- Page 1 PSE-SW5G2TB0HM 5 Port PoE Switch Combo 56V+24V output USER’S MANUAL MSTRONIC CO., LTD.
-
Page 2: General Information
LED ON when DC power input has valid power supplied. LED ON when the following warning happens. *24V power output under voltage (Vout<16V) *24V power output over voltage (Vout>33V) *24V PoE over current (1.25A/per port) *56V passive PoE output alarm No power supplied. MSTRONIC CO., LTD. -
Page 3: Power Wiring
Total power of PoE is 35W x2 (802.3at), 60W x1 (56V/1.07A) and 24W x2 (24V/1A). Please note green connector is capable of 12A max. If more current is required, use 4 pin DIN connector for up to 15A. MSTRONIC CO., LTD. - Page 4 802.3at PSE, port3 with 56V passive PSE and port4-5 with 24V PSE) with automatic MDI/MDI-X crossover, auto-sense the speed and duplex for 10Base-T, 100Base-TX or 1000Base-T connection. Automatic MDI/MDI-X crossover allows you to connect to other devices (switches, hubs, or workstations etc.), without regard to using straight-through or crossover cabling. MSTRONIC CO., LTD.
- Page 5 Pin 8 Pin 8 Cross-over Cabling Pin 1 Pin 3 Pin 2 Pin 6 Pin 3 Pin 1 Pin 6 Pin 2 Pin 4 Pin 7 Pin 5 Pin 8 Pin 7 Pin 4 Pin 8 Pin 8 MSTRONIC CO., LTD.
- Page 6 DC power to PD. The yellow PoE LED will light up when the cable is correctly connected. Refer to the LED Indicator section for descriptions of each LED indicator. If a port LED is off, go back and check for connectivity problems between that port and the network device connected. MSTRONIC CO., LTD.
-
Page 7: Technical Specifications
Port 1-2: IEEE802.3at – 35W(802.3at 2 event classification) Port 3: 56V 1.07A (60W) Port 4-5: 24V 1A (24W) PSE disconnect mode DC disconnect PoE auto detection IEEE802.3af & IEEE802.3at (2 event classification signaling) PoE protection Over-temperature, over-current, over/under voltage MSTRONIC CO., LTD. - Page 8 *POWER: Green-normal, Red-24V/56V passive PSE alarm Power input 18V~32VDC input @ rear terminal Power consumption <5W without PD loading Power efficiency 85% at full load (@24V typical) Operating temperature ℃~ +70℃ Operation humidity 90% relative humidity, non-condensing Storage temperature -40℃~+85℃ Dimension 40mm(H)x180mm(W)x150mm(D) MSTRONIC CO., LTD.
- Page 9 User’s Manual PSE-SW5G2TB0HM MSTRONIC CO., LTD.
