L3540, L4240, L5040, L5240, L5740, WSM
Model
Model
Type
Number of cylinders
Total displacement
Bore and stroke
Engine
Net power*
PTO power*
(factory observe)
Maximum torque
Battery capacity
Fuel
Fuel tank
Engine crankcase
(with filter)
Capacities
Engine coolant
Transmission case
Overall length
(without 3P)
Overall width (min. tread)
Overall height
Dimensions
Wheel base
Min. ground clearance
Front
Tread
Rear
Weight
Front
Standard
tire size
Rear
Clutch
Travelling Steering
system
Transmission
Braking system
Min. turning radius
(with brake)
Hydraulic control system
Pump capacity
Three point hitch
Hydraulic
At lift points
system
Max. lift
24 in. behind
force
lift points
System pressure
Rear PTO
PTO
PTO / Engine speed
Note : * Manufacture's estimate
The company reserves the right to change the specifications without notice.
Rear ROPS
Indirect injection vertical, water-cooled, 4-cycle diesel
2.434 L (148.5 cu.in.)
87 × 102.4 mm (3.4 × 4.0 in.)
33.6 kW (45.6 PS) / 2600 min
180.6 N·m (18.42 kgf·m, 13.8 lbf·ft)
12 V, RC : 133 min, CCA : 582 A
Diesel fuel No. 1 [below −10 °C (14 °F], Diesel fuel No. 2-D [above −10 °C (14 °F)]
54 L (14.3 U.S.gals, 11.9 Imp.gals)
9.4 L (9.9 U.S.qts, 8.3 Imp.qts)
8.2 L (8.7 U.S.qts, 7.2 Imp.qts)
45 L (11.9 U.S.gals, 9.9 Imp.gals)
3245 mm (127.8 in.)
1470 mm (57.87 in.)
2550 mm (100.4 in.)
1915 mm (75.55 in.)
1125 mm (44.3 in.), 1225 mm (48.2 in.), 1325 mm (52.2 in.)
1765 kg (3891 lbs)
Dry type single stage
Hydrostatic power steering
Hydrostatic transmission (3 speeds)
35.6 L (9.4 U.S.gals, 7.83 Imp.gals) / min.
17.7 MPa (180 kgf/cm
SAE 1-3/8, 6 splines
540 min
11
L5240
HST
CABIN
V2403-M-TE3-EU2
4
38.7 kW (52.6 PS)
−1
(rpm)
2375 mm (93.5 in.)
400 mm (15.7 in.)
1135 mm (44.7 in.)
1920 kg (4233 lbs)
9.5-16
13.6-28
Wet disk type
3.2 m (10 feet)
Position control
SAE Category 1, 2
1750 kg (3860 lbs)
1350 kg (2980 lbs)
2
, 2560 psi)
−1 −1
(rpm) / 2590 min (rpm)
SPECIFICATIONS
W10281170
