WARNING:
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
¥ Do not try to light any appliance.
¥ Do not touch any electrical switch; do not use any phone in your building.
¥ Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
¥ If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Spirit DV Gas Stove
10850 117th Place N.E. Kirkland, WA 98033
$10.00
Owner's
Manual
- November, 1999 -
¥ Freestanding Direct-Vent Stove
¥ Natural Gas or Propane
¥ Residential or Mobile Home
CAN/CGA 1-2.19-M81, IR41, IR55, 2.17-M91
93508056
ANSI Z21.44, Z21.11.4
Listed
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for Travis Industries Spirit DV
Summary of Contents for Travis Industries Spirit DV
-
Page 1: Introduction & Important Information
¥ If you cannot reach your gas supplier, call the fire department. - Installation and service must be performed by a qualified installer, service agency or the gas supplier. Spirit DV Gas Stove 10850 117th Place N.E. Kirkland, WA 98033 Listed $10.00... -
Page 2: Safety Precautions
AFETY RECAUTIONS ¥ IF YOU SMELL GAS: * Do not light any appliance * Extinguish any open flame * Do not touch any electrical switch or plug or unplug anything * Open windows and vacate building * Call gas supplier from neighbor's house, if not reached, call fire department ¥... - Page 3 Always follow ¥ If the fiber logs become the instructions in this damaged, replace with manual. Travis Industries log set. ¥ Do not touch the hot ¥ Plug the heater into a surfaces of the heater. 120V grounded electrical Educate all children of the outlet.
-
Page 4: Table Of Contents
ABLE OF ONTENTS General Information Operating Your Heater Introduction & Important Information ..... 1 Before You Begin.......... 18 Safety Precautions......... 2 Location of Controls ........18 Starting The Pilot ........... 19 Features & Specifications Starting the Heater for the First Time .... 20 Installation Options ........ -
Page 5: Installation Options
EATURES AND PECIFICATIONS Installation Options: Features: ¥ Works During Power Outages (millivolt system) ¥ Freestanding ¥ High Efficiency; Up to 80% for Natural Gas, 82% for LP (Steady State) ¥ Residential or Mobile Home ¥ Optional Thermostat or Remote Control ¥... -
Page 6: Stove Installation
The requirements listed below are divided into sections. All requirements must be met simultaneously. Items Packed with the Heater ¥ Lopi Spirit DV Gas Heater ¥ Door Kit (Door handle, mounting angle, T-nut) ¥ Log Set (2 Logs, 2 Twigs, Coals) ¥... -
Page 7: Stove Placement Requirements
.) - TOVE NSTALLATION For qualified installers only! Heater Placement Requirements ¥ Heater must be installed on a level surface capable of supporting the heater and vent ¥ Due to the high temperature of the heater, it should be located out of traffic and away from furniture and draperies. Heater must be placed so no combustibles are within, or can swing within 36"... -
Page 8: Vent Requirements
.) - TOVE NSTALLATION For qualified installers only! Vent Requirements Always maintain the required 1" clearance (air space) to combustible materials to prevent a fire hazard. Do not fill air spaces with insulation. The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas-burning appliance. -
Page 9: Approved Vent Configurations
.) - TOVE NSTALLATION For qualified installers only! Acceptable Vent Configurations Restrictor Position To Adjust the Restrictor: ¥ A vent restrictor is built into the appliance to Determine the correct restrictor position (see the adjust the flow rate of charts under "Approved exhaust gases. -
Page 10: Approved Vent Config's With No Elbows Or Two 45° Offsets (Vertical Term.)
