3589H-New_Manuals 7/8/10 9:38 AM Page 1
Self-Leveling Five-Beam Laser Dot
Model No. 40-6680
Instruction Manual
Congratulations on your choice of this Self-Leveling Five-Beam Laser
Dot. We suggest you read this instruction manual thoroughly before
using the instrument. Save this instruction manual for future use.
This tool emits five laser beams, which projects a series of visible points
on surfaces around the product (i.e. left, right, front, up, and down).
Beam visibility depends upon lighting conditions in the work area.
This is a Class IIIa laser tool and is manufactured to comply with CFR
21, parts 1040 .10 and 1040 .11 as well as international safety rule
IEC 285.
©2010 Johnson Level & Tool - Rev. 1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40-6680 and is the answer not in the manual?

Questions and answers

Related Manuals for Johnson 40-6680

Summary of Contents for Johnson 40-6680

  • Page 1 Beam visibility depends upon lighting conditions in the work area. This is a Class IIIa laser tool and is manufactured to comply with CFR 21, parts 1040 .10 and 1040 .11 as well as international safety rule IEC 285. ©2010 Johnson Level & Tool - Rev. 1...

  • Page 2: Table Of Contents

    • Low voltage indication when power indication lamp is flashing. • Pendulum locking mechanism helps protect units inner mechanisms. • Multi-functional magnetic base for attaching to tripod or any metal surface. • Dust and rain resistant. ©2010 Johnson Level & Tool - Rev. 1...

  • Page 3: Safety Instructions

    • Use only original Johnson ® parts and accessories purchased from your Johnson ® authorized dealer. Use of non-Johnson ® parts and accessories will void warranty. ©2010 Johnson Level & Tool - Rev. 1...

  • Page 4: Location/Content

    3589H-New_Manuals 7/8/10 9:38 AM Page 4 4. Location/Content of Warning Labels ©2010 Johnson Level & Tool - Rev. 1...

  • Page 5: Location Of Parts/Components

    Power Indicator Lamp 1/4" – 20 thread 1/4”– 20 Thread attaches laser to base Position tab on base into groove on laser Rare Earth Magnets Bumpers for setting base against metal track ©2010 Johnson Level & Tool - Rev. 1...

  • Page 6: Operating Instructions

    3. Turn unit off by rotating on/off switch fully counter clockwise. This will engage the self-leveling locking mechanism and turn unit off, ensuring that the unit will not get damaged when moved or stored. ©2010 Johnson Level & Tool - Rev. 1...

  • Page 7: Using The Product

    3. Position base by rotating top to shoot beam down the back of the base. Ideal for use with metal track. 4. Rare earth magnets located on base allows the base to attach to metal surfaces. ©2010 Johnson Level & Tool - Rev. 1...

  • Page 8: Self-Check & Fine Calibration

    8. If the center point (E) is more than 270º (D) 90º (C) 1/8” at 50’ or 1/32” at 12.5’ from points A, B, C and D, the unit needs to 180º (B) be recalibrated. Fig. A ©2010 Johnson Level & Tool - Rev. 1...
  • Page 9 8. If the laser is still beyond its accuracy specification, recalibrate the laser again. 9. If laser is still out of calibration, contact Johnson Level & Tool for service. 10. Return the plastic screws being careful to not over tighten.
  • Page 10 C. 4. The vertical distance between points A, B and C should not exceed 0.125" (3.2mm). 5. If laser exceeds 1/8” at 50’, contact Johnson Level & Tool for service. ©2010 Johnson Level & Tool - Rev. 1...

  • Page 11: Technical Specifications

    3.150" x 3.858" x 4.000" (80 x 98 x 101.6mm) Weight 1.101 lbs. (0.5 Kg) Working Temperature 14° F to 113° F (-10° C to +45° C) Center Screw Thread 5/8" – 11; 1/4" – 20 ©2010 Johnson Level & Tool - Rev. 1...

  • Page 12: Application Demonstrations

    Plumb reference for lamp installation Reference for fence installation Reference for pipeline installation Reference for dormer installation Reference for door frame installation Reference for baseboard installation Reference for vertical partition Reference for constructing cubic partition ©2010 Johnson Level & Tool - Rev. 1...

  • Page 13: Care And Handling

    12. Product Warranty Johnson Level & Tool offers a three year limited warranty on each of its products. You can obtain a copy of the limited warranty for a Johnson Level & Tool product by contacting Johnson Level & Tool's Customer Service Department, as provided below, or by visiting our web site at www.johnsonlevel.com.

  • Page 14: Warranty Registration

    For further assistance, or if you experience problems with this product that are not addressed in this instruction manual, please contact our Customer Service Dept. In the U.S., contact Johnson Level & Tool’s Customer Service Department at 888-9-LEVELS. In Canada, contact Johnson Level & Tool’s Customer Service Department at 800-346-6682.

  • Page 15: Accessories

    NO WARRANTY. If you need any assistance in locating any accessories, please contact our Customer Service Department. In the U.S., contact Johnson Level & Tool’s Customer Service Department at 888-9-LEVELS. In Canada, contact Johnson Level & Tool’s Customer Service Department at 800-346-6682.
  • Page 16 3589H-New_Manuals 7/8/10 9:39 AM Page 16 ©2010 Johnson Level & Tool - Rev. 1...
