3200, WSM G GENERAL Checking Battery Condition CAUTION • Do not use or charge the refillable type battery if the fluid level is below the LOWER (lower limit level) mark. Otherwise, the battery component parts may prematurely deteriorate, which may shorten the battery's service life or cause an explosion.
Page 39 L3200, WSM G GENERAL Battery Charging CAUTION • When the battery is being activated, hydrogen and oxygen gases in the battery are extremely explosive. Keep open sparks and flames away from the battery at all times, especially when charging the battery.
Page 40: Check Points Of Every 200 Hours
L3200, WSM G GENERAL [5] CHECK POINTS OF EVERY 200 HOURS Replacing Engine Oil Filter Cartridge 1. See page G-11. W1037936 Checking Radiator Hose and Hose Clamp Check to see if radiator hoses are properly fixed every 200 hours of operation or six months, whichever comes first.
Page 41 L3200, WSM G GENERAL Adjusting Toe-in 1. Park the tractor on the flat place. 2. Inflate the tires to the specified pressure. 3. Turn steering wheel so front wheels are in the straight ahead position. 4. Lower the implement, lock the parking brake and stop the engine.
Page 42: Check Points Of Every 400 Hours
L3200, WSM G GENERAL [6] CHECK POINTS OF EVERY 400 HOURS Changing Transmission Fluid 1. See page G-12. W1039932 Replacing Fuel Filter Element 1. See page G-19. W1039982 Changing Front Axle Case Oil 1. See page G-14. W1040022 [7] CHECK POINTS OF EVERY 600 HOURS Adjusting Front Axle Pivot 1.
Page 43: Check Points Of Every 2 Years
L3200, WSM G GENERAL [10] CHECK POINTS OF EVERY 2 YEARS Flush Cooling System and Changing Coolant CAUTION • Do not remove the radiator cap when the engine is hot. Then loosen cap slightly to the stop to relieve any excess pressure before removing cap completely.
Page 44 L3200, WSM G GENERAL NOTE • The above data represent industry standards that necessitate a minimum glycol content in the concentrates anti-freeze. • When the coolant level drops due to evaporation, add water only. In case of leakage, add anti-freeze and water in the specified mixing ratio.
Page 45: Others
L3200, WSM G GENERAL [11] OTHERS Bleeding Fuel System Air must be removed : 1. When the fuel filter or lines are removed. 2. When tank is completely empty. 3. After the tractor has not been used for a long period of time.
Page 46 L3200, WSM G GENERAL Replacing Fuse 1. The tractor electrical system is protected from potential damage by fuses. A blown fuse indicates that there is an overload or short somewhere in the electrical system. 2. If any of the fuses should blow, replace with a new one of the same capacity.
Page 47: Special Tools
L3200, WSM G GENERAL 8. SPECIAL TOOLS [1] SPECIAL TOOLS FOR ENGINE Special Use Puller Set Code No : 07916-09032 Application : Use exclusively for pulling out bearing, gears and other parts with ease. W10240500 Piston Ring Compressor Code No :...
Page 48 L3200, WSM G GENERAL Oil Pressure Tester Code No : 07916-32032 Application : Use to measure lubricating oil pressure. (1) Gauge (5) Adaptor 2 (2) Cable (6) Adaptor 3 (3) Threaded Joint (7) Adaptor 4 (4) Adaptor 1 (8) Adaptor 5...
Page 49 L3200, WSM G GENERAL Plastigage Code No : 07909-30241 Application : Use to check the oil clearance between crankshaft and bearing, etc.. Measuring: Green ..0.025 to 0.076 mm (0.001 to 0.003 in.) range Red ..0.051 to 0.152 mm (0.002 to 0.006 in.) Blue ..
Page 50 L3200, WSM G GENERAL NOTE • The following special tools are not provided, so make them referring to the figure. Valve Guide Replacing Tool Application : Use to press out and press in the valve guide. 20 mm dia. (0.79 in. dia.) 11.7 to 11.9 mm dia.
Page 51 L3200, WSM G GENERAL Bushing Replacing Tools Application : Use to press out and to press fit the bushing. (1) For small end bushing 162 mm (6.38 in.) 35 mm (1.38 in.) 27 mm (1.06 in.) 35 mm dia. (1.38 in. dia.) 27.90 to 27.95 mm dia.
Page 52 L3200, WSM G GENERAL Crankshaft Bearing 1 Replacing Tool Application : Use to press out and press fit the crankshaft bearing 1. 1. Extracting tool 135 mm (5.31 in.) 72 mm (2.83 in.) R40 mm (R1.57 in.) 10 mm (0.39 in.) 20 mm (0.79 in.)
Page 53: Special Tools For Tractor
L3200, WSM G GENERAL [2] SPECIAL TOOLS FOR TRACTOR Tie-rod End Lifter Code No : 07909-39051 Application : Use for removing the tie-rod end with ease. W10264720 Steering Wheel Puller Code No : 07916-51090 Application : Use for removing the steering wheel without damaging the steering shaft.
Page 54 L3200, WSM G GENERAL Rear Axle Cover Puller Code No : 07916-51041 Application : Use for removing a rear axle cover from rear axle. W10769940 Relief Valve Pressure Tester Code No : 07916-50045 Application : This allows easy measurement of relief set pressure.
Page 55 L3200, WSM G GENERAL Pump Adaptor Application : Use for checking the main hydraulic pump. NOTE • When using, attach with following parts. O-ring : 04811-00180 • This adaptor is modified from Adaptor 61 of flowmeter adaptor set. (See page G-38).
Page 56 L3200, WSM G GENERAL Pinion Locking Tool Code No : 07916-52311 Application : Use for preventing the shaft from turning when removing or tighten a bevel pinion shaft staking nut. W10445520 Rear Axle Nut Wrench 71 Code No : 07916-52531 Application : Use for removing and installing a rear axle nut.
Page 57 L3200, WSM G GENERAL NOTE • The following special tools are not provided, so make them referring to the figure. Pinion Shaft Remover Application : Use for removing a pinion shaft. 106 mm (4.17 in.) 350 mm (13.78 in.) 6 mm (0.24 in.) 90 mm (3.54 in.)
Page 58 L3200, WSM G GENERAL Draft Control Test Bar Application : Use for checking the lift range and floating range of hydraulic draft control. 1045 mm (41.14 in.) 1000 mm (29.37 in.) 20 mm dia. (0.79 in. dia.) 30 mm dia. (1.18 in. dia.) 90 mm (3.54 in.)
Page 59: Tires
L3200, WSM G GENERAL 9. TIRES [1] TIRE PRESSURE Though the tire pressure is factory-set to the prescribed level, it naturally drops slowly in the course of time. Thus, check it everyday and inflate as necessary. To inflate the wheel tires, use an air compressor or hand pump.
Page 60: Treads Adjustment
L3200, WSM G GENERAL [2] TREADS ADJUSTMENT CAUTION • When working on slopes or working with trailer, set the wheel tread as wide as practice for the job for maximum stability. • Support tractor securely on stands before removing a wheel.
Page 61: Rear Wheels
L3200, WSM G GENERAL (2) Rear Wheels Rear tread can be adjusted in 6 steps depending on the model. To change the tread 1. Lift the rear tires off the ground. 2. Follow the illustrations below to get the desired tread width.
Page 62: Tire Liquid Injection
L3200, WSM G GENERAL [3] TIRE LIQUID INJECTION Auxiliary weights can be used to increase traction force for plowing in fields or clay ground. Another way is to inject water or another liquid, such as a calcium chloride solution in the tires. Water must not be used in winter since it freezes at 0 °C (32 °F).
Page 63 L3200, WSM G GENERAL Injection CAUTION • When a calcium chloride solution is used, cool it before pouring it into the tire. • Do not fill tires with water or solution more than 75 % of full capacity (to the valve stem level).
Page 64 L3200, WSM G GENERAL Draining Water or Solution 1. Lift the rear tires off the ground. 2. Turn the tire so that the air valve is at the bottom. 3. Remove the air valve, and drain liquid (liquid can only be drained to the level of the valve and liquid under that level remains inside).
Page 65 ENGINE KiSC issued 12, 2006 A...
Page 66 MECHANISM CONTENTS 1. FEATURES ....................1-M1 2. FUEL SYSTEM ..................... 1-M2 [1] GENERAL ....................1-M2 [2] GOVERNOR .................... 1-M3 3. LUBRICATING SYSTEM ................1-M4 4. COOLING SYSTEM ..................1-M5 KiSC issued 12, 2006 A...
Page 67: Features
ENGINE 1. FEATURES The D1703-MA-E is vertical, water-cooled, 4 cycle diesel engine. This is incorporated KUBOTA’s foremost technologies. With KUBOTA’s E-TVCS (Three Vortex Combustion System), well-known Bosch type injection pump and the well-balanced designs, they give greater power, low fuel consumption, little vibration and quiet operation.
Page 68: Fuel System
L3200, WSM ENGINE 2. FUEL SYSTEM [1] GENERAL (1) Fuel Overflow Pipe (4) Fuel Tank (7) Fuel Filter a : Injected Fuel Flow (2) Injection Nozzle (5) Injection Pump Air Vent Pipe (8) Fuel Feed Pump b : Returned Fuel Flow...
Page 69: Governor
L3200, WSM ENGINE [2] GOVERNOR The governor serves to keep engine speed constant by automatically adjusting the amount of fuel supplied to the engine according to changes in the load. This engine employs an all-speed governor which controls the centrifugal force of the steel ball (1) weight, produced by rotation of the fuel camshaft (5), and the tension of the governor spring 1 (7) and 2 (8) are balanced.
Page 70: Lubricating System
L3200, WSM ENGINE 3. LUBRICATING SYSTEM (1) Rocker Arm (2) Oil Pressure Switch (3) Rocker Arm Shaft (4) Valve (5) Governor Shaft (6) Idle Gear (7) Crankshaft (8) Oil Pump (9) Oil Strainer (10) Relief Valve (11) Oil Filter Cartridge...
Page 71: Cooling System
L3200, WSM ENGINE 4. COOLING SYSTEM (1) Thermostat (2) Cylinder Head Water Jacket (3) Cylinder Block Water Jacket (4) Radiator (5) Cooling Fan (6) Water Pump The cooling system consists of a radiator (4), a centrifugal water pump (6), a cooling fan (5) and a thermostat (1).
Page 72 SERVICING CONTENTS 1. TROUBLESHOOTING ..................1-S1 2. SERVICING SPECIFICATIONS ..............1-S4 3. TIGHTENING TORQUES ................1-S9 4. CHECKING, DISASSEMBLING AND SERVICING........1-S10 [1] CHECKING AND ADJUSTING .............1-S10 (1) Compression Pressure ..............1-S10 (2) Valve Clearance................1-S11 (3) Top Clearance ..................1-S12 (4) Engine Oil Pressure ................1-S13 (5) Fan Belt.....................1-S13 (6) Radiator ....................1-S14 (7) Injection Pump ..................1-S16 (8) Injection Nozzle.................1-S17...
Page 73: Troubleshooting
L3200, WSM ENGINE 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Engine Does Not No fuel Replenish fuel – Start Air in the fuel system Bleed G-29 Water in the fuel system Change fuel and – repair or replace fuel...
