Model No. CDV-50A
User's Guide
Thank you for purchasing our COMMAX product.
Please carefully read this User's Guide (in particular, precautions for safety)
before using the product and follow the instructions to use your productexactly.
- 1 -
The company is not responsible for any safety accidents caused in abnormal
operation of the product.
Advertisement
Table of Contents
Related Manuals for Commax CDV-50A
Summary of Contents for Commax CDV-50A
- Page 1 Color Video Doorphone Model No. CDV-50A User’s Guide Thank you for purchasing our COMMAX product. Please carefully read this User’s Guide (in particular, precautions for safety) before using the product and follow the instructions to use your productexactly. - 1 - The company is not responsible for any safety accidents caused in abnormal operation of the product.
-
Page 2: Table Of Contents
Contents 1. Location ………………………………………………………………………… - Front view - Rear view 2. Product Usage ………………………………………………………………… - Visitor Call - Talking to the Interphone - Monitoring 3. Installation Method …………………………………………………………… - 1) Monitor Installation - 2) Standard Height of Monitor - 3) Wiring Diagram 4. -
Page 3: Location
1. Location ▶ Front view ① ② ③ ⑧ ④ ⑨ ⑤ ⑩ ⑥ ⑪ ⑦ ⑫ ⑬ ⑭ Rear view ▶ ⑮ ⒃ ⒔ ⒕ L.E.D Indicator Release open Button Power OFF/ON ① ⑦ ⑬ C-Microphone Volume adjust controller Speaker ②... -
Page 4: Product Usage
2. Product Usage Visitor Call ● 1. When a visitor presses the “Call” button on the door camera installed at the entrance, the monitor rings a chime bell and shows the visitor. At this time, the monitor LED will blink. 2. -
Page 5: Installation Method
3. Installation Method 1) Monitor Installation 2) Standard Height of Monitor 3) Wiring Diagram CDV-50A White Yellow Interphone Blue White Yellow CAMERA2 Blue White Yellow CAMERA1 Blue... -
Page 6: Part List
4. Part list Monitor …………………………………………………………………………… 1 unit Bracket for monitor ………………………………………………………………… 1 unit Connect connector ………………………………………………………………… 2 unit Fixed screw for bracket …………………………………………………………… 2 unit Fixed screw for monitor bracket …………………………………………………… 2 unit Manual …………………………………………………………………………… 1 unit... -
Page 7: Specifications
5” Color TFT-LCD Power Consumption Stand by 3Watts Operating 13Watts Transmitted Method Door : 4 wires (Polarity) Calling Sound Commax Chime Video Receiving Time 90±20 seconds Communication Distance For 0.65mm cable 50m Operating Temperature -10℃ ~ +40℃ Operating Humidity Less than 90% Dimensions (W/H/D) mm 245 X 175 X 45.6 mm... - Page 8 Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133 Web site : www.commax.com Printed In Korea...
