To remove the C5
The C5 can be removed from the Docking Station in two ways:
•
•

Setting the viewing angle

You can adjust the viewing angle of the Docking Station to 15°,
25°, or 38°.
To set the viewing angle
1. Press the viewing angle button.
2. Rotate the front of the Docking Station forward or backward
When the Docking Station is used only for charging the C5
battery or the spare battery, set the viewing angle to 15° to save
space and improve stability.
For keyboard use with a C5 docked in the Docking Station, set the
viewing angle to 25° or 38°.
8 English
Press the eject button, and then pull the C5 out of the Docking
Station.
Eject button
Hold the Docking Station with one hand and pull the C5 out of
the Docking Station. When removing the C5, you will feel
some resistance; this is normal.
Viewing angle button
to the desired viewing angle. When the station reaches a
viewing angle, it locks into place.