Page 74 L3200, WSM ENGINE Reference Symptom Probable Cause Solution Page Either White or Blue Excessive engine oil Reduce to specified G-11 Exhaust Gas Is level Observed Piston ring and cylinder worn or stuck Repair or replace 1-S36, S37, S51, S52 Incorrect injection timing...
Page 75 L3200, WSM ENGINE Reference Symptom Probable Cause Solution Page Low Oil Pressure Engine oil insufficient Replenish G-11 Oil filter clogged Clean G-11 Relief valve stuck with dirt Clean – Relief valve spring weaken or broken Replace – Excessive oil clearance of crankshaft bearing...
Page 76: Servicing Specifications
L3200, WSM ENGINE 2. SERVICING SPECIFICATIONS ENGINE BODY Item Factory Specification Allowable Limit Cylinder Head Surface Flatness – 0.05 mm / 500 mm 0.0020 in./ 19.69 in. Compression Pressure 3.53 to 4.02 MPa / 2.55 MPa / (When Cranking with Starting Motor)
Page 77 L3200, WSM ENGINE ENGINE BODY (Continued) Item Factory Specification Allowable Limit Valve Spring Free Length 41.7 to 42.2 mm 41.2 mm 1.6417 to 1.6614 in. 1.6220 in. Setting Load / 117.6 N / 35.0 mm 100.0 N / 35.0 mm Setting Length 12.0 kgf / 35.0 mm...
Page 78 L3200, WSM ENGINE ENGINE BODY (Continued) Item Factory Specification Allowable Limit Camshaft Side Clearance 0.07 to 0.22 mm 0.3 mm 0.0028 to 0.0087 in. 0.0118 in. Camshaft Alignment – 0.01 mm 0.0004 in. Height 33.90 mm 33.85 mm (Intake / Exhaust) 1.3346 in.
Page 79 L3200, WSM ENGINE ENGINE BODY (Continued) Item Factory Specification Allowable Limit Crankshaft Journal to Crankshaft Bearing 1 Oil Clearance 0.040 to 0.118 mm 0.20 mm 0.00157 to 0.00465 in. 0.0079 in. Crankshaft Journal O.D. 59.921 to 59.940 mm – I.D.
Page 80 L3200, WSM ENGINE COOLING SYSTEM Item Factory Specification Allowable Limit Fan Belt Tension 7.0 to 9.0 mm / (0.28 to – 0.35 in.) deflection at 98 N (10 kgf, 22 lbs) of force Thermostat Valve Opening Temperature At Beginning 69.5 to 72.5 °C –...
Page 81: Tightening Torques
L3200, WSM ENGINE 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item Size x Pitch N·m kgf·m ft-lbs Starter’s B terminal mounting nut 7.8 to 9.8...
Page 82: Checking, Disassembling And Servicing
L3200, WSM ENGINE 4. CHECKING, DISASSEMBLING AND SERVICING [1] CHECKING AND ADJUSTING (1) Compression Pressure Compression Pressure 1. Run the engine until it is warmed up. 2. Stop the engine and disconnect the 2P connector from the stop solenoid in order to inject fuel.
Page 83: Valve Clearance
L3200, WSM ENGINE (2) Valve Clearance Valve Clearance IMPORTANT • Valve clearance must be checked and adjusted when engine is cold. 1. Remove the head cover, the glow plugs and the timing window cover on the clutch housing. 2. Align the “1TC” mark line on the flywheel and center or timing window so that the No.
Page 84: Top Clearance
L3200, WSM ENGINE (3) Top Clearance Top Clearance 1. Remove the cylinder head. 2. Move the piston and place a strip of fuse on the piston head at three positions with grease. 3. Lower the piston, and install the cylinder head. (Use a new cylinder head gasket and tighten with a specified tightening torque.)
Page 85: Engine Oil Pressure
L3200, WSM ENGINE (4) Engine Oil Pressure Engine Oil Pressure 1. Remove the engine oil pressure switch, and set an oil pressure tester. (Code No. : 07916-32032). (Adaptor screw size : PT 1/8) 2. Start the engine. After warming up, measure the oil pressure of both idling and rated speeds.
Page 86: Radiator
L3200, WSM ENGINE Fan Belt Damage and Wear 1. Check the fan belt for damage. 2. If the fan belt is damaged, replace it. 3. Check if the fan belt is worn and sunk in the pulley groove. 4. If the fan belt is nearly worn out and deeply sunk in the pulley groove, replace it.
Page 87 L3200, WSM ENGINE Radiator Water Leakage 1. Pour a specified amount of water into the radiator. 2. Set a radiator tester (Code No. 07909-31551) with an adapter (BANZAI Code No. RCT-2A-30S) and raise the water pressure to the specified pressure.
Page 88: Injection Pump
L3200, WSM ENGINE (7) Injection Pump Injection Timing 1. Remove the stop solenoid. 2. Remove the injection pipes and nozzle. 3. Set the speed control lever to maximum fuel discharge position. (Reference) • Turn the flywheel with screwdriver. 4. Turn the flywheel counterclockwise (facing the flywheel) until the fuel fills up to the hole of the delivery valve holder for 1st cylinder.
Page 89: Injection Nozzle
L3200, WSM ENGINE (8) Injection Nozzle CAUTION • Check the nozzle injection pressure and condition after confirming that there is nobody standing in the direction of the injected fuel. If the injected fuel from the nozzle directly contacts the human body, cells may be destroyed and blood poisoning may be caused.
Page 90: Preparation
L3200, WSM ENGINE [2] PREPARATION (1) Separating Engine and Clutch Housing Draining Engine Oil 1. Start and warm up the engine for approx. 5 minutes. 2. Place an oil pan uderneath the engine. 3. Remove the drain plugs (1) to drain oil.
Page 91 L3200, WSM ENGINE Draining the Transmission Fluid 1. Place an oil pan underneath the transmission case. 2. Remove the drain plugs (1) at the bottom of the transmission case. 3. Drain the transmission fluid. 4. Screw in the drain plugs (1).
Page 92 L3200, WSM ENGINE Bonnet and Front Cover 1. Disconnect the battery negative cable (1). 2. Disconnect the connector to head light and the head light wiring. 3. Remove bonnet (2) and side covers (3) on both sides. 4. Remove the front cover (4).
Page 93 L3200, WSM ENGINE Suction Hose and Delivery Pipe 1. Disconnect the suction hose (2). 2. Remove the step (6) mounting screws. 3. Remove the steering joint shaft (3). 4. Remove the delivery pipe (5). 5. Remove the throttle rod (1).
Page 94 L3200, WSM ENGINE Wiring Harness (Right Side) 1. Disconnect 1P connector to water temperature sensor (1). 2. Disconnect glow plug wiring harness (2). 3. Disconnect 2P connector to key stop solenoid (3). 4. Disconnect fuel sensor wiring harness (7). 5. Disconnect 4P connector to starter relay (6).
Page 95 L3200, WSM ENGINE Propeller Shaft 1. Remove the screw (3) then tap out the spring pin (5). 2. Slide the propeller shaft cover 1 (8) to the front and the cover 2 (2) to the rear. 3. Tap out the spring pins (1) and then slide the coupling (6) to the front and coupling (4) to the rear.
Page 96: Separating Engine From Front Axle Frame
L3200, WSM ENGINE Clutch Assembly 1. Insert the clutch center tool. 2. Remove the clutch assembly together with the clutch center tool. (When reassembling) • Direct the shorter end of the clutch disc boss toward the flywheel. • Apply molybdenum disulphide (Three Bond 1901 or equivalent) to the splines of clutch disc boss.
Page 97 L3200, WSM ENGINE Separating Engine from Front Axle Frame 1. Hoist the engine using chains securely attached to the engine lift points (1). 2. Remove the front axle frame mounting screw. 3. Separate the engine from the front axle frame (2).
Page 98: Disassembling And Assembling
L3200, WSM ENGINE [3] DISASSEMBLING AND ASSEMBLING (1) Cylinder Head and Valves External Components 1. Attach the engine to the disassembling stand. 2. Remove the cooling fan. 3. Remove the alternator (3) and fan belt (2). 4. Remove the starter motor (4).
Page 99 L3200, WSM ENGINE Nozzle Holder Assembly and Glow Plug 1. Remove the overflow pipe assembly (3). 2. Remove the nozzle holder assemblies (4) using a 21 mm deep socket wrench. 3. Remove the copper gasket (5) and heat seal (6).
Page 100 L3200, WSM ENGINE Rocker Arm and Push Rod 1. Remove the rocker arm bracket nuts. 2. Detach the rocker arm assembly (1). 3. Remove the push rods (2). (When reassembling) • When putting the push rods (2) onto the tappets (3), check to see if their ends are properly engaged with the grooves.
Page 101: Timing Gears, Camshaft And Fuel Camshaft
L3200, WSM ENGINE Tappets 1. Remove the tappets (1) from the crankcase. (When reassembling) • Visually check the contact between tappets and cams for proper rotation. If defect is found, replace tappets. • Before installing the tappets, apply engine oil thinly around them.
Page 102 L3200, WSM ENGINE Injection Pump 1. Remove the stop solenoid (4) and hi-idling body (1). 2. Remove the engine stop lever (3) and stop solenoid guide (6). 3. Remove the fuel hose (7), pump cover (5) and fuel injection pump assembly (2).
Page 103 L3200, WSM ENGINE Governor Springs and Speed Control Plate NOTE • Specific tool (1) : 1.2 mm diameter hard wire with its end hooked, overall length 200 mm (7.87 in.) The tip of wire is bent like a hook to hang around the ends of the governor springs.
Page 104 L3200, WSM ENGINE Fan Drive Pulley 1. Lock the flywheel not to turn using the flywheel stopper. 2. Remove the fan drive pulley mounting nut (1). 3. Remove the fan drive pulley (2) with gear puller (3). 4. Remove the feather key.
Page 105 L3200, WSM ENGINE Gear Case 1. Remove the hour meter gear case. 2. Remove the gear case (2). 3. Remove the O-rings (1). (When reassembling) • Apply a liquid gasket (Three Bond 1215 or equivalent) to both sides of hour meter gear case gasket.
Page 106 L3200, WSM ENGINE Fuel Camshaft and Fork Lever Assembly 1. Remove the fuel feed pump (8) and hydraulic pump drive gear (9). 2. Detach the fuel camshaft stopper (1). 3. Remove the three fork lever holder mounting screws (2). 4. Draw out the fuel camshaft assembly (5), (6) and fork lever assembly (3), (4), (7) at the same time.
Page 107: Connecting Rod And Piston
L3200, WSM ENGINE (3) Connecting Rod and Piston Oil Pan and Oil Strainer 1. Remove the oil pan mounting screws. 2. Remove the oil pan (1) by lightly tapping the rim of the pan with a wooden hammer. 3. Remove the oil pan gasket (2).
Page 108 L3200, WSM ENGINE Pistons 1. Completely clean carbon (1) from the cylinders. 2. Remove the connecting rod cap (3). 3. Turn the flywheel and bring the piston to top dead center. 4. Draw out the piston upward by lightly tapping it from the bottom of the crankcase with the grip of a hammer.
