  • Page 1 SIMPLY CLEVER OWNER´S MANUAL OWNER´S MANUAL ŠKODA Superb...

  • Page 3: C  Start Regulation / Reduce Speed - Short Press

    Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. This Owner's Manual contains instructions about the vehicle operation, important information about safety, vehicle care, maintenance and self-help and technical vehicle data. The operation of some functions and vehicle systems is undertaken via Infotainment. Please do not read just this manual, but also the Infotainment Owner's Manual carefully as well.

  • Page 4: Table Of Contents

    MAXI DOT display Net partition Table of Contents Service interval display Roof rack SmartGate On-board literature Heating and ventilation Unlocking and opening Heating, manual air conditioning system, Notes Climatronic Unlocking and locking Structure and more information about the Auxiliary heating (auxiliary heating and Anti-theft alarm system Owner's Manual ventilation)
  • Page 5 Traffic jam assistant Emergency unlocking/locking Assistant for emergencies Replacing windscreen wiper blades Traffic sign recognition Fuses and light bulbs Fatigue detection Fuses Tyre pressure monitoring Bulbs Hitch and trailer Technical data Hitch Trailer Technical data Basic vehicle data General Maintenance Vehicle-specific information depending on engine type Care and maintenance...

  • Page 6: On-Board Literature

    ŠKODA AUTO a.s. pursues a policy of ongoing product and model development ▶ with all vehicles. Changes in terms of supply scope are possible at any time Select the desired model - a menu with the user manuals is displayed.

  • Page 7: Notes

    Note Notes Texts with this symbol contain additional information. Terms used The on-board literature contains the following terms relating to the service work for your vehicle. “Specialist” - Workshop - a workshop that carries out specialist service tasks for ŠKODA vehicles. A specialist can be a ŠKODA Partner, a ŠKODA Serv- ice Partner, or an independent workshop.

  • Page 8: Structure And More Information About The Owner's Manual

    Structure and more information about the Owner's Manual Structure of the manual The Owner's Manual is hierarchically divided into the following areas. Section (e.g. Safety) - the title of the Section is always indicated at the lower ■ left side Main chapters (e.g.

  • Page 9: Abbreviations

    Abbreviation Definition Abbreviations Panel van intended exclusively or mainly for the transporta- Abbreviation Definition tion of goods Engine revolutions per minute NiMH Nickel metal hydride Anti-lock brake system Newton meter, measuring unit for the engine torque Adaptive cruise control personal identification number ®...

  • Page 10: Safety Passive Safety

    ▶ Protect children in suitable child seats with correctly fastened seat belts Safety » page 20, Transporting children safely. ▶ Adopt the correct seated position » page 8, Correct and safe seated posi- Passive Safety tion. Tell your passengers to assume the correct seated position. General information Driving safety ...
  • Page 11 Adjust the head restraint so that the top edge of the head restraint is at WARNING  the same level as the upper part of your head » Fig. 2 (not for seats The front seats and all head restraints must be adjusted to match the ■...
  • Page 12 › Swing the safety lever under the steering wheel in the direction of arrow Correct seated position for the passengers in the rear seats » Fig. ›  Adjust the steering wheel to the desired position. The steering wheel can be Read and observe on page 9 first.

  • Page 13: Seat Belts

    WARNING (Continued) Seat belts A seat belt which is hanging too loose can result in injuries as your body is ■ moved forward by the kinetic energy produced in an accident and is then Using seat belts suddenly held firm by the belt. ...
  • Page 14 In the event of a frontal collision, occupants of the car not wearing a seat belt WARNING (Continued) are thrown forward and strike parts of the interior of the car, such as the Check the condition of all the seat belts on a regular basis. If any damage ■...

  • Page 15: Belt Retractors And Belt Tensioners, Reversible Seat Belts

    The shoulder part of the seat belt must never run across the neck but must Fasten › roughly run over the middle of the shoulder and fit snugly against the chest. Use the lock tongue to slowly pull the webbing over your chest and pelvis. ›...

  • Page 16: Airbag System

    Belt tensioners Airbag system The safety for the driver, front passenger and passengers on the outer rear Description of the airbag system seats who are wearing their seat belts, is enhanced by the belt tensioners fit- ted to the inertia reels on the front and rear external seat belts. ...

