MSTRONIC PSE-SW5FSFP24R User Manual

Poe switch + media converter ac+dc input
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

PSE-SW5FSFP24R
PoE Switch + Media Converter
AC+DC INPUT
USER'S MANUAL
MSTRONIC CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSE-SW5FSFP24R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MSTRONIC PSE-SW5FSFP24R

Summary of Contents for MSTRONIC PSE-SW5FSFP24R

  • Page 1 PSE-SW5FSFP24R PoE Switch + Media Converter AC+DC INPUT USER’S MANUAL MSTRONIC CO., LTD.

  • Page 2: General Information

    (for AC power). The following section describes the functions of each LED indicator. *POWER LED STATUS Description Green LED ON when power input (AC or DC IN on rear (Power) panel) has valid power supplied. No power supplied. MSTRONIC CO., LTD.

  • Page 3: Rear Panel

    The AC inlet, DC input terminal and 2 Ventilation fan are located at the rear panel of the PSE-SW5GSFP24R. The device will work with AC in the range 90-264VAC, 47-63Hz. It will also work with DC 24V(12V~36V). MSTRONIC CO., LTD.
  • Page 4 (pair 4,5 and pair7,8) to the PD. The following tables depict the wiring diagram of straight-through and crossover cabling. The crossover cables simply cross-connect the transmit lines at each end to the receive lines at the opposite end. MSTRONIC CO., LTD.
  • Page 5 The automatic MDI/MDI-X crossover function does not apply to fiber connections. To connect the fiber optic port on one switch to the fiber optic port of another switch, simply cross-connect the transmitter at each end to the receiver at the opposite end as illustrated in the figure below. MSTRONIC CO., LTD.
  • Page 6 PD. The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED flashes, go back and check for connectivity problems between that port and the network device it is connected to. MSTRONIC CO., LTD.

  • Page 7: Technical Specifications

    100Base-FX(100Mbps),full duplex *Wave length 1310nm *Max TX power -14dBm(mm), -8dBm(sm) *Min TX power -19dBm(mm), -15dBm(sm) *Min RX sensitivity -32dBm *Max RX power -14dBm(mm),-8dBm(sm) *Link budge 13dB(mm),17dB(sm) *Fiber multi-mode(mm) typical 50 or 62.5/125um *Fiber single-mode(sm) typical 9 or 10/125um MSTRONIC CO., LTD.
  • Page 8 *POWER Green-normal, Red-alarm Power input AC 90-264VAC, 47-63Hz. DC 24V (12V~36V). Power consumption 5W without PD loading Operating temperature -20℃~ 85℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -55℃~+105℃ Dimension 44mm(H)x210mm(W)x199mm(D) 19” rack mount available with brackets MSTRONIC CO., LTD.
