1.9

Space requirements

1.9 Space requirements
To ensure that machine operation, consumables replenishing, part replacement, and regular maintenance
can easily be performed, adhere to the recommended space requirements detailed below.
25-7/8 (658)
5-7/8
(150)
7-5/8
(194)
4-3/16
(107)
NOTICE
Be sure to allow a clearance of 3-15/16 inches (100 mm) or more at the back of this machine for the ventilation
duct.
ineo 223/283/363/423
64-5/16 (1634)
38-7/16 (976)
ineo 423/363/283/223+DF-621+PC-208+FS-527+SD-509
51-15/16 (1320)
38-7/16 (976)
ineo 423/363/283/223+DF-621+PC-208+FS-529
42-5/8 (1083)
38-7/16 (976)
ineo 423/363/283/223+DF-621+PC-208+JS-505
46-3/4 (1187)
11-9/16
32-13/16 (834)
(293)
3-15/16
(100)
Unit: inch (mm)
46-3/4 (1187)
11-9/16
32-13/16 (834)
(293)
3-15/16
(100)
Unit: inch (mm)
46-3/4 (1187)
11-9/16
32-13/16 (834)
(293)
3-15/16
(100)
Unit: inch (mm)
1
1-25