  • Page 17: Airbag Overview

    The following airbags will be deployed in the event of a severe side collision. System description ▶ Front side airbag on the side of the accident.  ▶ Read and observe on page 14 first. Rear side airbag on the side of the accident. ▶...
  • Page 18 WARNING Fig. 9 Front airbag and transporting children Safe distance to steering wheel Never transport children on the front seat of a vehicle without using a ■ proper restraint system. If airbags are deployed in the event of an accident, the child might suffer severe or even fatal injuries! The front passenger airbag must be deactivated if using a rear-facing ■...

  • Page 19: Driver's Knee Airbag

    Driver’s knee airbag Side airbags Fig. 10 Installation of the airbag / Gas-filled Airbag / Safe distance be- Fig. 11 Installation locations of airbags: the front seat / back tween the legs and the instrument panel The driver's knee airbag offers adequate protection for the driver's legs. The driver's knee airbag is located in the lower part of the dash panel below the steering column...

  • Page 20: Head Airbags

    WARNING Head airbags Information on correct seating position Your head should never be positioned in the deployment area of the side ■ airbag. You might suffer severe injuries in the event of an accident. This ap- plies in particular to children who are transported without using a suitable child safety seat »...

  • Page 21: Deactivating Airbags

    The front passenger airbag can be switched off with the key-operated switch WARNING (Continued) » Fig. 14 on page 19 - . When objects are attached to the sun visor, the visor can not be pivoted ■ to the side windows. This might result in injuries to the occupants if the We recommend that you ask a ŠKODA service partner to deactivate any other head airbag is deployed.

  • Page 22: Transporting Children Safely

    › Close the storage box on the front passenger's side. Transporting children safely › Check that the warning light under the text    » Fig. 14 -    lights up after the ignition is switched on. Child seat Switching on ›...
  • Page 23 WARNING (Continued) Children are exposed to an increased risk of injury in the event of an acci- ■ dent if they lean forward or adopt an incorrect seated position when the vehicle is moving. This particularly applies to children who are transported on the front passenger seat as they can suffer severe, or even fatal injuries if the airbag system is deployed! Pay particular attention to the information provided by the manufacturer...
  • Page 24 WARNING Child safety and side airbag Never use a rear-facing child seat on the front passenger seat if the pas- ■ senger airbag is activated. This child safety seat is positioned in the deploy- Fig. 18 ment area of the front passenger airbag. The airbag may cause the child se- Incorrect seated position of a vere, or even fatal injuries, in the event of it being deployed.

  • Page 25: Fastening Systems

    Use of child seats fastened with a seat belt Never use a rear-facing child seat on the front passenger seat if the passenger airbag is activated. This child safety seat is positioned in the deployment area of the front passenger airbag. The airbag may cause the child severe, or even fatal injuries, in the event of it being deployed. ...

  • Page 26: The Total Weight Of The Skis Which Are Transported Must Not Exceed

    There are two attachment points between the seat backrest and seat cushion Note of the outer rear seats and front passenger seat for fixing a child seat with the A child seat fitted with the  system can only be mounted in a vehicle fit- ■...
  • Page 27 Size class of Group Front passenger seat Rear seats outside Rear seat middle the child seat 15-25 kg 22-36 kg The size category is shown on the label attached to the child seat. If the front passenger seat is fitted with system attachment points, it is suitable for the installation of an  child seat with “Semi-Universal” approval. The seat is suitable for installation of a ...
  • Page 28 Fig. 21 Cockpit Using the system...

  • Page 29: Using The System

    Power window in the front passenger door Using the system Storage compartment with bottle storage Light switch Cockpit Bonnet release lever Overview Storage compartment on the driver's side Fuse box (behind the storage compartment on the driver's Electric windows side) Electric exterior mirror adjustment Operating lever for adaptive cruise control Door opening lever...

  • Page 30: Instruments And Warning Lights

    Storage compartment with bottle storage Instruments and warning lights Waste container Instrument cluster Note The arrangement of the controls right-hand drive models may differ from the  Introduction layout shown in » Fig. 21. The symbols on the controls and switches are the same as for left-hand drive models.

  • Page 31: Overview

    The beginning of the tachometer red scale range indicates the maximum per- Overview mitted speed for an engine that has been driven-in and has reached operating temperature. You should shift into the next highest gear before the red scale of the revolu- tion counter is reached, or select mode D on the automatic gearbox.

  • Page 32: Coolant Temperature Gauge

    Coolant temperature gauge Fuel gauge Fig. 24 Fig. 25 Coolant temperature gauge Fuel gauge   Read and observe on page 28 first. Read and observe on page 28 first. The display » Fig. 24 provides information on the engine coolant temperature. The display »...

