3. With the help of a second person, place some
of the packing materials (not shown) under the
front of the Frame (1). Have the second per-
son hold the Frame to prevent it from tipping
while you complete this step.
Attach the Front Stabilizer (3) to the Frame (1)
with two M10 x 115mm Screws (104).
Remove the packing materials from under the
front of the Frame (1).
4. Orient the Upright (4) and the Upright Cover (23)
as shown. Slide the Upright Cover upward onto
the Upright.
While a second person holds the Upright (4)
near the Frame (1), connect the Upper Wire
(116) to the Lower Wire (115).
Insert the excess wire into the Frame (1).
3
1
4
8
104
3
4
23
116
1
115
