Table 2-1 Tablet PC LEDs, Buttons, Connectors, and Other Components
Pen holder
Power LED
Battery LED
Hard Disk Drive LED
Wireless LED
Escape Button
Function Button
Five-way Directional
Control Button
Hot Key #1 Button
Hot Key #2 Button
Security Button
Built-in, mono microphone Works at a natural distance; disabled when an external microphone is plugged in
Pen tether
PC Card slot
Antenna cover
Power switch
AC power jack
Speakers (2) integrated
RJ-11 Modem port
RJ-45/LAN
RJ-45 LEDs (2)
External monitor
Docking connector
USB ports (2)
IEEE 1394 port
Audio-in/Microphone
Audio-out/Headphone
Battery
Battery release latch
Battery gauge
Memory/mini-PCI access 256MB RAM (standard) upgradeable to 1GB. For information about upgrading memory,
Security lock slot
Hard drive bay
Product Identification
Chapter 2 Motion M1200 and M1300 Tablet PC Hardware
Storage for the Motion M-Series Digitizer Pen
Displays power status
Displays battery status
Displays Hard Disk Drive activity
Displays wireless status (ON or OFF) and activity
Primary function (not programmable): Esc. Secondary function (programmable): Alt+Tab
Press this Function button + another button to activate Secondary functions
Primary functions (not programmable): Scrolls Up/Down/Right/Left + Enter
Secondary functions (programmable): Left arrow—Shift+Tab; Right arrow—Tab; Up
arrow—Page Up; Down arrow—Page Down
Primary function (programmable): Displays Dashboard
Secondary function (programmable): Opens the Windows Journal.
Primary function (programmable): Changes the Tablet PC display orientation.
Secondary function (programmable): Opens the Tablet PC Input Panel.
Primary function: Ctrl-Alt-Del; Secondary function: None
Attach a pen tether to this post to secure the Pen.
Holds one Type-II PC card for networking, memory expansion or accessory connections.
A plastic blank ships in this slot in the Tablet PC; leave this installed when not in use.
802.11 wireless networking antenna cover; this area does not open
Turns the Tablet PC on and off; can configure to activate Hibernate or Stand By modes
Connects to the Motion M-Series AC Adapter through a right-angled connector on the
Adapter. Use only a Motion M-Series AC Adapter for either Tablet PC.
Speakers mute when a headset or external speakers are connected.
Connector for a 56.6K V.90 modem
Standard RJ-45 connector for a 10/100 Mbps network
Display status of the LAN connection; blink green/amber for a connection
Fits a standard DB-15 monitor connector for an external monitor.
Docks with the Motion M-Series FlexDock
Each Universal Serial Bus port connects USB accessories, such as a
, mouse, printer, or digital camera.
Connects 4-pin accessories, such as DVD players, optical disk drives, video cameras and
other electronics.
Input jack for 3.5mm plug for a microphone
Input jack for a 3.5mm plug for a headset; mutes the built-in speakers
Self-monitoring battery monitors the amount of charge and notifies the Tablet PC of how
long it will operate with the current power consumption; user swappable
Slide this latch to remove the battery.
Push the button next to the LEDs to check the battery's charge.
see Chapter 4 of this User Guide.
Fits a Kensington-style cable lock for securing the unit to a desk, etc.
20GB (standard); optional 40GB and 60GB hard drive capacity
Serial numbers, System certifications