  • Page 33: Warning Lights

    The time can also be set in the Infotainment » Owner´s Manual Infotainment, Counter for distance driven chapter Device settings. Fig. 26 Display in rear centre console Display: MAXI DOT display / Seg- ment Display Fig. 28 Centre console at rear: Display ...
  • Page 34 Engine electronics check (petrol engine) After switching on the ignition, some warning lights light up briefly as a func-  tion test. Safety systems  Tyre pressure  If the tested systems are OK, the corresponding warning lights go out a few Brake linings ...
  • Page 35 Find a parking space on a flat surface or on a slope that is not so steep. Power steering / steering lock (KESSY system)    Read and observe on page 32 first. Brake system  Read and observe on page 32 first.
  • Page 36 Seek help from a specialist garage. Anti-lock braking system (ABS)   Read and observe on page 32 first. Stability control (ESC) / Traction control (TCS)   Read and observe on page 32 first. illuminates – there is an ABS fault. ...

  • Page 37: Engine Electronics Check (Petrol Engine)

    There is a fault in the glow plug system if the warning light does not come  on or illuminates continuously. Proactive passenger protection: function restricted.  Seek help from a specialist garage. LIMITED PROACTIVE PASSENGER PROTECT  The seat belt for the driver and front passenger needs to be replaced. Seek Engine electronics check (petrol engine) ...

  • Page 38: Brake Linings

    If, after a short drive, the indicator light does not go out, there is a system er- Lane departure warning (Lane Assist)   ror.  Read and observe on page 32 first. Seek help from a specialist garage. The warning lights indicates the state of the Lane Assist system.

  • Page 39: Speed Regulating System / Speed Limiter

    If the warning light does not go out, do not continue driving. Seek help from a Speed regulating system / Speed limiter  specialist garage.  Read and observe on page 32 first. Transmission problem The warning light  is only shown in the MAXI DOTdisplay. illuminates - the vehicle speed is limited by the speed regulator system ...

  • Page 40: Coolant

    CAUTION  Coolant Do not continue if for some reason it is not possible to fill with engine oil un-  Read and observe on page 32 first. der the current circumstances! Switch off the engine and seek assistance from a specialist garage. Coolant level too low illumi- Check coolant! Owner's manual!

  • Page 41: Adblue

    Seek help from a specialist garage. ®   AdBlue  Read and observe on page 32 first.  Lamp failure ®  AdBlue level too low Read and observe on page 32 first. ® Information on the amount of AdBlue to be added is also shown.

  • Page 42: Windscreen Washer Fluid Level

    WARNING  Low temperature displayed Always adjust the speed and driving style to the actual weather, road, ter- ■  Read and observe on page 32 first. rain and traffic conditions. The diesel particulate filter reaches very high temperatures - there is a ■...

  • Page 43: Information System

     Advance warning / emergency braking (Front Assist) Information system  Read and observe on page 32 first. Driver information system  illuminates – the system has detected the risk of a collision or automatically  Introduction triggered an emergency braking manoeuvre. This chapter contains information on the following subjects: Information on the Front Assist system»...

  • Page 44: Driving Data (Multifunction Display)

    While the operational faults remain unrectified, the messages are always indi- For vehicles with automatic transmission the recommended gear will be cated again. After they are displayed for the first time, the warning lights shown provided the mode for manual switching (Tiptronic) is selected. ...
  • Page 45 Range Operation The detail provides information about the distance in km, that can be travelled with the current tank and with the same driving style. If you drive more efficiently this value can increase. ® AdBlue range The detail provides information about the distance in km that can still be trav- ®...
  • Page 46 Average speed Deactivate speed limit › The indication is calculated continuously since the last deletion of the memory. Select the menu item Warning at at () or  () and confirm. › Confirm the stored value of the speed limits. After erasing the memory, no data will appear for the first 300 m driven.

  • Page 47: Maxi Dot Display

    Long-term (  ) And “2” (  ) WARNING The memory gathers driving information from any number of individual jour- Concentrate fully at all times on your driving! As the driver you are fully re- neys up to a total of 99 hours and 59 minutes driving or 9,999 kilometres driv- sponsible for the operation of your vehicle.

  • Page 48: Operation Using The Operating Lever

     Read and observe on page 45 first. Operation using the operating lever Description of the operation by means of the buttons on the multi-function Fig. 32 steering wheel Buttons: on the operating lever Button / Action Operation dial Voice control on/off / Sound off /on Press briefly (applies to vehicles without voice con- trol)

  • Page 49: Menu Itemnavigation

    When you select one of the menu items, the destination name and the follow- Button / Action Operation ing items are displayed. dial OK - Start navigation ■ Confirm menu item / menu / Repeat Cancel - Return to the Navigation menu – the compass/vehicle symbol will be ■...