Page 109 L3200, WSM ENGINE Piston Ring and Connecting Rod 1. Remove the piston rings using a piston ring tool (Code No. 07909-32121). 2. Remove the piston pin (1), and separate the connecting rod (7) from the piston (2). (When reassembling) • When installing the ring, assemble the rings so that the manufacturer’s mark (12) near the gap faces the top of the piston.
Page 110: Crankshaft
L3200, WSM ENGINE (4) Crankshaft Flywheel 1. Fit the stopper to the flywheel (1). 2. Remove the all flywheel screws (2). 3. Remove the flywheel (1) slowly. (When reassembling) • Insert two flywheel guide screws. • Check to see that there are no metal particles left on the flywheel mounting surfaces.
Page 111 L3200, WSM ENGINE Crankshaft NOTE • Before disassembling, check the side clearance of crankshaft. Also check it during reassembling. 1. Remove the main bearing case screw 2 (1). 2. Pull out the crankshaft assembly, taking care not to damage the crankshaft bearing 1.
Page 112 L3200, WSM ENGINE Main Bearing Case Assembly 1. Remove the two main bearing case screws 1, and remove the main bearing case assembly being careful with thrust bearing and crankshaft bearing. 2. Remove the main bearing case 1, 2 as above.
Page 113: Thermostat
L3200, WSM ENGINE (5) Thermostat Thermostat Assembly 1. Remove the thermostat cover mounting screws, and remove the thermostat cover (1). 2. Remove the thermostat assembly (3). (When reassembling) • Apply a liquid gasket (Three Bond 1215 or equivalent) only at the thermostat cover side of the thermostat cover gasket (2).
Page 114: Servicing
L3200, WSM ENGINE [4] SERVICING (1) Cylinder Head and Valves Cylinder Head Surface Flatness 1. Clean the cylinder head surface. 2. Place a straightedge on the cylinder head’s four sides and two diagonal as shown in the figure. 3. Measure the clearance with a feeler gauge.
Page 115 L3200, WSM ENGINE Valve Recessing 1. Clean the cylinder head surface, valve face and valve seat. 2. Insert the valve into the valve guide. 3. Measure the valve recessing with a depth gauge. 4. If the measurement exceeds the allowable limit, replace the valve.
Page 116 L3200, WSM ENGINE Clearance between Valve Stem and Valve Guide 1. Remove carbon from the valve guide section. 2. Measure the valve stem O.D. with an outside micrometer. 3. Measure the valve guide I.D. with a small hole gauge, and calculate the clearance.
Page 117 L3200, WSM ENGINE Valve Seating 1. Coat the valve face lightly with prussian blue and put the valve on its seat to check the contact. 2. If the valve does not seat all the way around the valve seat or the valve contact is less than 70 %, correct the valve seating as follows.
Page 118 L3200, WSM ENGINE Valve Lapping 1. Apply compound evenly to the valve lapping surface. 2. Insert the valve into the valve guide. Lap the valve onto its seat with a valve flapper or screwdriver. 3. After lapping the valve, wash the compound away and apply oil, then repeat valve lapping with oil.
Page 119 L3200, WSM ENGINE Oil Clearance between Rocker Arm and Rocker Arm Shaft 1. Measure the rocker arm shaft O.D. with an outside micrometer. 2. Measure the rocker arm I.D. with an inside micrometer, and then calculate the oil clearance. 3. If the oil clearance exceeds the allowable limit, replace the rocker arm and measure the oil clearance again.
Page 120: Timing Gears, Camshaft And Fuel Camshaft
L3200, WSM ENGINE (2) Timing Gears, Camshaft and Fuel Camshaft Timing Gear Backlash 1. Set a dial indicator (lever type) with its tip on the gear tooth. 2. Move the gear to measure the backlash, holding its mating gear. 3. If the backlash exceeds the allowable limit, check the oil clearance of the shaft and the gear.
Page 121 L3200, WSM ENGINE Camshaft Alignment 1. Support the camshaft with V blocks on the surface plate at both end journals. 2. Set a dial indicator with its tip on the intermediate journal. 3. Measure the camshaft alignment. 4. If the measurement exceeds the allowable limit, replace the camshaft.
Page 122: Piston And Connecting Rod
L3200, WSM ENGINE Oil Clearance between Idle Gear Shaft and Idle Gear Bushing 1. Measure the idle gear shaft O.D. with an outside micrometer. 2. Measure the idle gear bushing I.D. with an inside micrometer, and calculate the oil clearance.
Page 123 L3200, WSM ENGINE Oil Clearance between Piston Pin and Small End Bushing 1. Measure the piston pin O.D. where it contacts the bushing with an outside micrometer. 2. Measure the small end bushing I.D. with an inside micrometer, and calculate the oil clearance.
Page 124 L3200, WSM ENGINE Clearance between Piston Ring and Groove 1. Remove carbon from the ring grooves. 2. Measure the clearance between the ring and the groove with a feeler gauge or depth gauge. 3. If the clearance exceeds the allowable limit, replace the ring as compression leakage and oil loss or burning will result.
Page 125: Crankshaft
L3200, WSM ENGINE (4) Crankshaft Side Clearance of Crankshaft 1. Set a dial indicator with its tip on the end of the crankshaft. 2. Measure the side clearance by moving the crankshaft to the front and rear. 3. If the measurement exceeds the allowable limit, replace the thrust bearings.
Page 126 L3200, WSM ENGINE Oil Clearance between Crankpin and Crankpin Bearing 1. Clean the crankpin and crankpin bearing. 2. Put a strip of plastigage on the center of the crankpin. 3. Install the connecting rod cap and tighten the connecting rod screws to the specified torque, and remove the cap again.
Page 127 L3200, WSM ENGINE Oil Clearance between Crankshaft Journal and Crankshaft Bearing 1 1. Measure the O.D. of the crankshaft journal with an outside micrometer. 2. Measure the I.D. of the crankshaft bearing 1 with an inside micrometer, and calculate oil clearance.
Page 128 L3200, WSM ENGINE Oil Clearance between Crankshaft Journal and Crankshaft Bearing 2 1. Put a strip of plastigage on the center of the journal. 2. Install the bearing case and tighten the bearing case screws 1 to the specified torque, and remove the bearing case again.
Page 129 L3200, WSM ENGINE Replacing Crankshaft Sleeve 1. Remove the used crankshaft sleeve (3). 2. Set the sleeve guide (2) to the crankshaft (5). 3. Set the stopper (1) to the crankshaft (5) as shown in figure. 4. Heat a new sleeve to a temperature between 150 and 200 °C (302 and 392 °F), and fix the sleeve to the crankshaft (5) as...
Page 130: Cylinder
L3200, WSM ENGINE (5) Cylinder Cylinder Wear 1. Measure the I.D. of the cylinder at the six positions (see figure) with a cylinder gauge to find the maximum and minimum I.D.’s. 2. Get the difference (Maximum wear) between the maximum and the minimum I.D.’s.
Page 131: Oil Pump
L3200, WSM ENGINE (6) Oil Pump Rotor Lobe Clearance 1. Measure the clearance between lobes of the inner rotor and the outer rotor with a feeler gauge. 2. Measure the clearance between the outer rotor and the pump body with a feeler gauge.
Page 132 CLUTCH KiSC issued 12, 2006 A...
Page 133 MECHANISM CONTENTS 1. STRUCTURE ....................2-M1 KiSC issued 12, 2006 A...
Page 134 L3200 tractor, equipped with the dual stage type clutch, has a live PTO function which enables stoppage of the power transmission to the traveling system while the PTO is in rotation.
Page 135 SERVICING CONTENTS 1. TROUBLESHOOTING ..................2-S1 2. SERVICING SPECIFICATIONS ..............2-S2 3. TIGHTENING TORQUES ................2-S3 4. CHECKING, DISASSEMBLING AND SERVICING........2-S4 [1] CHECKING AND ADJUSTING ...............2-S4 [2] PREPARATION ..................2-S5 (1) Separating Engine and Clutch Housing ..........2-S5 (2) Separating Clutch Assembly.............2-S10 [3] DISASSEMBLING AND ASSEMBLING..........2-S11 [4] SERVICING ....................2-S12 KiSC issued 12, 2006 A...
Page 136: Troubleshooting
L3200, WSM CLUTCH 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Clutch Drags Clutch pedal free play excessive Adjust 2-S4 Clutch disc boss spline sticking or rusted Replace or remove 2-S10 rust Dust on clutch disc generated from clutch disc Replace or remove –...
Page 137: Servicing Specifications
L3200, WSM CLUTCH 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Clutch Pedal Free Travel 20 to 30 mm – 0.8 to 1.2 in. Pressure Plate to Adjusting Bolt Clearance 1.4 to 1.5 mm – 0.055 to 0.059 in. Clutch Disc Boss to Main Shaft (Traveling) Backlash –...
Page 138: Tightening Torques
L3200, WSM CLUTCH 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Lock nut 15.7 to 21.6 1.6 to 2.2...
Page 139: Checking, Disassembling And Servicing
L3200, WSM CLUTCH 4. CHECKING, DISASSEMBLING AND SERVICING [1] CHECKING AND ADJUSTING Clutch Pedal Free Travel 1. Stop the engine and remove the key. 2. Slightly depress the clutch pedal and measure free travel at top of pedal stroke. 3. If adjustment is needed, loosen the lock nut (1), and turn the turn buckle (2) to adjust the clutch pedal free travel within factory specification.
Page 140: Preparation
L3200, WSM CLUTCH [2] PREPARATION (1) Separating Engine and Clutch Housing Draining the Transmission Fluid 1. Place an oil pan underneath the transmission case. 2. Remove the drain plugs (1) at the bottom of the transmission case. 3. Drain the transmission fluid.
Page 141 L3200, WSM CLUTCH Bonnet and Front Cover 1. Disconnect the battery negative cable (1). 2. Disconnect the connector to head light and the head light wiring. 3. Remove bonnet (2) and side covers (3) on both sides. 4. Remove the front cover (4).
Page 142 L3200, WSM CLUTCH Suction Hose and Delivery Pipe 1. Disconnect the suction hose (2). 2. Remove the step (6) mounting screws. 3. Remove the steering joint shaft (3). 4. Remove the delivery pipe (5). 5. Remove the throttle rod (1).
Page 143 L3200, WSM CLUTCH Wiring Harness (Right Side) 1. Disconnect 1P connector to water temperature sensor (1). 2. Disconnect glow plug wiring harness (2). 3. Disconnect 2P connector to key stop solenoid (3). 4. Disconnect fuel sensor wiring harness (7). 5. Disconnect 4P connector to starter relay (6).
Page 144 L3200, WSM CLUTCH Propeller Shaft 1. Remove the screw (3) then tap out the spring pin (5). 2. Slide the propeller shaft cover 1 (8) to the front and the cover 2 (2) to the rear. 3. Tap out the spring pins (1) and then slide the coupling (6) to the front and coupling (4) to the rear.
