- Page 1 OWNER’S MANUAL FOR ELECTRIC RIDE-ON VEHICLES This manual contains important safety, performance and maintenance information. Read the manual before taking your first ride on your new ride-on vehicle, and keep the manual handy for future reference. REGISTER your bike online at www.dynacraftwheels.com...
- Page 2 OWNER’S MANUAL 6V BMW S1000RR MOTORCYCLE this manual contains important safety performance and maintenance information read the manual before taking your first ride or allowing your child to ride your new electric ride on toy keep the manual handy for future reference DO NOT return this item to the store.
-
Page 3: Table Of Contents
TABLE OF CONTENTS A Introduction, Safety and Warnings B Before You Begin Assembly C Parts Diagram D Assembly E How to Use Your Vehicle F Detailed Maintenance and Repair G Troubleshooting Guide H Warranty ELECTRIC CAR SPECIFICATIONS SUITABLE AGE CAPACITY Up to 65 lb (29 5 kg) SPEED 3 MPH... -
Page 4: A Introduction, Safety And Warnings
INTRODUCTION, SAFETY AND WARNINGS ABOUT THIS MANUAL: This Manual was written to help you and your child get the most performance, comfort, enjoyment and safety when riding your new electric ride-on toy. It is important for you to understand your new electric ride-on toy. - Page 5 RIDER USE AND REQUIRED PARENTAL SUPERVISION RIDERS MUST NOT EXCEED THE WEIGHT LIMIT OF 65 LB (29.5 KG) AND MUST BE OVER 3 YEARS OLD. The age grade for the electric ride-on toy is for 3 years and older. Just because your child is within the age and weight limitations specified for the electric ride- on toy, does not mean that his/her size is appropriate to fit or maintain control of the electric ride-on toy, or that he/she is capable of safely operating the electric...
- Page 6 SAFE RIDING PRACTICES AND WARNINGS • Check and obey all local laws or regulations which may be in effect in the locations where the electric ride-on toy may be used. • Always wear appropriate clothing and shoes. • Observe the age and weight limitations on the cover of this manual. •...
- Page 7 • Do not to allow hands, feet, hair, body parts, clothing, or similar articles to come in contact with wheels or other moving parts. • Before each cycle of operation, you must perform the preoperation checks specified in this manual or by the manufacturer, including: –...
-
Page 8: B Before You Begin Assembly
BEFORE YOU BEGIN ASSEMBLY WARNING: Remove all packing and items from the display box. Make sure that the power switch is turned "OFF" before assembling the electric ride-on toy. ESTIMATED ASSEMBLY TIME You should allow approximately 35 minutes for assembly, not including initial charging time. -
Page 9: C Parts Diagram
PARTS DIAGRAM Tools Required Screwdriver (not included) Socket Wrench (included) NOTE: Some parts shown are assembled on both sides of vehicle. Vehicle Body Assembly x 1 Tail light x 1 M10 Locknut x 1 Rear License Plate 4 x 12 Machine Screw x 9 10 Bolt x 1 View Mirror x 2 11 Training Wheel x 2... -
Page 10: D Assembly
ASSEMBLY Your new vehicle requires adult assembly. Please set aside around 30 minutes for assembly. Please identify all parts before assembly and save all packaging material until assembly is completed to ensure that no parts are discarded. TOOLS REQUIRED: Phillips Screwdriver 17mm Socket Wrench (not included) (included) - Page 11 2. SIDE VIEW MIRROR ASSEMBLY NOTE: Identify the left and right mirrors for assembly. 4 x 12 Round • Insert the side view mirror into the hole in Head Screw the front of the vehicle body as shown. • Insert and tighten the 4 x12 round head screw with a screwdriver.
- Page 12 • Non-rechargeable batteries should not be recharged. • Use only batteries of the same or equivalent type as recommended. • Rechargeable batteries are used, they should only be charged under adult supervision. • Remove rechargeable batteries from the product before charging. •...