  • Page 50: Menu Itemassist Systems

    The following symbols are displayed next to each entry in the call list. Menu itemAssist systems Incoming call   Read and observe on page 45 first. Outgoing call  Missed call  Select menu item Assist systems › Select and confirm Assist systems in the main menu. Outgoing call ...

  • Page 51: Service Interval Display

    In the display the symbol  appears for 4 seconds and the following message Eco-tips for the kilometre or days to the next service appointment.  Read and observe on page 45 first. Oil service … / … Inspection … / … ...

  • Page 52: Smartgate

    ŠKODA website » Fig. Start the SmartGate application using the communication device to be con- nected. http://www.skoda-auto.com › Then follow the instructions which are included in the SmartGate application. With SmartGate, a maximum of four communication devices can be connected simultaneously using Wi-Fi, with as many ŠKODA applications running simulta-...
  • Page 53 › Switch on the Wi-Fi on the communication device to be connected. With SmartGate, a maximum of two communication devices can be connected › Allow the communication device to be connected to search for available Wi- simultaneously using Wi-Fi Direct, with as many ŠKODA applications running Fi networks (see the Owner's Manual for the communication device to be simultaneously as required.

  • Page 54: Unlocking And Opening

    After changing the password/PIN, the connection to SmartGate must be re-es- Unlocking and opening tablished on the communication device to be connected using the new pass- word or new PIN code. Unlocking and locking If the password/PIN code is still set to the preset factory password/PIN code, ...

  • Page 55: Unlocking / Locking With The Remote Control Key

    After locking, depending on vehicle equipment and setting the following is Unlocking / locking with the remote control key valid for the central locking. ▶ The turn signal lights flash once as confirmation that the vehicle has been locked. ▶ An audible signal sounds additionally on vehicles which are fitted with the anti-theft alarm system.

  • Page 56: Kessy Override Key Removal

    CAUTION Unlocking / locking - KESSY The operation of the remote control may temporarily be affected by signal in- ■ terference from transmitters close to the car and which operate in the same frequency range. The operating range of the remote control key is approx. 30 m. But this range ■...

  • Page 57: Locking / Unlocking The Vehicle With The Central Locking Button

    If the boot lid is closed after the vehicle has been locked and the key with WARNING which the vehicle was locked remains in the luggage compartment, the lid will Doors locked from the inside make it difficult for rescuers to get into the be unlocked (partially opened).

  • Page 58: Individual Settings

    Individual settings Opening/closing a door  Read and observe on page 53 first. The following functions of the central locking system can be set individually in the Infotainment » Owner´s Manual Infotainment, chapter CAR - Car settings. Opening a single door The function allows you to unlock only the driver's door and the fuel filler flap with the radio remote control.

  • Page 59: Anti-Theft Alarm System

    Failure of the system KESSY Child safety lock If the following message is displayed in the display of the instrument cluster, then help is required from a specialist company. Keyless access system faulty.  KEYLESS ACCESS SYSTEM FAULTY  Key battery discharged If the voltage of the key battery is too low, the following message appears in the display of the instrument cluster.

  • Page 60: Luggage Compartment Lid

    Switching off the alarm By disabling the interior monitoring and the anti-towing the safe lock is The alarm is turned off by pressing the  button on the key or switching on switched off. the ignition. CAUTION CAUTION The opened glasses storage compartment reduces the effectiveness of the in- terior monitor.

  • Page 61: Electric Boot Lid

    Boot lid opening/closing Electric boot lid  Introduction This chapter contains information on the following subjects: Operating description Set the top position of the lid Malfunctions Boot lid non-contact opening The boot lid (hereinafter as lid) can be operated electrically and manual in the event of an emergency »...
  • Page 62 ▶ By pressing the handle » Fig. Operating description ▶ By briefly pressing the door in the closing direction. Stop lid movement The lid movement can be stopped in one of the following ways. ▶ By pressing the button » Fig. ▶...

  • Page 63: Window Operation

     Read and observe on page 59 first. Note The top position which is reached when the lid opens automatically, is always Depending on equipment the boot lid can be opened without contact. lower than the maximum top position which can be reached when the lid is opened manually.
  • Page 64 Force limit Opening/closing the windows Window comfort operation Malfunctions Fig. 48 Buttons for window lifter The windows in the doors can be operated electrically by means of the buttons contained in the doors. WARNING The system is fitted with a force limiter »...
  • Page 65 When the buttons are disabled in the rear doors, the warning light in the The window can be completely opened automatically by briefly pressing the  button lights up. button as far as the stop. Renewed pressing of the button causes the window to stop immediately.

