ENGINE BODY (Continued)
Balancer Shaft Journal 1 to Balancer Shaft
Bearing 1 (Balancer Model Only)
Balancer Shaft Journal 1
Balancer Shaft Bearing 1
Balancer Shaft Journal 2 to Balancer Shaft
Bearing 2 (Balancer Model Only)
Balancer Shaft Journal 2
Balancer Shaft Bearing 2
Balancer Shaft Journal 3 to Balancer Shaft
Bearing 3 (Balancer Model Only)
Balancer Shaft Journal 3
Balancer Shaft Bearing 3
Idle Gear Shaft to Idle Gear Bushing
Idle Gear Shaft
Idle Gear Bushing
Camshaft
Cam
D1803-M
V2203-M
V2403-M-TE3-EU1
V2403-M-TE3-EU2
V2403-M-TE3-EU3
Camshaft Journal to Cylinder Block Bore
Camshaft Journal
Cylinder Block Bore
Item
Clearance
O.D.
I.D.
Clearance
O.D.
I.D.
Clearance
O.D.
I.D.
Clearance
O.D.
I.D.
Alignment
Height
(Intake)
Height
(Intake / Exhaust)
Clearance
O.D.
I.D.
1-S6
Factory Specification
0.030 to 0.111 mm
0.00119 to 0.00437 in.
43.934 to 43.950 mm
1.7297 to 1.7303in.
43.980 to 44.045 mm
1.7315 to 1.7340 in.
0.030 to 0.111 mm
0.00119 to 0.00437 in.
41.934 to 41.950 mm
1.6510 to 1.6515 in.
41.980 to 42.045 mm
1.6528 to 1.6553 in.
0.020 to 0.094 mm
0.00079 to 0.0037 in.
21.947 to 21.960 mm
0.86406 to 0.86456 in.
21.980 to 22.041 mm
0.86536 to 0.86775 in.
0.025 to 0.066 mm
0.00099 to 0.0025 in.
37.959 to 37.975 mm
1.4945 to 1.4950 in.
38.000 to 38.025 mm
1.4961 to 1.4970 in.
–
33.90 mm
1.335 in.
33.90 mm
1.335 in.
33.27 mm
1.310 in.
33.47 mm
1.318 in.
0.050 to 0.091 mm
0.0020 to 0.0035 in.
39.934 to 39.950 mm
1.5722 to 1.5728 in.
40.000 to 40.025 mm
1.5748 to 1.5757 in.
ENGINE
Allowable Limit
0.20 mm
0.0079 in.
–
–
0.20 mm
0.0079 in.
–
–
0.20 mm
0.0079 in.
–
–
0.10 mm
0.0039 in.
–
–
0.01 mm
0.0004 in.
33.85 mm
1.333 in.
33.85 mm
1.333 in.
33.22 mm
1.308 in.
33.42 mm
1.316 in.
0.15 mm
0.0059 in.
–
–