Page 145: Separating Clutch Assembly
L3200, WSM CLUTCH (2) Separating Clutch Assembly Clutch Assembly 1. Insert the clutch center tool. 2. Remove the clutch assembly together with the clutch center tool. (When reassembling) • Direct the shorter end of the clutch disc boss toward the flywheel.
Page 146: Disassembling And Assembling
L3200, WSM CLUTCH [3] DISASSEMBLING AND ASSEMBLING Mounting to Main Clutch Assembling Tool 1. Put parting marks on the clutch cover and pressure plate. 2. Mount the clutch on dual stage clutch exclusive tool (Code No. 07916-90052). W1017217 Disassembling Clutch Assembly 1.
Page 147 L3200, WSM CLUTCH [4] SERVICING Backlash between Clutch Disc Boss and Shaft 1. Mount the PTO clutch disc to the 16T gear shaft. 2. Hold the gear 16T gear shaft so that it does not turn. 3. Rotate disc lightly and measure the displacement around the disc edge.
Page 148 L3200, WSM CLUTCH Release Lever Height 1. Mount the dual stage clutch exclusive tool (Code No. 07916- 90052). 2. Measure the clearance between gauge ring and the top of adjusting screw with a feeler gauge. 3. If the clearance is not within the factory specifications, adjust with the adjusting screws.
Page 149 TRANSMISSION KiSC issued 12, 2006 A...
Page 150 MECHANISM CONTENTS 1. STRUCTURE ....................3-M1 KiSC issued 12, 2006 A...
Page 151 L3200, WSM TRANSMISSION 1. STRUCTURE 3TLAAAE3P024A (1) Main Gear Shift Section (2) Lo-Reverse, Hi-Shift Section (3) PTO Gear Section (4) 4WD Section (Drive Gear) 3-M1 KiSC issued 12, 2006 A...
Page 152: Servicing
SERVICING CONTENTS 1. TROUBLESHOOTING ..................3-S1 2. SERVICING SPECIFICATIONS ..............3-S3 3. TIGHTENING TORQUES ................3-S4 4. CHECKING, DISASSEMBLING AND SERVICING........3-S5 [1] PREPARATION ..................3-S5 (1) Separating Engine and Clutch Housing ..........3-S5 (2) Separating Clutch Housing Case ............3-S10 (3) Separating Transmission Case............3-S11 [2] DISASSEMBLING AND ASSEMBLING..........3-S17 (1) Clutch Housing Case ................3-S17 (2) Transmission Case ................3-S21 (3) Disassembling Differential Gear Assembly ........3-S26...
Page 153: Troubleshooting
L3200, WSM TRANSMISSION 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Excessive Transmission fluid insufficient Replenish 3-S5 Transmission Noise Gear worn or backlash improper Replace 3-S29 Bearing worn or broken Replace 3-S29 Shift fork worn Replace 3-S29 Spline worn Replace...
Page 154 L3200, WSM TRANSMISSION Reference Symptom Probable Cause Solution Page Excessive or Improper backlash between spiral bevel pinion Adjust 3-S30, S31 Unusual Noise at All and spiral bevel gear Time Improper backlash between differential pinion Adjust 3-S32 and differential side gear...
Page 155: Servicing Specifications
L3200, WSM TRANSMISSION 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Gear Backlash 0.1 to 0.3 mm 0.4 mm 0.004 to 0.012 in. 0.016 in. Gear to Spline Clearance 0.030 to 0.078 mm 0.2 mm 0.0012 to 0.0031 in. 0.0079 in.
Page 156: Tightening Torques
L3200, WSM TRANSMISSION 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Deliver pipe joint bolt 49 to 69 5.0 to 7.0...
Page 157: Checking, Disassembling And Servicing
L3200, WSM TRANSMISSION 4. CHECKING, DISASSEMBLING AND SERVICING [1] PREPARATION (1) Separating Engine and Clutch Housing Draining the Transmission Fluid 1. Place an oil pan underneath the transmission case. 2. Remove the drain plugs (1) at the bottom of the transmission case.
Page 158 L3200, WSM TRANSMISSION Bonnet and Front Cover 1. Disconnect the battery negative cable (1). 2. Disconnect the connector to head light and the head light wiring. 3. Remove bonnet (2) and side covers (3) on both sides. 4. Remove the front cover (4).
Page 159 L3200, WSM TRANSMISSION Suction Hose and Delivery Pipe 1. Disconnect the suction hose (2). 2. Remove the step (6) mounting screws. 3. Remove the steering joint shaft (3). 4. Remove the delivery pipe (5). 5. Remove the throttle rod (1).
Page 160 L3200, WSM TRANSMISSION Wiring Harness (Right Side) 1. Disconnect 1P connector to water temperature sensor (1). 2. Disconnect glow plug wiring harness (2). 3. Disconnect 2P connector to key stop solenoid (3). 4. Disconnect fuel sensor wiring harness (7). 5. Disconnect 4P connector to starter relay (6).
Page 161 L3200, WSM TRANSMISSION Propeller Shaft 1. Remove the screw (3) then tap out the spring pin (5). 2. Slide the propeller shaft cover 1 (8) to the front and the cover 2 (2) to the rear. 3. Tap out the spring pins (1) and then slide the coupling (6) to the front and coupling (4) to the rear.
Page 162: Separating Clutch Housing Case
L3200, WSM TRANSMISSION (2) Separating Clutch Housing Case Outer Components 1. Remove the grip (1) and auxiliary change lever guide (3). 2. Remove the grip (2). 3. Remove the grip (4) and position control lever guide (5). 4. Remove the housing cover (7) and center cover (6).
Page 163: Separating Transmission Case
L3200, WSM TRANSMISSION (3) Separating Transmission Case Draining the Transmission Fluid 1. Place an oil pan underneath the transmission case. 2. Remove the drain plugs (1) at the bottom of the transmission case. 3. Drain the transmission fluid. 4. Screw in the drain plugs (1).
Page 164 L3200, WSM TRANSMISSION Three Point Linkage and ROPS 1. Secure ROPS (1) with safety strap (2). 2. Remove top link (3), lift rod (4) and lower link (5). 3. Unscrew ROPS mounting screws (6) (both sides), then remove ROPS. (When reassembling) 167 to 196 N·m...
Page 165 L3200, WSM TRANSMISSION Outer Components 1. Place the disassembling stands under the transmission case. 2. Remove the seat (1). 3. Remove the grip (2), (4), (7) and (9) if equipped. 4. Remove the range gear shift lever guide (3) and the position control lever guide (6).
Page 166 L3200, WSM TRANSMISSION Suction Pipe and Brake Rods 1. Remove the PTO safety switch connector (2). 2. Remove the brake rod RH (3). 3. Remove the suction pipe (4). 4. Disconnect the delivery pipe (1) from the hydraulic cylinder. 5. Disconnect the ground wiring harness (5) and move the main harness to the front.
Page 167 L3200, WSM TRANSMISSION Hydraulic Cylinder Assembly 1. Loosen and remove the hydraulic cylinder assembly mounting screws and nuts. 2. Support the hydraulic cylinder assembly with nylon lift strap and hoist, and then lift it clear. (When reassembling) • Apply liquid gasket (Three Bond 1208D or equivalent) to joint face of the hydraulic cylinder assembly and transmission case after eliminating the water, oil and the old remaining liquid gasket.
Page 168 L3200, WSM TRANSMISSION Brake Case 1. Loosen and remove the brake case mounting screws and nuts. 2. Separate the brake case (2), tapping the brake cam lever (3) lightly. (When reassembling) • Apply grease to the brake ball seats. (Do not grease excessively.).
Page 169: Disassembling And Assembling
L3200, WSM TRANSMISSION [2] DISASSEMBLING AND ASSEMBLING (1) Clutch Housing Case Speed Change Cover 1. Remove the speed change cover (1). (When reassembling) • Apply liquid gasket (Three Bond 1208D or equivalent) to joint face of speed change cover and clutch housing.
Page 170 L3200, WSM TRANSMISSION Counter Shaft 1. Remove the bolt (1) and take out the spring and ball. 2. Tap out the spring pin (2). 3. Draw out the fork rod (3) to the front and take out the shift fork (4) and balls.
Page 171 L3200, WSM TRANSMISSION PTO Gear Shaft 1. Remove the external snap ring (2) and 29T gear (3). 2. Remove the internal snap ring (1). 3. Draw out the PTO gear shaft assembly (4) to the rear with a slide hammer (5).
Page 172 L3200, WSM TRANSMISSION Main Shaft 1. Remove the internal snap ring (6). 2. Tap out the main shaft (4) to the rear. NOTE • When drawing out the main shaft, take out the following parts one by one: copper washer (1), 23T gear (2) and 17T gear (3).
Page 173: Transmission Case
L3200, WSM TRANSMISSION PTO Counter Shaft 1. Remove the bearing cover (2). 2. Remove the external snap ring (3). 3. Tap out the PTO counter shaft (1) to the rear and take out the 39T gear (6). 4. Tap out the PTO counter shaft (1) to the front and take out the 23T gear (7).
Page 174 L3200, WSM TRANSMISSION Mid Case 1. Tap out the spring pin (1). 2. Remove the guide plate (2). 3. Remove the lock nut (3) and lock bolt (4). 4. Remove the pinion bearing cover (6) and shims (5). 5. Separate the mid case (7) from the transmission case.
Page 175 L3200, WSM TRANSMISSION Sub Shaft 1. Remove the bearing (1) and (16) with bearing puller. 2. Remove the external snap ring (2) and (15). 3. Remove the shift fork (12) and 31T gear (3). 4. Remove the external snap ring (4) and collar (5).
Page 176 L3200, WSM TRANSMISSION Pinion Shaft 1. Remove the pinion shaft (1) and PTO drive shaft assembly (8). (1) Pinion Shaft (5) External Snap Ring (2) 19T Gear (6) External Snap Ring (3) 42T Gear (7) External Snap Ring (4) 29T Gear...
Page 177 L3200, WSM TRANSMISSION PTO Bearing Case 1. Remove the bearing case (2) mounting screws. 2. Take out the PTO shaft (1) with bearing case. (1) PTO Shaft (2) PTO Bearing Case W1021660 PTO Shaft 1. Remove the internal snap ring (2).
Page 178: Disassembling Differential Gear Assembly
L3200, WSM TRANSMISSION Front Drive Case 1. Removing the front drive case. 2. Remove the oil seal (1). 3. Tap out the propeller shaft 1 (3) to the front. 4. Take out the shift gear (6). (When reassembling) • Replace the oil seal (1) with a new one and apply grease to its inside.
Page 179 L3200, WSM TRANSMISSION Spiral Bevel Gear 1. Remove the spiral bevel gear. (When reassembling) • Check the spiral bevel gear for wear or damage. If it is no longer serviceable, replace it. Then, also replace the spiral bevel pinion shaft.
Page 180: Servicing
L3200, WSM TRANSMISSION [3] SERVICING (1) Clutch Housing Gear Backlash 1. Set a dial indicator (lever type) on one of the tooth faces. 2. Clamp the mating gear. 3. Measure backlash by turning the gear to be measured. 4. If the reading exceeds the allowable limit, replace the gear.
Page 181: Transmission Case