.) - TOVE NSTALLATION For qualified installers only! Approved Venting Configurations for Vertical Terminations with (or without)Two 45° Offsets ¥ 10' Minimum Height (with or without 33' (max) offsets) Restrictor ¥ 33' Maximum Height Position # 7 30 feet 30 feet ¥... -
Page 11: Horizontal Termination
.) - TOVE NSTALLATION For qualified installers only! Approved Venting Configurations with a Horizontal Termination ¥ A Minimum of 2' rise is required directly off of the stove ¥ A minimum of 1' run is required ¥ If using a Snorkel Termination (14" or 36") add the snorkel height to the vertical height. NOTE: A minimum 1' horizontal run is required. -
Page 12: Termination And Two 90° Elbows
.) - TOVE NSTALLATION For qualified installers only! Approved Configurations with a Vertical Termination and Two 90° Elbows 35' (max) 35' (max) Restrictor Position # 7 30 feet 30 feet Restrictor Position #6 25 feet 25 feet Restrictor Position # 5 20 feet 20 feet NOTE:... -
Page 13: Horizontal Vent Termination Requirements
.) - TOVE NSTALLATION For qualified installers only! Horizontal Vent Termination Requirements (see the illustration below) Minimum 9" (225 mm) clearance from any door or window Roof Minimum 12" (300 mm) above any grade, veranda, porch, deck or balcony Surface Minimum 12"... -
Page 14: Finalizing The Installation
INALIZING THE NSTALLATION For qualified installers only! 1 Remove the glass. To remove the glass: Loosen the nuts on the top and right side glass clips. Then slide the glass clips off. Loosen the nuts on the bottom and left side glass clip. Then slide the glass to the right, pivot the glass forward, and remove it from the heater. -
Page 15: Installing The Logs And Coals
.) - INALIZING THE NSTALLATION For qualified installers only! 2 Install the log set and embers (see the illustration below). Burner Pan Log Installation These clips keep the rear log from tilting backwards. The rear log contacts the air deflectors. The rear log protrudes over the burner pan on both... -
Page 16: Installing The Door
.) - INALIZING THE NSTALLATION CONT For qualified installers only! 4 Install the door (see the illustration below). Remove the four screws in the door Place the door face frame with a 5/16Ó socket wrench. down on a Attach the mounting angle to the door non-scratching with two of the screws. -
Page 17: Checking The Pilot Flame
.) - INALIZING THE NSTALLATION For qualified installers only! The pilot flame should impinge the top 3/8Ó of the To adjust the pilot flame, remove the cover screw (and 6 Check the pilot flame gasket) and turn the needle valve. Clockwise lowers thermopile. -
Page 18: Before You Begin
PERATING EATER Before You Begin Read this entire manual before you use your new heater (especially the section "Safety Precautions" on pages 2 & 3). Failure to follow the instructions may result in property damage, bodily injury, or even death. Location of Controls - See explanation below ON/OFF Switch... -
Page 19: Operating Your Heater
PERATING EATER ONTINUED Starting The Pilot Flame The pilot flame is required to ignite the main burners (it also plays a safety role). It should be left on once lit. It will stay lit unless the gas control valve is turned to "OFF". -
Page 20: Starting The Heater For The First Time
PERATING EATER ONTINUED Starting the Heater for the First Time ¥ Paint Curing insures a durable finish. Start the heater and burn on low for 20 minutes. Turn off and let cool. Repeat twice to fully cure the paint. + Fumes and smoke from the paint curing and oil burning off the steel may occur the first time you start your heater. -
Page 21: Adjusting The Blower Speed
PERATING EATER ONTINUED Adjusting the Blower Speed + The blower helps transfer the heat from the heater into the room. It will not turn on until the heater is up to temperature (approximately 10 minutes after starting). See the illustration below for instructions on adjusting the blower speed. -
Page 22: Maintaining Your Heater
AINTAINING EATER Yearly Service Procedure Failure to inspect and maintain the heater may lead to improper combustion and a potentially dangerous situation. We recommend the following procedures be done by a qualified technician. 1 Check the pilot flame (see illustration below). If not correct, contact your dealer for service. 2 Shut off gas to the heater by turning the gas control knob to "OFF"... -
Page 23: Troubleshooting Table
ROUBLESHOOTING Problem: Possible Cause: Don't Call for Service Until You: Pilot Will Not Flame A gas shut off valve is turned off Check all gas shut off valves See "Starting the Pilot Flame" Pg 19 The gas control knob isn't turned to "PILOT" See "Starting the Pilot Flame"... -
Page 24: Troubleshooting
