Note :
Follow the disassembly procedure in the numerical order given.
3-1. SLIDE RACK
2 Slide rack
(Disengage claws
to remove the rack.)
claws
1 Eject CD by moving "A" in
3-2. FRONT PANEL
claws
6 Five screws
(+BV 3 × 8)
8
SECTION 3
DISASSEMBLY
claws
the direction of the arrow.
2 Connector
5 Four screws
(+BV 3 × 8)
7 Front panel
(Disengage claws to remove the rack.)
A
4 Connector
3 Flat cable
1 Two connectors
claws
