Summary of Contents for Merrychef Mealstream 401
-
Page 2: Table Of Contents
Users are cautioned that maintenance and repairs should be performed by a Merrychef authorized service agent using genuine Merrychef replacement parts. Merrychef will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified or repaired using ... -
Page 3: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS DO NOT operate empty, without food or liquid inside the oven, as this will result in overheating and may cause damage. NEVER remove the exterior casework of the oven. 3. NEVER remove any fixed internal parts of the oven. NEVER tamper with the control panel, door, seals, or any other part oven. -
Page 4: Electrical Supply
BS EN 60309.2 The Circuit Breaker should be rated at 45A (TypeC). TWIN PHASE TWIN PHASE The Mealstream 401 oven Twin Phase models should be connected as shown. The Circuit Breaker should be rated at 16amps/ phase (TypeC). If you are in any doubt about your electrical... -
Page 5: Installation Instructions
INSTALLATION Remove packing material and protective film from the oven. Check for obvious signs of transit damage. If necessary, inform the supplier IMMEDIATELY. Note: Remove and check accessories: The air intake is located at 2 turntable trays, 1 rack, 1 oven tray, 1 handle, 1 turntable disc, the rear of the oven, even Service registration card, operating and cleaning instruction sheet. -
Page 6: Suitable Cooking Utensils
SUITABLE COOKING UTENSILS Manufacturer’s instructions should be checked to determine the suitability of individual containers or utensils using each of the cooking functions combination (microwave+convection), convection only and microwave only. The following chart provides general guidelines: Heat resistant containers Toughened glass Do not use items with metallic Vitreous ceramics decoration. - Page 7 THE USE OF METALLIC ITEMS IN COMBINATION AND MICROWAVE ONLY FUNCTIONS Metallic Pans must only be used in the turntable tray. The turntable is made of vitreous enamel which acts as an insulator and allows the safe use of metal pans in controlled conditions. Position large metal pans centrally in the oven at least 40mm ( 1.5 inches ) from side walls.
-
Page 8: Introduction
Programs can have one, two, or three stages. Note: remember convection temperature takes time to change. Do not expect an instant response when a different temperature is activated. The instructions outlined in this guide are intended to ensure the safety and long life of your Merrychef oven. -
Page 9: Main Features
Found on the rear panel, this states the serial The cavity is constructed mainly from stainless steel number, model type, electrical specifications and and vitreous enamelled panel on the door. It must be Merrychef address and telephone number. kept clean (see CLEANING). DOOR RUNNERS... -
Page 10: Control Panel
CONTROL PANEL (electronic controls ) STARBUCKS MODELS MULTI-STAGE MULTI-STAGE INDICATOR INDICATOR TIME/ PROGRAM/ ERROR DISPLAY TIME/ERROR Menukey models DISPLAY TEMPERATURE SETTING PADS non Menukey models TIME/PROGRAM SELECT PADS PROGRAM PAD PROGRAM PAD CONVECTION PAD CANCEL PAD CONVECTION PAD POWER PADS MENUKEY ON/OFF ON/OFF... -
Page 11: Operating Instructions: Manual Mode
OPERATING INSTRUCTIONS: MANUAL MODE The oven can be operated in WARNING: manual or programmed mode. DO NOT APPLY MICROWAVE ENERGY WHEN OVEN IS EMPTY It is important to understand manual mode prior to attempting DO NOT USE THE OVEN WITHOUT program operation. -
Page 12: Programing Number Pads
PROGRAMMING NUMBER PADS Pre-programming allows repetitive cooking procedures to be stored for ease MENUKEY of use in up to 10 programs ( on menukey models up to 100 programs). Note: some MENUKEY settings Each program can comprise up to three stages, allowing at each will prohibit the programming of independent control of Convection temperature, Stage time and Microwave individual number pads... -
Page 13: Running A Program
RUNNING A PROGRAM Using number pad keys to run a programme E6 Error Programs can be recalled using the number pad keys. If the required starting temperature The following procedure should be used to activate these pro- has not been reached, an error grams. -
Page 14: Manual Controls ( Rd401 Models )
MANUAL CONTROLS ( MODEL RD401 ) Switch on oven. Set required oven temperature by turning the temperature control dial clockwise. The convection temperature indicator will illuminate until the set temperature is achieved. For best results, wait for this to happen. The indicator will go on and off as temperaturre within the oven is main- tained. -
Page 15: Cleaning: 1
CLEANING: 1 For the oven to operate at peak efficiency, the cavity, door and air filter must be kept clean. A daily cleaning routine will ensure that you comply with the required hygiene standards and will help to maintain and prolong the efficiency of your oven. Follow the SAFETY INSTRUCTIONS at the beginning of this manual. -
Page 16: Cleaning
efficiently through the filter.Tighten up the three thumb nuts. Merrychef recommends the use of approved Merrychef Oven Cleaner and Merrychef Oven Protector. -
Page 17: Menukey: Changing Oven Menu Programs
™ MenuKey : CHANGING OVEN MENU PROGRAMS The Menukey System automatically changes all the cooking programs with the turn of a key. To change the menus on the oven: Ensure the power switch is off. Lift the Menukey cover in the front panel of the oven.and put the key in the keyhole Turn the key clockwise to the... -
Page 18: Problem Solving
EMC 89/336 EEC than 70dB as required to the LVD 73/23 EEC EN 27779 standard Merrychef reserves the right to alter specifications without prior notice. Pt No. 32Z3455 Issue 09 Merrychef, Mealstream and Menukey are registered trademarks of Merrychef Ltd. -
Page 19: Service Contact Details
On such occasions it is the customer’s responsibility to return the oven to an authorised service centre for repair. SERVICE CONTRACTS Service contracts may be extended at the time of purchase. Contact the Merrychef Service Department for more details.
