10.2.5 LANGUAGE

You can adjust the following languages as defaults for the TIMY3
•
<GERMAN>
•
<ENGLISH>
•
<FRENCH>
•
<ITALIAN>
•
<SPANISH>
•
<SCHWEDISH>

10.2.6 STANDARD

Reset the TIMY3 to the factory defaults.
•
<STANDARD-SETT>

10.2.7 HARDWARE

This menu is only available for our service technicians.

10.2.8 HARDWARE 2

This menu is only available for our service technicians.

10.2.9 PROGS ON OFF

As standard all programs are activated. The programs that are not used can be hidden to re-
duce the select list. Hidden programs can be activated any time in this menu again.

10.3 CHANNELS

Configuration of the timing channels:

10.3.1 INTERNAL

10.3.1.1 DELAY TIME
The delay time of the internal timing channels c0, c1, c2, c3, c4, c5, c6, c7 and c8 can be set.
Delay time is the time after which the channel is blocked after an impulse, to prevent multiple
impulses (see point 5.2).
•
<DELAY START C0>
•
<DELAY C1-C8>
•
<DELAY C1>
•
<DELAY C2>
•
<DELAY C3>
•
<DELAY C4>
•
<DELAY C5>
•
<DELAY C6>
•
<DELAY C7<
•
<DELAY C8>
10.3.1.2 0.1s-CORRECTION
If impulses are transmitted by the TED or an external WTN, the 0.1 seconds delay can here
automatically be corrected for every channel. This function is not adjustable at the TIMY3
when the internal WTN is activated as the correction is then automatically activated.
10.3.1.3 EDGE
This is for setting of triggering the impulses either on closing and/or opening. Standard for all
channels is on closing.
Manual
TIMY3 - General
standard is 1.00 second
standard is 0.30 second
not always available!
Page 21
