Specifications - Kubota L3540 Workshop Manual

L3540, L4240, L5040, L5240, L5740, WSM

SPECIFICATIONS

Model
Model
Type
Number of cylinders
Total displacement
Bore and stroke
Engine
Net power*
PTO power*
(factory observe)
Maximum torque
Battery capacity
Fuel
Fuel tank
Engine crankcase
(with filter)
Capacities
Engine coolant
Transmission case
Overall length
(without 3P)
Overall width (min. tread)
Overall height
Dimensions
Wheel base
Min. ground clearance
Front
Tread
Rear
Weight
Front
Standard
tire size
Rear
Clutch
Travelling Steering
system
Transmission
Braking system
Min. turning radius
(with brake)
Hydraulic control system
Pump capacity
Three point hitch
Hydraulic
At lift points
system
Max. lift
24 in. behind
force
lift points
System pressure
Rear PTO
PTO
PTO / Engine speed
Note : * Manufacture's estimate
The company reserves the right to change the specifications without notice.
Manual Transmission
Rear ROPS
Indirect injection vertical, water-cooled, 4-cycle diesel
87 × 102.4 mm (3.4 × 4.0 in.)
22.0 kW (29.9 PS) / 2700 min
101.7 N·m (10.37 kgf·m, 75.01 lbf·ft)
12 V, RC : 133 min, CCA : 582 A
Diesel fuel No. 1 [below −10 °C (14 °F], Diesel fuel No. 2-D [above −10 °C (14 °F)]
44.0 L (11.6 U.S.gals, 9.68 Imp.gals)
5.7 L (6.0 U.S.qts, 5.0 Imp.qts)
6.0 L (6.3 U.S.qts, 5.3 Imp.qts)
42.0 L (11.1 U.S.gals, 9.24 Imp.gals)
2415 mm (95.08 in.)
360 mm (14.2 in.)
1110 mm (43.70 in.), 1205 mm (47.44 in.), 1300 mm (51.18 in.), 1385 mm (54.53 in.)
7-16
12.4-24
Hydrostatic power steering
F8, R8 fully synchronized main and shuttle transmission
Position control
31.5 L (8.3 U.S.gals, 6.9 Imp.gals) / min.
17.7 MPa (180 kgf/cm
540 min
750 min
8
L3540
Center ROPS
D1803-M-E2-EU1
3
1.826 L (111.4 cu.in.)
25.9 kW (35.2 PS)
−1
(rpm)
3015 mm (118.7 in.)
1430 mm (56.30 in.)
2265 mm (89.17 in.)
1805 mm (71.06 in.)
380 mm (15.0 in.)
1150 mm (45.28 in.)
1470 kg (3241 lbs)
260 / 70R16
360 / 70R24
Dry type single stage
Wet disk type
2.7 m (8.9 feet)
Position and draft control
SAE Category 1
1700 kg (3750 lbs)
1200 kg (2650 lbs)
2
, 2560 psi)
SAE 1-3/8, 6 splines
−1 −1
(rpm) / 2550 min (rpm),
−1 −1
(rpm) / 2550 min (rpm)