L3200, WSM TRANSMISSION (2) Transmission Case Checking Bearing 1. Hold the inner race, push and pull the outer race in all directions to check for wear and roughness. 2. Apply transmission fluid to the bearing, and hold the inner race.
Page 182 L3200, WSM TRANSMISSION Spiral Bevel Pinion Turning Torque (with Differential Gear) 1. Grip the spiral bevel pinion nut with a torque wrench and measure the turning torque. 2. If the turning torque is not within the factory specifications, check the differential gear turning force, backlash and tooth contact again.
Page 183 L3200, WSM TRANSMISSION Proper Contact More than 35 % red lead contact area on the gear tooth surface. The center of tooth contact at 1/3 of the entire width from the small end. (A) Correct Contact W10187470 Heel Contact and Tip Contact Replace the adjusting shim with thicker one to move the bevel pinion shaft forward.
Page 184 L3200, WSM TRANSMISSION Clearance between Differential Pinion Shaft and Differential Pinion 1. Measure the differential pinion shaft O.D. 2. Measure the differential pinion I.D. and calculate the clearance. 3. If the clearance exceeds the allowable limit, replace them. 0.080 to 0.122 mm Factory spec.
Page 185: Rear Axle
REAR AXLE KiSC issued 12, 2006 A...
Page 186 MECHANISM CONTENTS 1. STRUCTURE ....................4-M1 KiSC issued 12, 2006 A...
Page 187 L3200, WSM REAR AXLE 1. STRUCTURE (1) Ball Bearing (2) Rear Axle (3) Rear Axle Case (4) Differential Gear Shaft (5) Brake Case (6) Brake Disc (7) Differential Lock Shift Fork (8) 39T Bevel Gear (9) Differential Pinion (10) Final Gear...
Page 188 SERVICING CONTENTS 1. TROUBLESHOOTING ..................4-S1 2. TIGHTENING TORQUES ................4-S2 3. DISASSEMBLING AND SERVICING............4-S3 [1] PREPARATION ..................4-S3 [2] DISASSEMBLING REAR AXLE..............4-S6 [3] SERVICING ....................4-S7 KiSC issued 12, 2006 A...
Page 189: Troubleshooting
L3200, WSM REAR AXLE 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Excessive or Improper backlash between differential gear Replace 4-S6 Unusual Noise at All shaft and final gear Time Bearing worn Replace 4-S6 Insufficient or improper type of transmission fluid...
Page 190: Tightening Torques
L3200, WSM REAR AXLE 2. TIGHTENING TORQUES Tightening torques of screws, and nuts on the table below are especially specified. (For general use screws and nuts : See page G-7.) Item N·m kgf·m ft-lbs Rear wheel mounting screw and nut...
Page 191: Disassembling And Servicing
L3200, WSM REAR AXLE 3. DISASSEMBLING AND SERVICING [1] PREPARATION Draining the Transmission Fluid 1. Place an oil pan underneath the transmission case. 2. Remove the drain plugs (1) at the bottom of the transmission case. 3. Drain the transmission fluid.
Page 192 L3200, WSM REAR AXLE Three Point Linkage and ROPS 1. Secure ROPS (1) with safety strap (2). 2. Remove top link (3), lift rod (4) and lower link (5). 3. Unscrew ROPS mounting screws (6) (both sides), then remove ROPS.
Page 193 L3200, WSM REAR AXLE Rear Axle Case 1. Loosen and remove the rear axle case mounting screws and nuts. 2. Support the rear axle case (1) with the nylon lift strap and hoist. 3. Separate the rear axle case from brake case.
Page 194: Disassembling Rear Axle
L3200, WSM REAR AXLE [2] DISASSEMBLING REAR AXLE (1) Rear Axle (2) Oil Seal (3) Internal Snap Ring (4) Ball Bearing (5) Spacer (6) Rear Axle Case (7) Gear (8) Lock Nut (9) Ball Bearing (10) Ball Bearing W10115940 1. Remove the ball bearing (9) with a puller.
Page 195: Servicing
L3200, WSM REAR AXLE [3] SERVICING Checking Bearing 1. Hold the inner, and push and pull the outer race in all directions to check for wear and roughness. 2. Apply transmission fluid to the bearing, and hold the inner race.
Page 196 BRAKES KiSC issued 12, 2006 A...
Page 197 MECHANISM CONTENTS 1. STRUCTURE ....................5-M1 2. OPERATION ....................5-M2 KiSC issued 12, 2006 A...
Page 198 L3200, WSM BRAKES 1. STRUCTURE (1) Brake Pedal (2) Parking Brake Lever (3) Parking Brake Cable (4) Cam Plate W1012845 Independent mechanical wet disc brakes are used for the right and left traveling brakes. They are operated by the brake pedals through the mechanical linkages.
Page 199 L3200, WSM BRAKES 2. OPERATION (1) Brake Case (3) Cam Plate (5) Brake Cam Lever (7) Brake Cam (2) Brake Disc (4) Steel Ball (6) Plate (8) Brake Shaft The brakes are provided on the power transmitting shafts (brake shafts (8)) through which power is transmitted to the final reduction system.
Page 200 SERVICING CONTENTS 1. TROUBLESHOOTING ..................5-S1 2. SERVICING SPECIFICATIONS ..............5-S2 3. TIGHTENING TORQUES ................5-S3 4. CHECKING, DISASSEMBLING AND SERVICING........5-S4 [1] CHECKING AND ADJUSTING ...............5-S4 [2] PREPARATION ..................5-S5 (1) Separating Rear Axle Case from Transmission Case ......5-S5 [3] DISASSEMBLING AND ASSEMBLING..........5-S8 [4] SERVICING ....................5-S9 KiSC issued 12, 2006 A...
Page 201: Troubleshooting
L3200, WSM BRAKES 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Uneven Braking Brake disc worn Replace 5-S9 Force Cam plate warped Replace 5-S9 Brake Drags Ball holes of cam plate for uneven wear Replace 5-S9 Brake pedal return spring weaken or broken Replace –...
Page 202: Servicing Specifications
L3200, WSM BRAKES 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Parking Brake Cable Adjusting 125 to 130 mm – Dimension 4.92 to 5.12 in. Parking Brake Shaft to Bushing Clearance 0.05 to 0.20 mm 1.0 mm 0.002 to 0.008 in.
Page 203: Tightening Torques
L3200, WSM BRAKES 3. TIGHTENING TORQUES Tightening torques of screws, and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Rear wheel mounting screw and nut...
Page 204: Checking, Disassembling And Servicing
L3200, WSM BRAKES 4. CHECKING, DISASSEMBLING AND SERVICING [1] CHECKING AND ADJUSTING Brake Pedal Free Travel CAUTION • Stop the engine and remove the key, then chock the wheel before checking brake pedals. 1. Release the parking brake. 2. Slightly depress the brake pedals and measure free travel (A) at top of pedal stroke.
Page 205: Preparation
L3200, WSM BRAKES [2] PREPARATION (1) Separating Rear Axle Case from Transmission Case Draining the Transmission Fluid 1. Place an oil pan underneath the transmission case. 2. Remove the drain plugs (1) at the bottom of the transmission case. 3. Drain the transmission fluid.
Page 206 L3200, WSM BRAKES Three Point Linkage and ROPS 1. Secure ROPS (1) with safety strap (2). 2. Remove top link (3), lift rod (4) and lower link (5). 3. Unscrew ROPS mounting screws (6) (both sides), then remove ROPS. (When reassembling) 167 to 196 N·m...
Page 207 L3200, WSM BRAKES Rear Axle Case 1. Loosen and remove the rear axle case mounting screws and nuts. 2. Support the rear axle case (1) with the nylon lift strap and hoist. 3. Separate the rear axle case from brake case.
Page 208: Disassembling And Assembling
L3200, WSM BRAKES [3] DISASSEMBLING AND ASSEMBLING Brake Case It is possible to disassemble as shown in the figure below. (When reassembling) • Place the brake discs (4) so that the hole (A) of the second disc should be overlapped 50 % or more.
Page 209: Servicing
L3200, WSM BRAKES [4] SERVICING Brake Cam Lever Movement 1. Move the brake cam lever by hand to check the movement. 2. If the movement is heavy, clean up the brake cam with sandpaper. W10144750 Cam Plate Flatness 1. Place the cam plate on the surface plate.
Page 210 L3200, WSM BRAKES Clearance between Parking Brake Shaft and Bushing 1. Measure the parking brake shaft O.D. with an outside micrometer. 2. Measure the parking brake bushing I.D. with a cylinder gauge. 3. Calculate the clearance. 4. If the clearance exceeds the allowable limit, replace the bushing.
Page 211: Front Axle
FRONT AXLE KiSC issued 12, 2006 A...
Page 212 MECHANISM CONTENTS 1. STRUCTURE ....................6-M1 KiSC issued 12, 2006 A...
Page 213 L3200, WSM FRONT AXLE 1. STRUCTURE (1) Bevel Gear Case (7) Front Axle Bracket, Front (13) Bevel Gear (19) Pinion Shaft (2) Bevel Gear (8) Differential Pinion (14) Bevel Gear (20) Differential Assembly (3) Front Axle Case (9) Differential Case...
Page 214 SERVICING CONTENTS 1. TROUBLESHOOTING ..................6-S1 2. SERVICING SPECIFICATIONS ..............6-S2 3. TIGHTENING TORQUES ................6-S5 4. CHECKING, DISASSEMBLING AND SERVICING........6-S6 [1] CHECKING AND ADJUSTING ...............6-S6 [2] PREPARATION ..................6-S8 (1) Separating Front Axle .................6-S8 [3] DISASSEMBLING AND ASSEMBLING..........6-S10 [4] SERVICING ....................6-S14 KiSC issued 12, 2006 A...
Page 215: Troubleshooting
L3200, WSM FRONT AXLE 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Front Wheels Tire pressure uneven Adjust G-43 Wander to Right or Improper toe-in adjustment (improper alignment) Adjust 6-S6 Left Clearance between front axle case boss and Replace 6-S18...
Page 216: Servicing Specifications
L3200, WSM FRONT AXLE 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Front Wheel Alignment Toe-in 2 to 8 mm – 0.08 to 0.32 in. Front Wheel Axial Sway Less than 5 mm – 0.20 in. Front Axle Rocking Force 49.0 to 117.7 N...
Page 217 L3200, WSM FRONT AXLE (Continued) Item Factory Specification Allowable Limit Differential Pinion to Differential Side Gear Backlash 0.1 to 0.3 mm – 0.004 to 0.012 in. Shim Thickness 0.4 mm – 0.016 in. 0.6 mm – 0.024 in. 0.8 mm –...
Page 218 L3200, WSM FRONT AXLE (Continued) Item Factory Specification Allowable Limit 11T Bevel Gear to 42T Bevel Gear Backlash 0.15 to 0.35 mm – 0.0059 to 0.0138 in. Shim Thickness 1.0 mm – 0.039 in. 1.2 mm – 0.047 in. 1.4 mm –...
Page 219: Tightening Torques
L3200, WSM FRONT AXLE 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Tie-rod end nut 39.2 to 44.1 4.0 to 4.5...
Page 220: Checking, Disassembling And Servicing
L3200, WSM FRONT AXLE 4. CHECKING, DISASSEMBLING AND SERVICING [1] CHECKING AND ADJUSTING Toe-in 1. Park the tractor on flat ground. 2. Inflate the tires to the specified pressure. 3. Turn steering wheel so front wheels are in the straight ahead position.
