Specifications

● General
Rated power source .................. 14.4 V DC
(allowable voltage range:
12.0 V to 14.4 V DC)
Grounding system .............Negative type
Maximum current consumption ... 10.0 A
Dimensions (W × H × D):
DIN
Chassis ....................... 178 mm × 100 mm
× 157 mm
Nose............................ 188 mm × 118 mm
D
Chassis ....................... 178 mm × 100 mm
× 164 mm
Nose.............................. 171 mm × 97 mm
Weight ...............................................2.2 kg
● Display
Screen size/aspect ratio ............ 6.95 inch
wide/16:9
(effective display area:
156.6 mm × 81.6 mm)
Pixels ....................1 152 000 (2 400 × 480)
Display method ........... TFT Active matrix
Color system .......................... PAL/NTSC/
PAL-M/PAL-N/SECAM compatible
Tolerable temperature range:
Power off .........................–20 °C to +80 °C
● Audio
Maximum power output ............ 50 W × 4
Continuous power output ......... 22 W × 4
(50 Hz to 15 kHz, 5 %THD, 4 W LOAD,
Both Channels Driven)
Load impedance ...................................4 W
(4 W to 8 W allowable)
Preout output level (max) ................ 4.0 V
Equalizer (13-Band Graphic Equalizer):
Frequency ................ 50 Hz/80 Hz/125 Hz/
200 Hz/315 Hz/500 Hz/800 Hz/1.25 kHz/
2 kHz/3.15 kHz/5 kHz/8 kHz/12.5 kHz
Gain ................................................±12 dB
80
En
HPF:
Frequency .................. 50 Hz/63 Hz/80 Hz/
100 Hz/125 Hz/160 Hz/200 Hz
Slope .....................–6 dB/oct, –12 dB/oct,
Subwoofer (mono):
Frequency ..... 50 Hz/63 Hz/80 Hz/100 Hz/
125 Hz/160 Hz/200 Hz
Slope .....................–6 dB/oct, –12 dB/oct,
Gain ...............................–24 dB to +10 dB
Phase .............................. Normal/Reverse
Time alignment .................... 0 to 200 step
× 27 mm
● DVD drive
System ........ DVD-Video, VCD, CD, MP3,
WMA, AAC, DivX, JPEG, MPEG player
Region number ........................................2
× 20 mm
Usable discs .........................DVD-VIDEO,
VIDEO-CD, CD, CD-R, CD-RW,
DVD-R, DVD-RW, DVD-RDL
Frequency response .... 5 Hz to 44 000 Hz
(with DVD, at sampling frequency 96 kHz)
Signal-to-noise ratio ...........96 dB (1 kHz)
(IEC-A network) (RCA level)
Output level:
Video ......................1.0 Vp-p/75 W (±0.2 V)
Number of channels ................. 2 (stereo)
driving
MP3 decoding format .... MPEG-1, 2 & 2.5
WMA decoding format ............. Ver.7, 8, 9
(2 ch audio) (Windows Media Player)
AAC decoding format .........MPEG-4 AAC
(only encoded by iTunes):
.m4a (Ver.11 and earlier)
DivX decoding format.......Home Theater
Ver.3.11, Ver.4.X, Ver.5.X, Ver.6.X :
MPEG video decoding format
.................. MPEG-1: mpg, mpeg, dat
MPEG-2 PS: mpg, mpeg
MPEG-4 Part2 (Visual),
MS MPEG-4 Ver.3: avi
● USB
USB standard spec. .......USB1.1, USB2.0
Max current supply ........................... 1.6 A
–18 dB/oct USB Class ................MSC (Mass Storage
Class) device, iPod (AudioClass,
File system .............. FAT16, FAT32, NTFS
MP3 decoding format ...MPEG-1/Layer 1,
MPEG-1/Layer 2, MPEG-1/Layer 3
–18 dB/oct
MPEG-2/Layer 1, MPEG-2/Layer 2,
(2.5 cm/step) WMA decoding format ........ WMA10 Std,
WMA10 Pro, WMA9 Lossless
AAC decoding format
................................MPEG-2 AAC-LC,
WAVE signal format .............Linear-PCM
H.264 video decoding format
.........BaseLine Profile, Main Profile,
WMV video decoding format ........... VC-1
MPEG4 video decoding format
.....................................SimpleProfile,
AdvancedSimpleProfile
JPEG decoding format .................... JPEG
● SD
Audio Layer 3
Compatible physical format
.......................................... Version 2.0
File system .............. FAT16, FAT32, NTFS
MP3 decoding format ...MPEG-1/Layer 1,
MPEG-1/Layer 2, MPEG-1/Layer 3
MPEG-2/Layer 1, MPEG-2/Layer 2,
.avi, .divx
WMA decoding format ........ WMA10 Std,
WMA10 Pro, WMA9 Lossless
AAC decoding format
................................MPEG-2 AAC-LC,
WAVE signal format .............Linear-PCM
H.264 video decoding format
.........BaseLine Profile, Main Profile,
WMV video decoding format .... VC-1 SP/
High Speed MPEG4 video decoding format
.....................................SimpleProfile,
HID Class) device JPEG decoding format .................... JPEG
● Bluetooth
Version ................................ Bluetooth 3.0
Output power......................+4 dBm Max.
MPEG-2/Layer 3
MPEG-2.5/Layer 3
● FM tuner
Frequency range ................... 87.5 MHz to
Usable sensitivity ............................11 dBf
(0.8 µV/75 W, mono, S/N: 30 dB)
MPEG-4 AAC-LC
Signal-to-noise ratio ........................72 dB
● AM tuner
High Profile
Frequency range
............. 531 kHz to 1 602 kHz (9 kHz)
SP/MP/AP, WMV 7/8
530 kHz to 1 640 kHz (10 kHz)
Usable sensitivity ....... 25 µV (S/N: 20 dB)
Signal-to-noise ratio ........................62 dB
(except GMC)
Note
Specifications and design are subject to
possible modifications without notice due to
improvements.
MPEG-2/Layer 3
MPEG-2.5/Layer 3
MPEG-4 AAC-LC
High Profile
MP/AP, WMV 7/8
AdvancedSimpleProfile
(except GMC)
+EDR certified
(Power class 2)
108.0 MHz
(IEC-A network)
(IEC-A network)
