Summary of Contents for Gree NEO09HP230V1AH
- Page 1 Technical Product Guide MULTI WaLL MoUnT UnITs Models: NEO09HP230V1AH NEO12HP230V1AH NEO18HP230V1AH...
-
Page 2: Table Of Contents
Table of Contents Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3 Features and Benefits . -
Page 3: Product Overview
When laying out a new project, you’ll appreciate the flexibility of Gree’s Multi Zone Systems. A single outdoor unit can simultaneously power up to five indoor units while eliminating expensive ductwork. Without those ducts, your installation is simpler, faster and more cost-effective. -
Page 4: Product Overview
Condensate Water Too High troubleshooting and shorten repair times. Outdoor Coil Sensor Failure Flexible Design Gree’s Multi Zone systems have many advantages One outdoor unit for both the property owner and the installer. can power up to Up to five indoor units, powered by a single 5 indoor units. -
Page 5: Features And Benefits
LCD display. Tether Controller (optional) The Gree tether controller mounts to the wall up to 25 feet from the unit. It provides complete control over operation mode, desired temperature, fan speed, airflow direction and more. - Page 6 The filters are washable and permanent. self-Diagnosis With an on-board computer using real-time diagnostics, the Gree Multi Zone system helps to prolong its own life. The automatic diagnosis feature continuously scans for unacceptable operating conditions or malfunctions. If such conditions occur, the system takes corrective action or stops.
-
Page 7: Product Nomenclature
+Multi Wall Mount Units NOMENCLATURE HP 230V 1 A H Series Designation NEO - Neo Indoor High Wall MULTI - Multiple Port Outdoor Unit Product Type DUCT - Slim Duct Indoor Unit S - System CAS - Ceiling Cassette O - Outdoor Units FLR - Floor/Ceiling Unit H - Indoor High Wall CONS - Mini Console... -
Page 8: Product Performance Data
PERFORMANCE SPECIFICATIONS & DATA Indoor High Wall Units COOLING CAPACITY HEATING CAPACITY DEHUMIDIFICATION MODEL NUMBER (BtuH) (BtuH) (Pts./hr.) NEO09HP230V1AH 9,000 9,800 NEO12HP230V1AH 12,000 13,000 NEO18HP230V1AH 18,000 19,800 Indoor High Wall Units MODEL NUMBER AIR FILTER TYPE AIR FLOW FAN TYPE... -
Page 9: Sound Data
SOUND SOUND SOUND SOUND SOUND SOUND POWER PRESSURE POWER PRESSURE POWER PRESSURE POWER PRESSURE NEO09HP230V1AH 42 dBA 32 dBA 45 dBA 35 dBA 48 dBA 38 dBA 52 dBA 42 dBA NEO12HP230V1AH 43 dBA 33 dBA 46 dBA 36 dBA... -
Page 10: Dimensional Specifications
DIMENSIONAL SPECIFICATIONS Model no: nEo09HP230V1aH 9,000 BtuH Model no: nEo12HP230V1aH 12,000 BtuH 7.1 (180) 10.8 (275) Suction/Gas Line Port Size Port 1 3/8-in OD Flared Liquid Line Port Size Port 1 1/4-in OD Flared Drain Connector Drain Line 0.625-in OD... -
Page 11: Limited Warranty Statement
NEO12HP230V1AH NEO18HP230V1AH GREE distributor (hereinafter “Company”) warrants this product against failure due to defect in materials or workmanship under normal use and maintenance as follows. All warranty periods begin on the date of original installation. If the date cannot be verified, the warranty period begins one hundred twenty (120) days from date of manufacture. - Page 12 LIMITATIONS OF WARRANTIES All implied warranties and/or conditions (including implied warranties or conditions of merchantability and fitness for a particular use or purpose) are limited to the duration of this limited warranty, some states or provinces do not allow limitations on how long an implied warranty or condition lasts, so the above may not apply to you.
- Page 13 Specifications in this booklet are subject to change without notice. Manufacturer reserves the right to discontinue or modify specifications or designs without notice or without incurring obligations. All rights reserved. Cat# +MULTI-HW-1TPG Version: Original © 2014 Gree Electric Appliance, Inc.