Page 221 L3200, WSM FRONT AXLE Front Axle Rocking Force 1. Jack up the front side of tractor. 2. Set a spring balance to the front axle flange. 3. Measure the front axle rocking force. 4. If the measurement is not within the factory specifications, adjust the adjusting screw (1).
Page 222: Preparation
Front axle case oil Capacity 4.8 U.S.qts 3.9 Imp.qts IMPORTANT • Use KUBOTA SUPER UDT fluid or SAE 80, 90 gear oil. Refer to "LUBRICANTS, FUEL AND COOLANT". (See page G-6.) (1) Drain Plug (3) Check Plug (2) Filling Port Plug...
Page 223 L3200, WSM FRONT AXLE Bumper and Tie-rods 1. Place the disassembling stand under the transmission case. 2. Remove the bumper. 3. Remove the tie-rods with the tie-rod end lifter. In this case, take special care not to damage the tie-rod end nut (slotted nut).
Page 224: Disassembling And Assembling
L3200, WSM FRONT AXLE [3] DISASSEMBLING AND ASSEMBLING Bevel Gear Case and Front Gear Case 1. Remove the bevel gear case mounting screws. 2. Remove the bevel gear case (3) and front gear case (4) as a unit from the front axle case (1).
Page 225 L3200, WSM FRONT AXLE Bevel Gear Case, Axle Flange and Front Gear Case 1. Remove the plug (4). 2. Remove the internal snap ring (3) and shim (2). 3. Remove the axle flange (1). 4. Tap out the bevel gear (6) and ball bearing.
Page 226 L3200, WSM FRONT AXLE Bevel Gear Case Gears 1. Remove the internal snap ring (1). 2. Take out the bevel gears (5), (7) with ball bearings (4), (6), collar (2) and shims (3). (When reassembling) • Install the same shims (3) before they are removed.
Page 227 L3200, WSM FRONT AXLE Spiral Bevel Pinion Shaft and Differential Gear Assembly 1. Take out the differential yoke shaft (11), (12) both sides. 2. Remove the oil seal (6) and internal snap ring (5). 3. Remove the plug (10), and then tap out the spiral bevel pinion shaft (3) with a brass rod and hammer.
Page 228: Servicing
L3200, WSM FRONT AXLE Differential Gear 1. Remove the differential case cover mounting screws (9) and then take out the differential case cover (5), ball bearing (6) and spiral bevel gear (7) as a unit. 2. Remove the external snap ring (8), and then remove the ball bearing (6) and spiral bevel gear (7) as a unit with a puller.
Page 229 L3200, WSM FRONT AXLE Clearance between Pinion Shaft and Differential Pinion 1. Measure the pinion shaft O.D.. 2. Measure the differential pinion I.D. and calculate the clearance. 3. If the clearance exceeds the allowable limit, replace faulty parts. 0.064 to 0.100 mm Factory spec.
Page 230 L3200, WSM FRONT AXLE Backlash between Spiral Bevel Pinion Shaft and Spiral Bevel Gear 1. Set a dial gauge (lever type) with its finger on the spline of spiral bevel pinion shaft. 2. Measure the backlash by moving the spiral bevel pinion shaft by hand lightly.
Page 231 L3200, WSM FRONT AXLE Backlash between 11T Bevel Gear and 42T Bevel Gear 1. Place a strip of fuse to three spots on the 42T bevel gear (1) with grease. 2. Fix the axle flange and front gear case. 3. Turn the axle.
Page 232 L3200, WSM FRONT AXLE Clearance between Front Axle Case Bosses and Bracket Bushings 1. Measure the front axle case bosses O.D. with an outside micrometer. 2. Measure the bracket bushing I.D. with an inside micrometer and calculate the clearance. 3. If the clearance exceeds the allowable limit, replace the bracket bushing.
Page 233 STEERING KiSC issued 12, 2006 A...
Page 234 MECHANISM CONTENTS 1. STRUCTURE ....................7-M1 [1] LINKAGE....................7-M1 [2] STEERING GEAR BOX ................. 7-M2 (1) Structure .................... 7-M2 (2) Operation ................... 7-M3 KiSC issued 12, 2006 A...
Page 235: Structure
L3200, WSM STEERING 1. STRUCTURE [1] LINKAGE (1) Steering Gear Box (2) Joint Shaft 2 (3) Support (4) Mini-Flange (5) Joint Shaft (6) Steering Shaft (7) Bolt W1012968 The integral type power steering is used on this tractor. This steering system is composed of steering wheel, steering joint shafts, steering gear box and other components shown in the figure.
Page 236: Steering Gear Box
L3200, WSM STEERING [2] STEERING GEAR BOX (1) Structure (1) Input Shaft (3) Sleeve (5) Main Shaft (7) Gear Box (2) Torsion Bar (4) Ball Nut (6) Sector Shaft (8) Adjusting Screw This integral power steering mechanism consists of the following two major components as shown above: hydraulic control valve and steering force assist hydraulic cylinder.
Page 237: Operation
L3200, WSM STEERING (2) Operation Neutral Position While the steering wheel is not moved, the torsion bar (2) is not twisted. There is no gap between the input shaft (1) and sleeve (3). This makes no pressure difference between the chambers "a" and "b" of the cylinder, which keeps the ball nut (4) and sector shaft (6) in their positions.
Page 238 L3200, WSM STEERING Manual Operation in Case of Hydraulic System Failure Let's suppose that the hydraulic system fails due to a defective pump, damaged pipe or the like and that the steering resistance is too high to use the power steering system.
Page 239 SERVICING CONTENTS 1. TROUBLESHOOTING ..................7-S1 2. SERVICING SPECIFICATIONS ..............7-S2 3. TIGHTENING TORQUES ................7-S3 4. CHECKING, DISASSEMBLING AND SERVICING........7-S4 [1] CHECKING AND ADJUSTING ...............7-S4 [2] PREPARATION ..................7-S5 (1) Separating Steering Gear Box ............7-S5 [3] DISASSEMBLING AND ASSEMBLING..........7-S7 [4] SERVICING ....................7-S9 KiSC issued 12, 2006 A...
Page 240: Troubleshooting
L3200, WSM STEERING 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Excessive Steering Backlash between sector gear shaft and rack Adjust 7-S9 Wheel Play (piston) too large Steering linkage worn Replace – Sector gear shaft worn Replace 7-S7 Tractor Pulls to Right...
Page 241: Servicing Specifications
L3200, WSM STEERING 2. SERVICING SPECIFICATIONS Item Factory Specification Allowable Limit Steering Wheel Play 20 to 50 mm – 0.79 to 1.97 in. Relief Valve Steering Pressure 11.1 to 12.1 MPa – Condition 113 to 123 kgf/cm • Engine Speed : Approx. 2500 min...
Page 242: Tightening Torques
L3200, WSM STEERING 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Tie-rod end nut 39.2 to 44.1 4.0 to 4.5...
Page 243: Checking, Disassembling And Servicing
L3200, WSM STEERING 4. CHECKING, DISASSEMBLING AND SERVICING [1] CHECKING AND ADJUSTING Steering Wheel Play 1. Turn the front wheels straight ahead. 2. Rotate the steering wheel lightly by hand, and measure the play (A). 3. If the play (A) is not within the factory specifications, turn the adjusting screw (1) to adjust.
Page 244: Preparation
L3200, WSM STEERING [2] PREPARATION (1) Separating Steering Gear Box Joint Shaft 1. Remove the support (3) mounting screw. 2. Remove the screw (1). 3. Remove the joint shaft (2). (When reassembling) • Lift the universal joint so that there is a clearance (A) of more than 5 mm (0.19 in.) between the universal joint and flywheel housing.
Page 245 L3200, WSM STEERING Delivery Pipe and Return Hose 1. Remove the battery and shutter plate. 2. Disconnect the power steering delivery pipe (1) and return hose (2). (When reassembling) 34 to 39 N·m Tightening torque Delivery pipe joint bolt 3.5 to 4.0 kgf·m 25.3 to 28.9 ft-lbs...
Page 246: Disassembling And Assembling
L3200, WSM STEERING [3] DISASSEMBLING AND ASSEMBLING Pitman Arm 1. Turn the input shaft clockwise and counterclockwise several time to drain oil from gear box. 2. Secure the power steering gear box with a vise. 3. Remove the nut and spring washer.
Page 247 L3200, WSM STEERING Valve Assembly 1. Remove the valve mounting screws. 2. Remove the valve assembly (1) and ball nut (2). (When reassembling) • Apply oil to O-ring and oil seal. 48.0 to 55.0 N·m Tightening torque Valve mounting screw 4.9 to 5.7 kgf·m...
Page 248: Servicing
L3200, WSM STEERING [4] SERVICING Backlash between Sector Gear and Ball Nut 1. Set a dial indicator with its finger on the pitman arm. 2. Move the pitman arm lightly, and measure the pitman arm deflection. 3. If the measurement is not within the factory specifications, adjust the backlash with the adjusting screw.
Page 249: Hydraulic System
HYDRAULIC SYSTEM KiSC issued 12, 2006 A...
Page 250 MECHANISM CONTENTS 1. HYDRAULIC CIRCUIT .................. 8-M1 2. POSITION CONTROL VALVE ..............8-M2 3. HYDRAULIC CYLINDER ................8-M4 4. LINKAGE MECHANISM................8-M5 [1] POSITION CONTROL LINKAGE............8-M5 [2] DRAFT CONTROL LINKAGE ..............8-M7 5. FRONT HYDRAULIC BLOCK ..............8-M11 KiSC issued 12, 2006 A...
Page 251: Hydraulic Circuit
L3200, WSM HYDRAULIC SYSTEM 1. HYDRAULIC CIRCUIT (1) Oil Tank (Transmission Case) (2) Oil Strainer (3) Hydraulic Pump (4) Relief Valve (5) Position Control Valve (6) Lowering Speed Adjusting Valve (7) Hydraulic Cylinder (8) Cylinder Safety Valve (9) Draft Control Valve...
Page 252: Position Control Valve
L3200, WSM HYDRAULIC SYSTEM 2. POSITION CONTROL VALVE Neutral Pressurized oil flows at the P port, pushes open unload poppet (2) and returns to the transmission case from T port. The oil in the A chamber (a) behind the unload poppet (2) returns to the transmission case through the clearance between spool (1) and valve body.
Page 253 L3200, WSM HYDRAULIC SYSTEM Lowering When the control lever is moved to DOWN position, spool (1) moves to arrow-mark direction, and poppet 2 (4) is pushed by set screw (5). As the poppet 2 (4) is pushed, an oil circuit of C port to T port is formed.
Page 254: Hydraulic Cylinder
L3200, WSM HYDRAULIC SYSTEM 3. HYDRAULIC CYLINDER (1) Lowering Speed Adjusting (4) Hydraulic Cylinder (8) Hydraulic Rod (12) Position Control Arm Knob (5) O-ring (9) Hydraulic Arm (13) Spool Drive Lever (2) Lowering Speed Adjusting (6) Back-up Ring (10) Hydraulic Arm Shaft...
Page 255: Linkage Mechanism
L3200, WSM HYDRAULIC SYSTEM 4. LINKAGE MECHANISM [1] POSITION CONTROL LINKAGE (1) Position Control Lever (2) Control Arm (3) Control Valve (4) Hydraulic Arm Shaft (5) Lift Arm (6) Spool Drive Lever (7) Spool Joint (8) Feedback Lever Shaft (9) Feedback Lever...
Page 256 L3200, WSM HYDRAULIC SYSTEM Lifting 1. When the position control lever is moved to the LIFT position, the control arm (2) rotates to the arrow. Therefore, the spool drive lever (1) moves around the fulcrum P and pull the spool (3) opening the LIFT circuit.
