Summary of Contents for GPO Display Panoramic Display
-
Page 1: User Guide
Panoramic Display User Guide Before operating the unit, please read this manual thoroughly, and retain it for future reference... - Page 2 “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product. www.gpodisplay.com Panoramic Display...
- Page 3 19. Note: Prolonged use of headphones at a high volume may cause damage your ears. 20. Notice to users : This is a Class A digital device 21. This device is designed for commercial use and features safety certificates for electromagnetic interference (EMI). Users should be mindful of EMI issues. www.gpodisplay.com Panoramic Display...
- Page 4 •Ventilation space in front of Product must be furnished for heat dispersion. If the front space of Product has to be sealed, there must be consideration for the heat dispersion in the rear side of Product. www.gpodisplay.com Panoramic Display...
- Page 5 5. RIGHT : Controls the RIGHT cursor in the menu 6. DOWN : Controls the DOWN cursor in the menu 7. ENTER : Controls the ENTER cursor in the menu 8. MENU : Displays the main On-Screen menu 9. EXIT : Exits the On-Screen menu www.gpodisplay.com Panoramic Display...
- Page 6 While the desired menu option is selected, press ENTER to move to the second level. d. Press ENTER to move to the third level: Some menu options require additional steps. e. Press MENU to return to the previous menu or press EXIT on the Remote Control to return to monitor viewing. www.gpodisplay.com Panoramic Display...
- Page 7 From this point on, the on-screen menus will be shown in the selected language. d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. Supported Languages : English, French, Italian, Portuguese, Russian, Chinese, etc. www.gpodisplay.com Panoramic Display...
- Page 8 Press the MENU button and then ◀/▶button to select each menu. b. Press the ENTER button and then use ▲/▼ button to display the available menus. • Your monitor's OSD (On Screen Display) may differ slightly from what is shown in this manual. www.gpodisplay.com Panoramic Display...
- Page 9 Contrast, Brightness, Color, Sharpness, Tint. d. Press ENTER button and then use ◀/▶ buttons to make appropriate adjustments. e. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 10 Press the ENTER button and then use ▲/▼ buttons to select desired option: Auto, 4:3, 16:9, Zoom1, Zoom2, Just Scan. d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 11 Press the ▲/▼ buttons and then use ENTER button to select Screen Menu. c. Press ▲/▼ buttons and then use ◀/▶ buttons to make desired adjustments. d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 12 Press the ◀/▶ button and then use ▲/▼ button to select - User menu : Treble, Bass. d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 13 Press the ▲/▼ buttons and then use ENTER button to select the Auto Volume menu. c. Press ENTER button to make desired adjustments : On, Off d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu www.gpodisplay.com Panoramic Display...
- Page 14 Press the ENTER button and then use ◀/▶ buttons to make desired adjustments; 20Hz, 500Hz, 1.5KHz, 5KHz, 10KHz. d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 15 Press the ▲/▼ buttons to select the SET ID Menu. c. Press the ENTER button and then use ◀/▶ buttons to select SET ID options. d. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 16 Press the ENTER button and then use ▲/▼ buttons to select the Show Effect Menu. d. Press the ◀/▶ buttons to set Show Effect options. e. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 17 Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. ON : Dim level is adjusted by light sensor OFF : Dim level is adjusted by manual control www.gpodisplay.com Panoramic Display...
- Page 18 Press the ▲/▼ buttons to select the Min Ambient functions. e. Use ◀/▶ buttons to set detected light ambient value by LUX unit. f. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 19 Press the ENTER button and then use ▲/▼ buttons to select the Active Temperature Menu. d. Use ◀/▶ buttons to set fan driving temperature by Celsius degree unit. e. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 20 Press the ▲/▼ buttons to select Restore Factory Default menu c. Press the ENTER button and then use ▲/▼ button to make a selection in the Are you sure? menu. d. Press the ◀/▶ buttons and then monitor’s www.gpodisplay.com Panoramic Display...
- Page 21 Press the ENTER button to select the Details Menu : Off, 5sec, 10sec, 15sec 9) Software Update (USB) When downloading software via USB memory.a. Press the MENU button and then use - Must be new version software (merge.bin) in USB memory www.gpodisplay.com Panoramic Display...
- Page 22 Press the ENTER button and then use ▲/▼ buttons to select Clock. c. Press the ▲/▼ buttons to select the Hour, Minute. d. Use ◀/▶ buttons to adjust clock. e. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 23 Press the ▶ button and then use ◀/▶ buttons to select the On, OFF. d. Use ▲/▼ buttons, ◀/▶ buttons to adjust off time schedule and activation. e. Press EXIT button to return to monitor viewing or press MENU button to return to the previous menu. www.gpodisplay.com Panoramic Display...
- Page 24 Press the ENTER button to see the Play menu. * The menu will be showed during playing the contents * To Auto play, save the content (Video & Photo) in the memory USB stick and turn power off and on the monitor. www.gpodisplay.com Panoramic Display...
- Page 25 The USB memory stick should not have any other file except the files that will be played. If there are any unrelated files, there may be interruptions. If the content format is not supported by the media board, it will not play the content. This type is Recommended. www.gpodisplay.com Panoramic Display...
- Page 26 (Bit rate) Vorbis ~48KHz (Sampling rate) only support stereo decoding Image Photo Size Base-line 15360 X 8704 (1920x8 X 1088x8) JPEG Progressive 1024 X 768 Photo non-interlace 9600 X 6400 interlace 1200 X 800 9600 X 6400 www.gpodisplay.com Panoramic Display...
- Page 27 720x576 31.250 50.00 26.566 1280x720 44.964 59.94 74.176 1280x720 37.500 50.00 60.466 1920x1080 33.750 60.00 74.25 Interlaced 1920x1080 28.125 50.00 70.723 Interlaced 1920x1080 31.250 50.00 72.000 Interlaced 1920x1080 67.500 60.00 148.500 Progressive 1920x1200 74.000 60.00 154.000 Progressive www.gpodisplay.com Panoramic Display...
