User’s Manual MSE PSE-SW5G series 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port Wiring................PD Port Wiring..................Network Application……………………………………......3. Model Information............4. Technical Specification............MSTRONIC CO., LTD.
User’s Manual MSE PSE-SW5G series 1. General Information The PoE (Power Over Ethernet) Switch family provide four 10M/100M/1000M TX ports with PoE PSE function plus one 10M/100M/1000M TX up-link port with PoE PD function. It allows power souring equipment (PSE) to be powered from PoE and deliver power to PoE powered device (PD), which are compliant with IEEE802.3af and IEEE802.3at standard to receive and deliver both...
Page 4
User’s Manual MSE PSE-SW5G series *POWER LED STATUS Description Power Green LED ON when power input (DC IN on rear panel or Port 5 (UPLINK) on front panel) has valid power supplied. The indicator is only used on PSE-SW5G11CN, LED ON when the following warning condition happens.
User’s Manual MSE PSE-SW5G series *PoE LED (the left indicator on RJ45) P1~P4 Yellow A valid Powered Device (PD) is detected and delivering power on this port. No PD is detected on this port. Yellow Powered via all 4 data pairs.
Page 6
User’s Manual MSE PSE-SW5G series Port 5 may get DC power over the Ethernet cable, as detailed below: * Data pair A plus V+ /V- on line 1 and 2 * Data pair B plus V-/V+ on line 3 and 6...
Page 7
User’s Manual MSE PSE-SW5G series Input Voltage Input Voltage Model Output voltage 802.3af/at Isolated (REAR) (Port 5) 12-57VDC PSE-SW5G11CN 12-57VDC No input (As input voltage) (non-regulated) 56VDC 12-36VDC No input (regulated) 42.5-57VDC PSE-SW5G24DN No input 42.5-57VDC (As input voltage) (non-regulated)
User’s Manual MSE PSE-SW5G series *Ethernet Port Wiring The PoE switch family supports one RJ-45 uplink (port 5 with PoE PD) and four RJ-45 ports (port 1~4 with PoE PSE) with automatic MDI/MDI-X crossover, auto-sense for speed and duplex for 10Base-T, 100Base-TX or 1000Base-T connection.
Page 9
User’s Manual MSE PSE-SW5G series Cross-over Cabling Pin 1 Pin 3 Pin 2 Pin 6 Pin 3 Pin 1 Pin 6 Pin 2 Pin 4 Pin 7 Pin 5 Pin 8 Pin 7 Pin 4 Pin 8 Pin 8 Connect an Ethernet cable into any switch port and connect the other side to your attached device.
User’s Manual MSE PSE-SW5G series *PD Port Wiring Port 1 to 4 provides PoE injection function with maximum 35W ability to power up the powered device using the straight-through or cross-over Ethernet cable. The PoE switch follows the IEEE802.3af Alternative B mode connector assignment. The following table shows pin assignment of alternative A and B for the Power Source Equipment.
User’s Manual MSE PSE-SW5G series *Network Application The PoE Switch can receive power from a PoE midspan and provide power to the PD which follows the IEEE 802.3af/at standard in the network. The PoE Switch can be installed in a more appropriate position for better performance to extend Ethernet to 200 meters.