Page 257: Draft Control Linkage
L3200, WSM HYDRAULIC SYSTEM [2] DRAFT CONTROL LINKAGE Draft control is a system which maintains a constant traction load, and is suited for the work which needs heavy traction load such as plowing. The implement is automatically raised when the traction load is increased, and lowers when the traction load is decreased.
Page 258 L3200, WSM HYDRAULIC SYSTEM Draft Control Operation (1) Draft Control Lever (6) Draft Control Rod (10) Top Link Bracket C : C (Cylinder) Port (2) Lever Guide (7) Top Link Holder (11) Feedback Lever Shaft T : T (Tank) Port...
Page 259 L3200, WSM HYDRAULIC SYSTEM (1) Draft Control Lever (6) Draft Control Rod (10) Top Link Bracket C : C (Cylinder) Port (2) Lever Guide (7) Top Link Holder (11) Feedback Lever Shaft T : T (Tank) Port (3) Control Lever Shaft...
Page 260 L3200, WSM HYDRAULIC SYSTEM (1) Draft Control Lever (6) Draft Control Rod (10) Top Link Bracket C : C (Cylinder) Port (2) Lever Guide (7) Top Link Holder (11) Feedback Lever Shaft T : T (Tank) Port (3) Control Lever Shaft...
Page 261: Front Hydraulic Block
L3200, WSM HYDRAULIC SYSTEM 5. FRONT HYDRAULIC BLOCK (1) Cap A : To Implement Control Valve C : To Position Control Valve : To Transmission Case (2) Front Hydraulic Block B : From Implement Control P : From Hydraulic Valve...
Page 262 SERVICING CONTENTS 1. TROUBLESHOOTING ..................8-S1 2. SERVICING SPECIFICATIONS ..............8-S2 3. TIGHTENING TORQUES ................8-S5 4. CHECKING, DISASSEMBLING AND ASSEMBLING ........8-S6 [1] CHECKING AND ADJUSTING ...............8-S6 (1) Hydraulic Pump Test Using Flow-meter (Power Steering) ....8-S6 (2) Relief Valve (Power Steering) .............8-S8 (3) Hydraulic Pump Test Using Flow-meter (Three Point Hydraulic System) ....................8-S8 (4) Relief Valve (for Three Point Hydraulic System).......8-S10 [2] DISASSEMBLING AND ASSEMBLING..........8-S13...
Page 263: Troubleshooting
L3200, WSM HYDRAULIC SYSTEM 1. TROUBLESHOOTING Reference Symptom Probable Cause Solution Page Implement Does Not Control linkage improperly adjusted Adjust 8-S11, S12 Rise (Without Noise) Control linkage improperly assembled or Repair or replace 8-S11, S12, damaged S19, S20 Position control valve malfunctioning...
Page 264: Servicing Specifications
L3200, WSM HYDRAULIC SYSTEM 2. SERVICING SPECIFICATIONS POWER STEERING HYDRAULIC PUMP Item Factory Specification Allowable Limit Hydraulic Pump Delivery at No Above – Condition Pressure 14.5 L/min. • Engine speed : 3.83 U.S.gals/min. Approx. 2500 min (rpm) 3.19 Imp.gals/min. • Rated Pressure : 11.1 to 12.1 MPa...
Page 265 L3200, WSM HYDRAULIC SYSTEM THREE POINT SYSTEM HYDRAULIC PUMP Item Factory Specification Allowable Limit Hydraulic Pump Delivery at No Above – Condition Pressure 23.9 L/min. • Engine speed : 6.31 U.S.gals./min. Approx. 2500 min (rpm) 5.26 Imp.gals./min. • Rated Pressure : 15.7 to 16.7 MPa...
Page 266 L3200, WSM HYDRAULIC SYSTEM HYDRAULIC CYLINDER Item Factory Specification Allowable Limit Cylinder Bore I.D. 75.000 to 75.050 mm 71.150 mm 2.9528 to 2.9547 in. 2.9587 in. Hydraulic Arm Shaft to Bushing Clearance (Right) 0.125 to 0.230 mm 0.50 mm 0.00492 to 0.00906 in.
Page 267 L3200, WSM HYDRAULIC SYSTEM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Relief valve plug 49.0 to 68.6 5.0 to 7.0...
Page 268: Checking, Disassembling And Assembling
L3200, WSM HYDRAULIC SYSTEM 4. CHECKING, DISASSEMBLING AND ASSEMBLING [1] CHECKING AND ADJUSTING (1) Hydraulic Pump Test Using Flow-meter (Power Steering) Preparation 1. Remove the support (3) mounting screw. 2. Remove the screw (1). 3. Remove the joint shaft (2).
Page 269 L3200, WSM HYDRAULIC SYSTEM Hydraulic Flow Test IMPORTANT • When using a flowmeter other than KUBOTA specified flowmeter, be sure to use the instructions with that flowmeter. • Do not close the flowmeter loading valve completely, before testing, because it has no relief valve.
Page 270: Relief Valve (Power Steering)
L3200, WSM HYDRAULIC SYSTEM (2) Relief Valve (Power Steering) Relief Valve Setting Pressure 1. Disconnect the power steering delivery pipe joint bolt. 2. Install the adaptor E and adaptor 58 of relief valve setting pressure tester to the regulator valve, and then connect the threaded coupler of the test hose and pressure gauge.
Page 271 L3200, WSM HYDRAULIC SYSTEM Hydraulic Flow Test IMPORTANT • When using a flowmeter other than KUBOTA specified flowmeter, be sure to use the instructions with that flowmeter. • Do not close the flowmeter loading valve completely, before testing, because it has no relief valve.
Page 272: Relief Valve (For Three Point Hydraulic System)
L3200, WSM HYDRAULIC SYSTEM (4) Relief Valve (for Three Point Hydraulic System) Relief Valve Setting Pressure 1. Remove the delivery pipe joint bolt from front hydraulic block. 2. Install the adaptor E. Then connect the hose and pressure gauge to adaptor E.
Page 273 L3200, WSM HYDRAULIC SYSTEM Position Control Feedback Rod Adjustment 1. Set the position control lever (1) to the lowest position. 2. Start the engine, and after warming-up, set the engine speed to idle. 3. Move the position control lever (1) to the uppermost position.
Page 274 L3200, WSM HYDRAULIC SYSTEM Draft Control Rod Adjustment 1. Attach the weights (2) of 490 N (50 kgf, 110 lbs) to the end of lower link or linkage drawbar. 2. Start the engine, and after warming-up, set the engine speed at maximum.
Page 275: Disassembling And Assembling
L3200, WSM HYDRAULIC SYSTEM [2] DISASSEMBLING AND ASSEMBLING (1) Hydraulic Pump (Power Steering) Hydraulic Pump Assembly 1. Remove the side cover. 2. Remove the steering joint shaft (3). 3. Disconnect the suction hose (1). 4. Disconnect the return hose (2).
Page 276: Hydraulic Pump (Three Point Hydraulic System)
L3200, WSM HYDRAULIC SYSTEM Hydraulic Pump Running-in After reassembly, perform break-in operation in the following manner, and check the pump for abnormality before use. If the pump temperature should rise noticeably during running-in, recheck should be performed. 1. Install the hydraulic pump to the tractor, and mount the suction pipe and delivery pipe securely.
Page 277: Hydraulic Cylinder
L3200, WSM HYDRAULIC SYSTEM Hydraulic Pump Assembly 1. Remove the pump cover mounting screw (7). 2. Remove the drive gear (6), driven gear (2) and side plate (3) from the casing. (When reassembling) • Take care not to damage the gasket.
Page 278 L3200, WSM HYDRAULIC SYSTEM Outer Components 1. Remove the seat (1). 2. Remove the grips (2), (4), (7) and (8). 3. Remove the range gear shift lever guide (3) and hydraulic lever guide (6). 4. Remove the center cover (5).
Page 279 L3200, WSM HYDRAULIC SYSTEM Lowering Speed Adjusting Valve 1. Remove the lowering speed adjusting valve from hydraulic cylinder block. 2. Tap out the spring pin (8), and remove the grip (5). 3. Remove the internal snap ring (4), and remove the hydraulic adjusting shaft (2).
Page 280 L3200, WSM HYDRAULIC SYSTEM Lift Arm, Hydraulic Arm and Hydraulic Arm Shaft 1. Disconnect the position control rod from feedback lever. 2. Remove the lift arm setting screws. 3. Draw out the hydraulic arm shaft (5) and right lift arm (6) as a unit.
Page 281: Position Control Valve
L3200, WSM HYDRAULIC SYSTEM (4) Position Control Valve Position Control Valve 1. Loosen and remove the position control valve mounting screws. 2. Remove the position control valve (1). (When reassembling) • Take care not to damage the O-rings. 23.6 to 27.4 N·m...
Page 282 L3200, WSM HYDRAULIC SYSTEM IMPORTANT • Set screw (3) and spool joint 1 (2) are adjusted to very close accuracy. Do not disassemble them unless necessary. If disassembled due to unavoidable reasons, be sure to make the following adjustments before assembling.
Page 283: Draft Control Valve
L3200, WSM HYDRAULIC SYSTEM (5) Draft Control Valve Removing Draft Control Valve 1. Removing the draft control lever (1). 2. Disconnect the draft control rod from the draft control valve (2). 3. Remove the draft control valve (2). (When reassembling) •...
Page 284: Relief Valve
L3200, WSM HYDRAULIC SYSTEM (6) Relief Valve Relief Valve 1. Remove the plug (9), and draw out the spring (5) and the poppet (4). 2. Remove the valve seat (3). (When reassembling) • Take care not to damage the O-ring.
Page 285: Servicing
L3200, WSM HYDRAULIC SYSTEM [3] SERVICING (1) Hydraulic Pump (Power Steering) Housing Bore (Depth of Scratch) 1. Check for the scratches on the interior surface of the housing caused by the gear. 2. If the scratches reach more than half the area of the interior surface of the housing, replace the pump assembly.
Page 286: Hydraulic Pump (Three Point System)
L3200, WSM HYDRAULIC SYSTEM (2) Hydraulic Pump (Three Point System) Housing Bore (Depth of Scratch) 1. Check for the scratches on the interior surface of the housing caused by the gear. 2. If the scratches reach more than half the area of the interior surface of the housing, replace the pump assembly.
Page 287: Hydraulic Cylinder
L3200, WSM HYDRAULIC SYSTEM (3) Hydraulic Cylinder Hydraulic Cylinder Bore 1. Check the cylinder internal surface for scoring or damage. 2. Measure the cylinder I.D. with a cylinder gauge. 3. If the measurement exceeds the allowable limit, replace. 75.000 to 75.050 mm Factory spec.
Page 288: Electrical System
ELECTRICAL SYSTEM KiSC issued 12, 2006 A...
Page 289 MECHANISM CONTENTS 1. WIRING DIAGRAM ..................9-M1 KiSC issued 12, 2006 A...
Page 290 L3200, WSM ELECTRICAL SYSTEM 1. WIRING DIAGRAM Head Lamp Head Lamp Flasher Unit Key Stop Coolant Key Stop Starter (R.H.) (L.H.) Brake Lamp Front Combination Solenoid Temperature Lamp Relay Solenoid Relay Fuel Level Switch Relay Glow Plug Front Combination Sensor Lamp (R.H.)
Page 291 SERVICING CONTENTS 1. TROUBLESHOOTING ..................9-S1 2. SERVICING SPECIFICATIONS ..............9-S5 3. TIGHTENING TORQUES ................9-S6 4. CHECKING, DISASSEMBLING AND SERVICING........9-S7 [1] CHECKING AND ADJUSTING ...............9-S7 (1) Battery....................9-S7 (2) Main Switch..................9-S8 (3) Safety Switch ..................9-S10 (4) Starter and Starter Relay ..............9-S10 (5) Glow Control System ................9-S11 (6) Engine Stop Solenoid ...............9-S12 (7) Charging System ................9-S13 (8) Combination Switch ................9-S14...
