BETCO BPS28 Instruction Manual

28” battery powered sweeper
Hide thumbs Also See for BPS28:

Advertisement

Quick Links

BPS28 28" Battery Powered Sweeper
Parts Schematic
Item #89001
©Betco Corporation. All Rights Reserved • 1001 Brown Avenue • P.O. Box 3127 • Toledo, Ohio 43607-0127 • 800-777-9343 • www.betco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPS28 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BETCO BPS28

  • Page 1 BPS28 28” Battery Powered Sweeper Parts Schematic Item #89001 ©Betco Corporation. All Rights Reserved • 1001 Brown Avenue • P.O. Box 3127 • Toledo, Ohio 43607-0127 • 800-777-9343 • www.betco.com...
  • Page 2: Table Of Contents

    INDEX BPS-28 ..General information and key ....Page 1 1.1 ..Safety Warning ......Page 1 1.2 .
  • Page 3: Safety Warning

    GENERAL INFORMATION – KEY Indications such as RIGHT or LEFT, CLOCKWISE or COUNTER-CLOCKWISE used in this booklet relate to the forward movements of the machine. This symbol draws your attention top operations that could cause damage to the machine if NOTE improperly executed.
  • Page 4: Machine Registration Sheet

    Do not use a jet of water to wash the machine. The machine must not be used for the recovery of toxic or hazardous substances. The machine can only work in presence of light. NEVER LEAVE the machine with the key in the dashboard unattended. In case the machine is being used in a place where there is a danger for falling little objects, a helmet must be worn by the operator.
  • Page 5: Foreword

    1.5 FOREWORD The purpose of this manual is to inform the operator of the basic rules, safety rules and criteria which must be observed when using, adjusting and maintaining the machine. The machine has been developed and has been developed and manufactured to ensure excellent performance and the utmost comfort and ease of operation in a variety of working conditions.
  • Page 6: Controls

    2.2 PREPARING THE BATTERY The battery must be prepared before it is mounted on the machine. This simple precaution will prevent the machine from being damaged by the electrolytic liquid of the battery. Always prepare the battery in a sufficiently ventilated environment. Do not smoke or use flames during this operation (see the section on battery maintenance).
  • Page 7: Correct Operation

    4.2 CORRECT OPERATION After you have become familiar with the operations required to start the machine, you can actually start using the sweeper. To obtain the best results, it is always wise to take a few precautions. These will help you to get the best from your machine and reduce damage to a minimum.
  • Page 8: Routine Maintenance

    NOTE 5.1 ROUTINE MAINTENANCE ALL ROUTINE MAINTENANCE AND SPECIAL MAINTENANCE MUST BE CARRIED OUT BY COMPETENT PERSONNEL OR BY AN AUTHORIZED SERVICE CENTER .ALWAYS USE ORIGINAL SPARE PARTS. ATTENTION: ALL MAINTENANCE OPERATIONS MUST BE CARRIED OUT WITH THE MACHINE OFF. CHECK Check the battery liquid The belts for slackening...
  • Page 9: Filter Maintenance

    5.3 FILTER MAINTENANCE CLEANING THE FILTER The filter is one of the machine main components. It is essential for the best results from your machine. If you notice that dust forms when the machine is at work, check the filter. The filter is cleaned as follows: A.
  • Page 10: Replacing And Adjusting The Side Brush

    5.4 REPLACING AND ADJUSTING THE SIDE BRUSH REPLACING After lifting the front part of the machine, replace the side brush by loosening the brush fixing screw and removing the brush. Replace the brush and secure the new one in place with the screw and its washer. ADJUSTING The side brush is adjusted by loosening screws and using the slots to position the brush at the required height.
  • Page 11: Replacing And Adjusting The Belts

    5.6 REPLACING AND ADJUSTING THE BELTS To prepare the machine for belt replacement, carry out the following operations: -Remove the top bonnet and the front bin. -After removing the right wheel, loosen the screws that secure the bumper and right side guard in place and remove the latter.
  • Page 12 5.7 REPLACING THE FLAPS 5.7.1 OUTER SIDE FLAPS To replace the side flaps (#1, Fig. 7), remove the rear wheels and the relevant side guards. Loosen the screws that secure the flaps to frame (#2, Fig. 7) and replace the old flaps with new ones. 5.7.2 INNER SIDE FLAPS To replace the inner side flaps (#5, Fig.
  • Page 13 5.8 REPLACING THE TRACTION CABLE 5.8.1 REMOVE THE TRACTION CABLE AS FOLLOWS: - Open the upper hood of the machine. - Lift the security dowel located on the cable fixing pin. - Open the traction handle casing. - Pull the cable out of the fixing pin and remove the adjusting screw mounted on the handle. - Press the handle and pull the cable out of its sheath.
  • Page 14: Wiring Diagram

    6.1 WIRING DIAGRAM — 12 —...
  • Page 15: Trouble Shooting

    6.2 TROUBLESHOOTING Trouble Cause Remedy The main brush is not spinning.....The belt is broken............Replace The motoriduct has burnt out ........Replace A wire is detached............Check The side brush is not spinning....The belt is broken............Replace The battery does not stay charged ..The liquid is insufficient ..........Top-off The terminal is loose ...........Tighten Dust comes out of the fan......The filter is broken............Replace The filter is in the wrong position ........Position correctly...
  • Page 16 — 2 —...
  • Page 17 Ref. Part No. Description Qty. 1. 2120417 Upper cover 2. 2300405 Fixing screw 3. 1105220 Block nut M8 4. 2300111 Locking 5. 2310097 Complete handle 6. 1105325 Washer 6x24x2 7. 1105361 Screw 6.3x19 8. 2120422 Front drawer 9. 2110402 Bushing 10.
  • Page 18 — 4 —...
  • Page 19 Ref. Part No. Description Qty. Ref. Part No. Description Qty. 2125017B Side brush sheathing 1105420 Outer snap ring Ø12 2310454 Traction handle 2230029 Brush adjusting fixing pivot 1105229 Turned adjuster Ø7 2190005 Main brush adjustment bracket 1125005 Sidebrush drive lever 2105001 Side arm felt washer 1105162...
  • Page 20 — 6 —...
  • Page 21 Ref. Part No. Description Qty. 1. 2120084 Wheel cover Ø200 2. 1105234 Screw 6x10 3. 1105325 Washer 6x24 4. 1105418 Outer snap ring Ø28 5. 1390016 Bearing HFL 1426 6. 2110033 Exagonal bushing 7. 1390015 Bearing HK 1412 8. 2250071 Wheel Ø250x55 black / black 2250086 Wheel Ø250x55 grey / black...
  • Page 22 — 8 —...
  • Page 23 Ref. Part No. Description Qty. 1. 6911400 Dashboards plate 2. 13801001 Keyswitch 3. 1380009 Bipolar switch 4. 1105363 Screw 5x20 5. 1380008 Batt. charger connector 6. 2180009 12V motor blocking driving 7. 2160107 Left side flap grey 2160060 Left side flap black 8.
