- Page 1 RF Robotic Pool Cleaner Installation and Operating Instructions Product 11716 BK0019022_PA Product Inst 353...
-
Page 2: Important Safety Instructions
Dear Customer, IMPORTANT SAFETY INSTRUCTIONS Thank you for choosing our product to clean your pool. We hope that you will enjoy using your new robot to maintain your swimming pool for years to come. READ AND FOLLOW ALL THE INSTRUCTIONS Before you begin to use your robot, please take a few minutes to carefully read these operating instructions. - Page 3 Operating the pool cleaner 1. Place the power supply (transformer) at least 3.6 meters / 11.8 feet from the pool and at 4. Plug the cable into the power supply. Make sure the key on the plug corresponds least 12 cm / 4 Inch above the surface (fig.1). The transformer will supply low voltage to exactly with the key slot on the socket of the power supply (fig.
- Page 4 Operating the pool cleaner Grounding Plugs Type II The power supply must be connected to a grounded 3 conductor socket. The mains power supply To plug the cable (Fig A) into the socket on the power supply (Fig. B), please do the must be connected via a GFCI (ground fault circuit interrupter) or RCD (residual current device) having a rated residual operating current not greater than 30mA.
-
Page 5: Maintenance And Adjustment
Operating the pool cleaner a. Power LED The blue LED flashes when the power supply is in standby mode and lights continuously when the pool cleaner is operating.The power button switches between ON and STANDBY b. "POWER" button The button switches between "ON" and "STANDBY". IMPORTANT- After every cycle the pool cleaner will automatically go to "standby". - Page 6 Maintenance and adjustment CLEAN THE FILTER BAG AFTER EVERY CLEANING CYCLE a. Unplug the power supply. (Please keep the plug away from contact with water) b. If the unit is in the pool, gently pull the cleaner toward you using the cable until the handle is within reach. Use the handle (not the cable) to pull the cleaner out of the pool smooth smooth...
-
Page 7: Important Tips
Maintenance and adjustment Screws Filter bag 30°C / 85°F outlet top propeller label (continued from the previous page) d. Remove the filter bag from the support bars, turn it inside out and wash off all the dirt Cleaning the pump propeller: with a garden hose or in a sink. -
Page 8: Troubleshooting Guide
Troubleshooting Guide PLEASE CHECK THE FOLLOWING BEFORE CALLING YOUR SERVICE CENTER Before troubleshooting, the pool cleaner must be disconnected from the power supply and the power supply must be unplugged from the electrical outlet to prevent damage to the unit and possible personal injury. For reference numbers, consult the parts list diagram located on the last page of the instructions. -
Page 10: Warranty Terms And Conditions
WARRANTY TERMS AND CONDITIONS Astral Pool Australia Pty Ltd (ABN 97 007 284 504) ("Astral Pool") provides the following warranty in relation to its Robotic Pool Cleaners. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. -
Page 11: Warranty Claims
WARRANTY CLAIMS 1.If a fault covered by warranty occurs, the customer must first contact AstralPool at the contact address listed below, or an Authorised AstralPool Service Agent. 2. Any warranty claim must be accompanied by: (a) proof of purchase; (b) full details of the alleged defect; and (c) appropriate documentation (such as historical and maintenance records). -
Page 12: Exclusions And Limitations
EXCLUSIONS AND LIMITATIONS EXCLUSIONS The warranty will not apply where: the customer is in breach of the Terms and Conditions of Sale; the Product was used for a purpose other than one it was intended for; the Product was repaired, modified or altered by any person other than AstralPool; the Product has not been installed, maintained and/or operated in complete compliance with the installation and operating instructions and any instructions by AstralPool;... - Page 16 Melbourne Townsville Sydney Seven Hills Sydney Moorebank 39-45 Cyber Loop 17 Auscan Crescent 2/2 Welder Road 6/30 Heathcote Road Dandenong VIC 3175 Garbutt QLD 4814 Seven Hills NSW 2147 Moorebank NSW 2170 P: 03 8796 8600 P: 07 4796 0100 P: 02 9853 2100 P: 02 8778 9500 Adelaide...
