Planning the installation
Contents
These installation instructions describe how to install
your 45HOM Mortise Lock. Topics covered include:
Planning the installation...........................................1
Preparing the door and door jamb..........................4
Installing the lock........................................................7
Completing the installation......................................9
Site survey
Use the following survey to record information
about the installation site. You need this information
to determine how to prepare the door for the lock.
Door information
Door handing and bevel:
If a handing change is required, see "Rotate latchbolt
(if necessary)" on page 4.
❐ Left hand (LH)
❐ Left hand, reverse bevel (LHRB)
❐ Right hand (RH)
❐ Right hand, reverse bevel (RHRB)
Door thickness: 1-3/4 to 2 inches (44 to 50 mm).
Environment information
Side of
Model
door
Standard Outside
Weatherized Outside
Outside
Extreme
a
Weatherized
Inside
a. See Stanley installation instruction Addendum (T83317)
Extreme Weatherized Installation for the extreme weatherized
model installation.
T83312/Rev A 000000 ER-7991-12 Jan 2010
Temperature
Exposure
Range
Drip proof.
Inadvertent
+32°F to +129°F
splashing of
0°C to +54°C
water spray
acceptable.
-4°F to +129°F Direct exposure
-20°C to +54°C to rain and snow
-40°F to +129°F Direct exposure
-40°C to + 54°C to rain and snow
+32°F to +129°F
N/A
0°C to +54°C
a Product Group of Stanley Security Solutions, Inc.
Installation Instructions for
Stanley Omnilock 45HOM
Mortise Locks
Components checklist
Use the following checklist to make sure that you
have the items necessary to install your Omnilock
Mortise Lock.
Components provided in the box:
❐ Inside and outside trim cassettes
❐ Inside and outside rose and rose ring
❐ Outside escutcheon assembly
❐ Mortise case assembly
❐ Mortise cylinder and collar
❐ Outside lever and spindle assembly
❐ Inside lever
❐ Strike package
❐ Installation template and instructions
❐ Screw package
❐ Mortise case faceplate
❐ Batteries
❐ Torx T15 driver
❐ 1/8" hex wrench
Other components:
❐ Programming Default ID Card (provided with
software)
Stanley Omnilock 1