ROUBLESHOOTING ONTINUED How this Heater Works This heater was designed with safety as the primary concern. Many of the components inside this heater are for safety purposes. Therefore, only certified gas service technicians should service this heater. What Turns the Main Burners On and Off This heater uses a millivolt system to control its operation (a millivolt is a very small amount of electricity). -
Page 25: Why Nothing Should Be Placed Against The Heater
ROUBLESHOOTING ONTINUED Why Nothing Should Be Placed Against the Heater Your heater has a grill below the ashlip and air openings on along the top that must not be blocked. These openings are used to draw room air over the hottest parts of the heater and distribute the warmed air into the room. -
Page 26: Warranty
At that time, you may be asked to ship your appliance, freight charges prepaid, to TRAVIS INDUSTRIES, INC. TRAVIS INDUSTRIES, INC., at its option, will repair or replace, free of charge, your TRAVIS appliance if it is found to be defective in material or workmanship within the time frame stated within this 7 year warranty. -
Page 27: Listing Information
ISTING NFORMATION The safety label can be found on the rear panel. A copy is shown below. S p i r i t D V Tested & Beaverton, Listed by OR. USA Listed Gas-Fired Report No. 028-S-15-5 Direct Vent Wall Furnace Tested and certified by OMNI-Test, Inc. -
Page 28: Optional Equipment
PTIONAL QUIPMENT Stove Leg Installation (Brass # 99200500, Cast Black # 99200800, Black Steel # 99200100) Raise the stove 8" (use lumber or other sturdy device). Attach each leg following the instructions below. Attach each leg to the stove by inserting a bolt and washer through the hole or slot in the leg and into the threaded hole on the stove. -
Page 29: Thermostat
PTIONAL QUIPMENT ONTINUED Thermostat (Part # 99300650) Do not connect 120 VAC to the gas control valve or wiring of this unit. 1 Attach the thermostat wire and route it under the burner pan (see the illustration below). Remove the green jumper wire. -
Page 30: Remote Control Thermostat
PTIONAL QUIPMENT ONTINUED Remote Thermostat Do not connect 110-120 VAC to the gas control valve or wiring system of this unit. ¥ Follow the instructions included with the remote thermostat for installation. IMPORTANT OPERATIONAL NOTE FOR REMOTE THERMOSTAT USE: Included with the remote thermostat is a set of instructions that should be given to the homeowner. Please be aware that the remote thermostat has a 1 to 2 minute lag time between the time the thermostat is turned up and the heater turns on. - Page 31 PTIONAL QUIPMENT ONTINUED 3 Remove the burner pan from the burner pan box following the instructions below. Remove the two screws holding the burner box front in place. 1/4" Nutdriver Remove the burner box front. Rotate the burner pan upwards. Slide the burner pan to the left until the fixed shutter disengages from the orifice.
-
Page 32: Propane Conversion Kit
PTIONAL QUIPMENT ONTINUED 4 Follow the directions below to remove the natural gas orifice. Apply thread sealant to the LP orifice (#50 - it has "50" stamped on it) and tighten in place with a 1/2" open end wrench. Replace the spring. - Page 33 PTIONAL QUIPMENT ONTINUED 7 Replace the pilot assembly (follow the instructions in step 6 in reverse order). Make sure the pilot assembly gasket is placed correctly. 8 Replace the rear log shelf (see step 2). Install the logs and embers. Replace the glass and door. 9 Remove the regulator from the front of the gas control valve.
-
Page 34: Addendum
DDENDUM ADDENDUM #1 Altitude Considerations This fireplace has been tested at altitudes ranging from sea level to 8,000 feet. In this testing we have found that the fireplace, with its standard orifice, burns correctly with just an air shutter adjustment. For information on adjusting the air shutter see page 17 of this manual. Failure to adjust the air shutter properly may lead to improper combustion which can create a safety hazard. -
Page 35: Class A Chimney Retrofit
DDENDUM ADDENDUM #3 Interior Masonry Chimney Conversions ¥ Follow the requirements and use the equipment listed in the illustration to the right to install this appliance into an interior masonry chimney. ¥ Maximum vertical rise is 30' ¥ Minimum vertical rise is 10' ¥... -
Page 36: Index
NDEX 131002 Blower Speed ............... 21 Paint Curing..............20 BTU Input ..............5 Pedestal (installation) ........... 28 Cap (vent termination) ..........12 Pilot (starting) ............... 19 Clearances ..............6 Propane Conversion Kit (Installation)......32 Controls................ 18 Propane Line Install (gas line install)......7 Dimensions..............
