Intex CS8110 Owner's Manual

Krystal clear saltwater system
Hide thumbs Also See for CS8110:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
(131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5" X 10.3" PANTONE 295U 06/28/2013
Krystal Clear
Saltwater System
Model CS8110
For illustrative purposes only.
Don't forget to try these other fine Intex products: Pools, Pool
Accessories, Inflatable Pools and In-Home Toys, Airbeds and
Boats available at fine retailers or visit our website listed below.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance,
which may result in updates to the instruction manual without
notice.
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, Visit
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
Monday through Friday, 8:30am to 5:00pm Pacific Time
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
IMPORTANT!
www.intexcorp.com
1-800-234-6839
English
English
131
131
®
131-***-R0-1406

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS8110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intex CS8110

Summary of Contents for Intex CS8110

  • Page 1 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English English IMPORTANT SAFETY RULES Read, understand, and follow all instructions carefully before installing and using this product. Krystal Clear ® Saltwater System Model CS8110 For illustrative purposes only.

  • Page 2: Table Of Contents

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English TABLE OF CONTENTS Warnings................3 Parts References..............4-5 Product Information & Specifications........ 6 Setup Instructions..............7-11 Salt & Pool Water Volumes...........12 Intex Pools Salt Table............13 Intex Pools Cyanuric Acid Table..........14 Intex Pools Operating Time Table........15...

  • Page 3: Warnings

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities.

  • Page 4: Parts References

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.

  • Page 5: Parts References

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. REF. NO. SPARE PARTS FOR...

  • Page 6: Product Information & Specifications

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English HOW THE CHLORINE IS GENERATED This product is specially designed for above ground pools. It will destroy the bacteria, oxidize bather organics and control algae, which provide a safe, clean and comfortable swimming pool.

  • Page 7: Setup Instructions

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS IMPORTANT • The Saltwater System requires a separate filter pump [700~4000 gph (2650~15140 lph)] to drive the water and function properly. • The Saltwater System must be installed as the last piece of pool equipment in the water return line to the pool as displayed in Drawing #1.
  • Page 8 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS (continued) 1. Go directly to step 2 if your pool is empty. If your above-ground-pool is filled with water, unscrew the strainer grids from the strainer connectors and insert the black hat-like plugs into the connectors, before installing the saltwater pool system.
  • Page 9 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS (continued) Connecting the system to pump and pool with 1-1/2” (38mm) connections/hoses: Pump and pool with 1-1/2” (38mm) connections do not require the adaptors A (1) or B (9).
  • Page 10 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS (continued) Connecting the system to other types of pump (with different type of thread or no thread): The Saltwater System can also be adapted to other filter pumps with different thread or those without a thread on the connection.
  • Page 11 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SETUP INSTRUCTIONS (continued) Connecting the system to other types of pool After you have connected the Saltwater System to the pump, connect it to the pool. This is depicted in Drawings #1 and #2.

  • Page 12: Salt & Pool Water Volumes

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SALT & POOL WATER VOLUMES • Which kind of salt to use: Use only Sodium Chloride Salts Use only sodium chloride (NaCl) salt that is at least 99.8% pure. It is also acceptable to use water conditioning salt pellets (the compressed forms of evaporated salt).

  • Page 13: Intex Pools Salt Table

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English INTEX POOLS SALT TABLE This table shows the amount of salt needed to achieve and maintain the optimal 3000 ppm salt level. Water Capacity (Calculated at Salt Needed for...

  • Page 14: Intex Pools Cyanuric Acid Table

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English INTEX POOLS CYANURIC ACID TABLE Cyanuric acid is a chemical that reduces the loss of chlorine in water due to ultraviolet rays. To maintain the pool water clear and clean, and to maximize the performance of the device, add cyanuric acid to the pool.

  • Page 15: Intex Pools Operating Time Table

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English INTEX POOLS OPERATING TIME TABLE (WITH CYANURIC ACID) Operating Time (hours) Water Capacity (Calculated at Intex Filter at different ambient/air 90% for Frame Pool and 80% pump temperatures for Easy Set &...

  • Page 16: Non-Intex Pools Salt Table

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English SALT CALCULATION FORMULA FOR ALL POOLS Salt Needed for Startup Salt Needed for Startup Salt Needed when Salt Needed when (Lbs) (Kgs) Low Salt Detected (Lbs) Low Salt Detected (Kgs) Water Capacity (Gals) x 0.025 Water Capacity (Liters) x 0.003...

  • Page 17: Operating Instructions

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English OPERATION INSTRUCTIONS 1. Turn on the filter pump. 2. Start up the unit: Plug the power cord into the electrical outlet and test the GFCI/RCD (circuit breaker).
  • Page 18 For example, the boost operating time is 8 hours, the filter pump should be set to run for 8 hours at least. Increase the filter pump operating time if necessary. Note: If an Intex filter pump is attached to the system, set the pump switch to on “I” position.

  • Page 19: Led Code Chart

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English LED CODE CHART LED Reading Definitions Boost Mode Stand-By Mode (Start-up) Minimum Operating Hour (1 hour remaining) Operating Hours (2 hours remaining) Operating Hours (3 hours remaining)

  • Page 20: Maintenance

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English MAINTENANCE IMPORTANT Unplug the power cord before cleaning your system. Also close the plunger valves on your pool or insert the black hat-like plugs in the strainer opening to prevent water spillage.
  • Page 21 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English MAINTENANCE (continued) 3. Disconnect the 2 hoses from the Saltwater System, and assemble the cell cover (10) at each side of the cell. 4. In a counter-clockwise motion, unscrew the collar of the copper electrode (5) and remove it from the electrolytic cell (4).

  • Page 22: Long Term Storage

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English MAINTENANCE (continued) INTEX COPPER ION TEST STRIPS (PACKED WITH THE PRODUCT) ® The Copper Ion Test Strips can be used to test the copper ion concentration in the water.

  • Page 23: Pool Maintenance And Chemical Definitions

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English POOL MAINTENANCE & CHEMICAL DEFINITIONS Preferred Water Chemistry Reading Minimum Ideal Maximum Copper Ions 0.1 - 0.2 ppm 0.2 ppm Free Chlorine 0.5 - 3.0 ppm 5.0 ppm...

  • Page 24: Troubleshooting Guide

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English TROUBLESHOOTING GUIDE PROBLEM CAUSE SOLUTION • Increase the daily Saltwater System • Insufficient operating hours of INSUFFICIENT operating time. See “Operating Instructions”. the Saltwater System. CHLORINE • Check the salt level with the Test Kit. Adjust •...
  • Page 25 (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English TROUBLESHOOTING GUIDE (continued) LED PANEL SOLUTION PROBLEM CODE LED Panel Code Flash & Alarm On (NOTE: Always turn off the power before cleaning and servicing). 1. Filter pump not attached to •...

  • Page 26: General Aquatic Safety

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions.

  • Page 27: Limited Warranty

    (131) MODEL CS8110 SALTWATER SYSTEM ENGLISH 7.5” X 10.3” PANTONE 295U 06/28/2013 English LIMITED WARRANTY ® Your Krystal Clear Saltwater System has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only ®...