Page 292 L3200, WSM ELECTRICAL SYSTEM 1. TROUBLESHOOTING FUSE AND WIRING Reference Symptom Probable Cause Solution Page All Electrical Battery discharged or defective Recharge or replace 9-S7 Equipment Do Not Battery positive cable disconnected or Repair or replace 9-S7 Operate improperly connected...
Page 293 L3200, WSM ELECTRICAL SYSTEM LIGHTING SYSTEM Reference Symptom Probable Cause Solution Page Head Light Does Not Fuse blown (25 A) Replace G-30 Light Bulb blown Replace G-30 Wiring harness disconnected or improperly Repair or replace – connected (between main switch AC terminal...
Page 294 L3200, WSM ELECTRICAL SYSTEM LIGHTING SYSTEM (Continued) Reference Symptom Probable Cause Solution Page Licence Plate Light Fuse blown (15A) Replace G-30 Does Not Light Bulb blown Replace G-30 Wiring harness disconnected or improperly Repair or Replace – connected (between main switch AC terminal...
Page 295 L3200, WSM ELECTRICAL SYSTEM GAUGES Fuel Gauge Does Not Fuel level sensor (tank unit) defective Replace 9-S20 Function Wiring harness disconnected or improperly Repair or Replace – connected (between panel board and fuel level sensor) Circuit in panel board defective Replace –...
Page 296: Servicing Specifications
L3200, WSM ELECTRICAL SYSTEM 2. SERVICING SPECIFICATIONS STARTER MOTOR Item Factory Specification Allowable Limit Commutator O.D. 29.0 mm 28.0 mm 1.14 in. 1.10 in. Mica Undercut 0.50 to 0.80 mm 0.20 mm 0.020 to 0.031 in. 0.008 in. Brush Length 16 mm 12.0 mm...
Page 297 L3200, WSM ELECTRICAL SYSTEM 3. TIGHTENING TORQUES Tightening torques of screws, bolts and nuts on the table below are especially specified. (For general use screws, bolts and nuts : See page G-7.) Item N·m kgf·m ft-lbs Alternator pulley nut 58.3 to 78.9 5.95 to 8.05...
Page 298: Checking, Disassembling And Servicing
L3200, WSM ELECTRICAL SYSTEM 4. CHECKING, DISASSEMBLING AND SERVICING CAUTION • To avoid accidental short circuit, be sure to attach the positive cable to the positive terminal before the negative cable is attached to the negative terminal. • Never remove the battery cap while the engine is running.
Page 299: Main Switch
L3200, WSM ELECTRICAL SYSTEM Battery Specific Gravity 1. Check the specific gravity of the electrolyte in each cell with a hydrometer. 2. When the electrolyte temperature differs from that at which the hydrometer was calibrated, correct the specific gravity reading following the formula mentioned in (Reference).
Page 300 L3200, WSM ELECTRICAL SYSTEM Main Switch Key at OFF Position 1. Turn the main switch off. 2. Measure the resistance with an ohmmeter across the B terminal and the AC terminal, B terminal and ST terminal, and B terminal and G terminal.
Page 301: Safety Switch
L3200, WSM ELECTRICAL SYSTEM (3) Safety Switch Safety Switch Continuity 1. Remove the safety switch leads. 2. Connect the circuit tester to the safety switch leads. 3. Measure the resistance between leads. 4. If the safety switch is defective, replace it.
Page 302: Glow Control System
L3200, WSM ELECTRICAL SYSTEM Magnet Switch Test 1. Disconnect the battery negative cable from the battery. 2. Disconnect the battery positive cable and the leads from the starter M terminal. 3. Remove the starter from the engine. 4. Disconnect the connecting lead (1) from the starter C terminal (2).
Page 303: Engine Stop Solenoid
L3200, WSM ELECTRICAL SYSTEM Glow Plug Continuity 1. Disconnect the lead from the glow plugs. 2. Measure the resistance between the glow plug terminal and the chassis. 3. If 0 ohm is indicated, the screw at the tip of the glow plug and the housing are short-circuited.
Page 304: Charging System
L3200, WSM ELECTRICAL SYSTEM Glow Relay (Lamp Relay / Key Stop Solenoid Relay) 1. Turn the main switch off. 2. Disconnect the 4P connector from glow relay. 3. Measure the voltage across the terminal 3 (Positive) and chassis (Negative). 4. If the voltage differs from the battery voltage, the wiring harness is faulty.
Page 305: Combination Switch
L3200, WSM ELECTRICAL SYSTEM No-Load Test 1. Connect the 2P connector (6) to previous positions of the alternator after turning the main switch “OFF”. 2. Connect the jumper lead (3) between IG terminal (4) and B terminal (2). 3. Start the engine and then set at idling speed.
Page 306 L3200, WSM ELECTRICAL SYSTEM 1) Connector Voltage 1. Connect the combination switch connector to the main wire harness. 2. Measure the voltage with a voltmeter between the connector B1 terminal (2) and chassis when the main switch is “ON” position.
Page 307 L3200, WSM ELECTRICAL SYSTEM 3) Head Light Switch Continuity when Setting Switch in HI- BEAM Position 1. Set the light switch in “HI-BEAM” position. 2. Measure the resistance with an ohmmeter between the B1 terminal (1) and the T terminal (2), the B1 terminal (1) and the 1 terminal (3).
Page 308 L3200, WSM ELECTRICAL SYSTEM 5) Turn Signal Light Switch Continuity When Setting Switch Knob in OFF Position 1. Set the flasher switch knob in “OFF: position. 2. Measure the resistance with an ohmmeter between the B2 terminal (1) and the R terminal (2), the B2 terminal (1) and the L terminal (3).
Page 309: Hazard Switch
L3200, WSM ELECTRICAL SYSTEM 7) Turn Signal Light Switch Continuity When Setting Switch Knob in “LEFT TURN” Position 1. Set the flasher switch knob in “LEFT TURN” position. 2. Measure the resistance with an ohmmeter between the B2 terminal (1) and the L terminal (2), the B2 terminal (1) and the R terminal (3).
Page 310: Parking (Position) Switch
L3200, WSM ELECTRICAL SYSTEM Hazard Switch Continuity 1. Measure the resistance with ohmmeter between the terminal a and terminal c, between the terminal d and terminal e. 2. If measurement is not the same as the following, the hazard switch or the bulb is faulty.
Page 311: Flasher (Hazard) Unit
L3200, WSM ELECTRICAL SYSTEM (11) Flasher (Hazard) Unit Flasher (Hazard) Unit 1. Disconnect the connector from the flasher unit. 2. Turn the main switch at “ON” position 3. Measure the voltage between the terminal 12 and chassis. 4. If the voltage differs from the battery voltage, the wiring harness is faulty.
Page 312: Brake Light Switch
L3200, WSM ELECTRICAL SYSTEM (14) Brake Light Switch Brake Light Switch Continuity 1. Remove the brake light switch (1). 2. Connect the ohmmeter leads to the brake light switch terminals. 3. Measure the resistance between terminals. 4. If the measurement value is not the same as follows, the brake light switch is faulty.
Page 313 L3200, WSM ELECTRICAL SYSTEM 1) Turning Signal Terminals 1. Turn the main switch “ON”, and measure the voltage with voltmeter across the 1 terminal (1) and 3 terminal (2), and across the 4 terminal (3) and 3 terminal (2). 2. If the voltage differs from the battery voltage, the wiring harness or switches for turning signal are faulty.
Page 314: Disassembling And Assembling
L3200, WSM ELECTRICAL SYSTEM [2] DISASSEMBLING AND ASSEMBLING (1) Starter Disassembling Motor 1. Disconnect the connecting lead (9) from the magnet switch (8). 2. Remove the screws (6), and then separate the end frame (4), yoke (2) and armature (1).
Page 315 L3200, WSM ELECTRICAL SYSTEM Rear End Cover 1. Unscrew the three rear end cover screws and the B terminal nut, and remove the rear end cover. W10189820 Brush Holder 1. Unscrew the two screws holding the brush holder, and remove the brush holder (1).
Page 316 L3200, WSM ELECTRICAL SYSTEM Rotor 1. Press out the rotor (1) from drive end frame (3). IMPORTANT • Take special care not to drop the rotor and damage the slip ring or fan, etc.. (1) Rotor (3) Drive End Frame...
Page 317: Servicing
L3200, WSM ELECTRICAL SYSTEM [3] SERVICING (1) Starter Overrunning Clutch 1. Inspect the pinion for wear or damage. 2. If there is any defect, replace the overrunning clutch assembly. 3. Check that the pinion turns freely and smoothly in the overrunning direction and does not slip in the cranking direction.
Page 318 L3200, WSM ELECTRICAL SYSTEM Brush Holder 1. Check the continuity across the brush holder and the holder support with an ohmmeter. 2. If it conducts, replace the brush holder. Brush holder - Holder Resistance Infinity support W1017672 Armature Coil 1. Check the continuity across the commutator and armature coil core with an ohmmeter.
Page 319: Alternator
L3200, WSM ELECTRICAL SYSTEM (2) Alternator Bearing 1. Check the bearing for smooth rotation. 2. If it does not rotate smoothly, replace it. W10197900 Stator 1. Measure the resistance across each lead of the stator coil with an ohmmeter. 2. If the measurement is not within factory specification, replace it.
Page 320 L3200, WSM ELECTRICAL SYSTEM Rectifier 1. Check the continuity across each diode of rectifier with an analog ohmmeter. Conduct the test in the (R × 1) setting. 2. The rectifier is normal if the diode in the rectifier conducts in one direction and does not conduct in the reverse direction.
Page 321 EDITOR : KUBOTA FARM & INDUSTRIAL MACHINERY SERVICE, LTD. 64, ISHIZU-KITAMACHI, SAKAI-KU, SAKAI-CITY, OSAKA, 590-0823, JAPAN PHONE : ( 81 ) 72-241-1129 : ( 81 ) 72-245-2484 E-mail : ksos-pub@kubota.co.jp Printed in Japan 2006. 09, S, EI, EI, e Code No.9Y011-13601 KUBOTA Corporation 2006.

Kubota L3200 Workshop Manual

General

1 Tractor Indentification

2 General Precautions

3 Handling Precautions for Electrical Parts and Wiring

4 Lubricants, Fuel and Coolant

5 Tightening Torques

6 Maintenance

7 Check and Maintenance

8 Special Tools

9 Tires

Mechanism

1 Features

2 Fuel System

3 Lubricating System

4 Cooling System

Servicing

Servicing

Servicing

Servicing

1 Troubleshooting

2 Tightening Torques

3 Disassembling and Servicing

Servicing

Servicing

Mechanism

Servicing

Mechanism

Servicing

1 Troubleshooting

2 Servicing Specifications

4 Checking, Disassembling and Assembling

Servicing

2 Servicing Specifications

4 Checking, Disassembling and Servicing

Quick Links

Chapters

Troubleshooting

Related Manuals for Kubota L3200

Summary of Contents for Kubota L3200
