- Page 1 PSE-SW5G 5 Port PoE Switch & Extender (Repeat Ethernet and PoE) USER’S MANUAL MSTRONIC CO., LTD.
-
Page 2: Table Of Contents
User’s Manual PSE-SW5G series 1. General Information.............. 2. Hardware Description............LED Indicators..................Power Wiring ..................Ethernet Port Wiring................PD Port Wiring..................Network Application……………………………………......3. Model Information............4. Technical Specification............MSTRONIC CO., LTD. -
Page 3: General Information
PSE-SW5G series 1. General Information The PSE-SW5G PoE (Power Over Ethernet) Switch family provides four 10M/100M/1000M TX ports with PoE PSE function plus one 10M/100M/1000M TX up-link port with PoE PD function. It accepts power from PoE power souring equipment (PSE) and delivers power to PoE powered device (PD), which are compliant with IEEE802.3af and IEEE802.3at standard to receive and... - Page 4 LED ON when power input (DC IN on rear panel or UPLINK on front panel) has valid power supplied. The indicator is used on full range voltage model(PSE-SW5G-11x1) and 12VDC typical model(PSE-SW5G52x0), LED ON when the following warning condition happens.
- Page 5 User’s Manual PSE-SW5G series Yellow This port is transmitting to, or receiving Blinking package from another device at 10Mbps or 100Mbps. No device is detected. *PoE LED (the left indicator on RJ45) P1~P4 Yellow A valid Powered Device (PD) is detected and delivering power on this port.
-
Page 6: Power Wiring
User’s Manual PSE-SW5G series *Power wiring The PoE switch family includes 5 models, be used for 5 different ranges of input voltage: full range voltage (12 to 57VDC) (P/N: PSE-SW5G1111,PSE-SW5G1141,PSE-SW5G1181) 12VDC typical (10 to 15VDC) (P/N: PSE-SW5G5210,PSE-SW5G5240,PSE-SW5G5280) 24VDC typical (12 to 36VDC) - Page 7 User’s Manual PSE-SW5G series Mode D (dual,=A+B): * Data pair A plus V+ on line 1 and 2 * Data pair B plus V- on line 3 and 6 * Data pair C plus V+ on line 4 and 5...
- Page 8 User’s Manual PSE-SW5G series *For 24VDC typical model(PSE-SW5G25x4) Please note that the maximum power per port of 35W can only be achieved using 24VDC input operation. If your input is 12VDC, then the total power per port should be de-rated to 17W per port.
-
Page 9: Ethernet Port Wiring
User’s Manual PSE-SW5G series PSE-SW5G5210 24VDC PSE-SW5G5240 10-15VDC No input (regulated) PSE-SW5G5280 12-57VDC 12-57VDC No input (As input voltage) (non-regulated) 12-57VDC PSE-SW5G11XN No input 12-57VDC (non-regulated) Higher voltage 12-57VDC 12-57VDC output (REAR or Port 5) *Ethernet Port Wiring The PoE switch family supports one RJ-45 uplink (port 5 with PoE PD) and four RJ-45 ports (port 1~4 with PoE PSE) with automatic MDI/MDI-X crossover, auto-sense for speed and duplex for 10Base-T, 100Base-TX or 1000Base-T connection. - Page 10 User’s Manual PSE-SW5G series Straight-through Cabling Pin 1 Pin 1 Pin 2 Pin 2 Pin 3 Pin 3 Pin 6 Pin 6 Pin 4 Pin 4 Pin 5 Pin 5 Pin 7 Pin 7 Pin 8 Pin 8 Cross-over Cabling...
-
Page 11: Pd Port Wiring
User’s Manual PSE-SW5G series *PD Port Wiring Port 1 to 4 provides PoE injection function with maximum 35W ability to power up the powered device using the straight-through or cross-over Ethernet cable. The PoE switch follows the IEEE802.3af Alternative B mode connector assignment. The following table shows pin assignment of alternative A and B for the Power Source Equipment. - Page 12 User’s Manual PSE-SW5G series MSTRONIC CO., LTD.
-
Page 13: Model Information
User’s Manual PSE-SW5G series 3. Model Information Model number Input Voltage Vout/pin out/Iout Output Wattage Remark 12~57VDC(P3) PSE-SW5G1111 Vi/1236/2A 2A/port 12~57VDC(POE) 12~57VDC(P3) PSE-SW5G1141 Vi/4578/2A 2A/port 12~57VDC(POE) 12~57VDC(P3) PSE-SW5G1181 Vi/1236+4578/2A 2A/port 12~57VDC(POE) 12-36VDC(P3) PSE-SW5G25A4 56VDC/1236/0.625A 35W/port 802.3at 44~57VDC(POE) 12-36VDC(P3) PSE-SW5G25B4 56VDC/4578/0.625A 35W/port 802.3at... - Page 14 User’s Manual PSE-SW5G series 4. Technical Specifications Standards IEEE802.3/IEEE802.3u standards/IEEE802.3ab (10 base-T/100base-TX/1000base-T) Ports 5 ports with PoE (4 PSE & 1 PD), support auto-crossover & auto-polarity Transmission speed 1000Mbps (1000base-T).100 Mbps (100base-TX), 10 Mbps(10base-T) Auto-negotiation Switch technology store-and-forward Protocols CSMA/CD Flow control IEEE802.3x (full-duplex), back pressure (half-duplex)
- Page 15 User’s Manual PSE-SW5G series *A+B mode: data pair A plusV+(1,2), data pair B plusV-(3,6), data pair C plusV+(4,5), data pair D plus V-(7,8) Port 5, 4 pairs PD Maximum PoE power Port 1-4: IEEE802.3af – 16.8W IEEE802.3at – 35W Current limited – 2A 24V output –...
- Page 16 User’s Manual PSE-SW5G series Power consumption less than 5W when without PD loading Input PSE-SW5G11x1 PSE-SW5G25x4 PSE-SW5G44x4 0.190A 0.340A 0.190A 0.104A 0.170A 0.104A 0.061A 0.061A 0.056A 0.056A Power efficiency 85% at full load (@48V typical) Operating temperature -20℃~ +75℃ Operation humidity...
- Page 17 User’s Manual PSE-SW5G series MSTRONIC CO., LTD.