- Page 13 BATTERY CHARGING IMPORTANT! Before first time use, charge the battery for at least 18 hours. Charge the battery for at least 12 hours after each use of the vehicle. Never charge the battery longer than 30 hours. Overcharging or undercharging the battery may shorten battery life and decrease vehicle running time.
- Page 14 • Do not charge the battery on a surface (such as a kitchen counter top) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you charge your battery. • Use only an original charger (AC 120V 60Hz) with an output of DC 6V (1A) to charge your vehicle battery.
-
Page 15: E How To Use Your Vehicle
HOW TO USE YOUR VEHICLE Sound button Power switch Foot pedal POWER SWITCH Turn the vehicle on and off. FOOT PEDAL Push the foot pedal to start moving. The vehicle will stop automatically when your child’s foot is removed from the foot pedal. SOUND BUTTON Press to play sounds. -
Page 16: Safety Precautions
IMPORTANT • Your new battery must be charged for at least 18 hours before you use it in your vehicle for the first time. • Always stop vehicle when changing the direction to avoid damage to the gears and motor. •... -
Page 17: F Detailed Maintenance And Repair
DETAILED MAINTENANCE AND REPAIR Turn the power “OFF” before conducting any maintenance procedures. Flat head Screwdriver 17mm Socket Wrench TOOLS REQUIRED: (not included) (included) HOW TO REPLACE THE BATTERY 1. Turn the lock knob on the seat to “unlock” position, and remove the seat. 2. - Page 18 HOW TO REPLACE THE POWER SWITCH Power switch +Mark Wire Red Wire Flat Head screwdriver Black Wire 1. Remove the power switch with a flat head screwdriver. 2. Unplug the main connector from the wire terminals as shown in the photo. 3.
-
Page 19: Battery Care And Disposal
BATTERY CARE AND DISPOSAL Do not store the battery in temperatures above 75° F (23.5° C) or below 32° F (0°C). THIS PRODUCT CONTAINS SEALED LEAD ACID BATTERIES WHICH MUST BE RECYCLED IN ACCORDANCE TO YOUR LOCAL AND STATE LAWS PLEASE CAREFULLY READ AND UNDERSTAND THE FOLLOWING DISPOSAL INSTRUCTIONS: DISPOSAL: This product contains sealed lead acid batteries which must be... - Page 20 MAINTAINING YOUR VEHICLE Occasionally use a lightweight oil to lubricate moving parts such as wheels and the steering linkages. Park the vehicle indoors or cover to protect it from wet weather. Keep the vehicle away from sources of heat, such as stoves and heaters. Plastic parts may melt.
-
Page 21: Troubleshooting Guide
If your battery is old or if you have not followed Battery Care instructions, your battery may be dead. Replace only with an original 6 Volt (7 Amp/ Hr.) battery. Do not use non-original substitute parts. Motor damage Visit the Dynacraft website and replace with a new motor. www.dynacraftwheels.com... - Page 22 Replace only with an original 6 Volt (4 Amp/Hr.) battery. Do not use non-original substitute parts. Motor damage Visit the Dynacraft website and replace with a new motor. www.dynacraftwheels.com Tripped fuse The fuse may “trip” and shut down operation of the vehicle if the vehicle is overloaded or the driving conditions are too severe.
- Page 23 Problem Possible Cause Solution Vehicle runs Undercharged battery Charge the battery. A new battery should have sluggishly been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 12 hours after each use.
-
Page 24: H Warranty
Dynacraft shall not have any responsibility for any resulting break down of the ride-on toy or its components, or for any rider injuries... - Page 25 Dynacraft Customer Service 1-800-288-1560 7AM to 4PM Pacific Standard Time DO NOT return this item to the store. STOP Please call Dynacraft for assistance. Please have the following information available when you call: Model Number: (sample: 8802-33) Production Date: (sample: 03.03.2015)
- Page 26 Please visit dynacraftwheels.com for more information. Or call Customer Service at 1-800-288-1560, 7AM to 4PM PST. Please have the following information available when you call: Model Number: (example: 8XXX-XX) Production Date: (example: 2014.XX.XX) Serial Number: (example: XXXXXXXXXXX) 2015 Printed in China...