  • Page 66: Panorama Sliding/Tilting Roof

    Convenience operation can take place in one of the following ways. Convenience operation of sliding / tilting roof Sliding / tilting roof malfunction Opening › Manual operation of sunblind Press and hold the symbol key  on the key. › Electrical operation of the sunblind Switch off the ignition, open the driver's door and hold the key until it...
  • Page 67 Gradual closing WARNING Complete closing Close the sliding/tilting roof carefully – risk of injury! WARNING Sliding / tilting roof malfunction When operating the sliding/tilting roof, proceed with caution to avoid caus- ing crushing injuries – risk of injury! Fig. 51 CAUTION Operation of the sliding/tilting roof...
  • Page 68 By briefly pressing the button, the sun blind is fully opened or closed. The Manual operation of sunblind movement of the sun blind can be stopped by briefly pressing any button. By pressing and holding down the button the sun blind is opened or closed in Fig.

  • Page 69: Lights And Visibility

    Note Lights and visibility The headlights may mist up temporarily. When the driving lights are switched ■ on, the light outlet surfaces are free from mist after a short period, although Lights the headlight lenses may still be misted up in the peripheral areas. This mist ...

  • Page 70: Daylight Running Lights (Day Light)

    All seats occupied, boot loaded  Turn signal and main beam Driver seat occupied, boot loaded  Xenon headlight Fig. 55 Operating lever: Turn signal and The Xenon bulbs adapt automatically to the load and driving state of the vehi- main beam operation cle when the ignition is switched on and when driving.

  • Page 71: Automatic Driving Lamp Control

    If during the “comfort flashing” the operating lever in the opposite side is Automatic headlight control in rain can be activated or deactivated in the Info- pressed, then the blinking stops. tainment » Owner´s Manual Infotainment, chapter CAR - Vehicle settings. The “Lane change flash”...

  • Page 72: Front And Rear Fog Lights

    Fog mode Front and rear fog lights The cone of light in front of the vehicle is adjusted so that the driver is not dazzled by the reflection of the cone of light by fog in front of the vehicle. Fig.

  • Page 73: Fog Lights With The Corner Function

    CAUTION Fog lights with the CORNER function Poorer visibility is evaluated by a motor mounted below the windscreen in ■  Read and observe on page 67 first. the holder of the interior mirror sensor. Do not attach any stickers or similar objects in front of the light sensor on the windscreen in order to avoid impair- The function CORNER provides better illumination of the nearby environment ing the function or its reliability.

  • Page 74: Headlamp Assistant (Light Assist / Dynamic Light Assist)

    When the hazard warning system is on and the indicator light is switched on Headlamp Assistant (Light Assist / Dynamic Light Assist) (e.g. when turning), the hazard warning lights are switched off temporarily and only the turn signal flashes on the relevant side of the vehicle. ...
  • Page 75 In the following cases, the automatic adjustment of the cone of light of the Switching on and off headlights is disabled, the system automatically switches only the high beam on/off. Fig. 60 ▶ The driving mode Eco is selected » page 171, Selection of the driving Operating lever: Headlamp assis- mode(Driving Mode Selection).

  • Page 76: Interior Lights

    The system is turned off when any of the following is present. Interior lights ▶ The vehicle is locked. ▶ The ignition is switched on.  Introduction ▶ About 30 seconds after all the doors have been closed. This chapter contains information on the following subjects: Rear interior light Front interior light Rear interior light...

  • Page 77: Visibility

    Variant 3 » Fig. 63 Visibility  Switching on / off  Introduction The rear lights - variant 1/variant 3 are operated together with the front lights. ▶ When the front interior lighting is switched on, the rear interior lighting also This chapter contains information on the following subjects: turns on automatically.
  • Page 78 The heater automatically switches off after approximately 10 minutes. WARNING When objects are attached to the sun visor, the visor can not be pivoted to If the engine is switched off when the heating is on and turned back on again the side windows.

  • Page 79: Windscreen Wipers And Washers

    The windscreen wipers remain in the position in which they were when Sun screen in the rear doors switching off the ignition. The service position can also be used as a winter position » page 237. WARNING Properly maintained windscreen wiper blades are essential for clear visi- ■...
  • Page 80 Spraying and wiping the rear window  Windscreen wipers and washers After releasing the operating lever, the wipers will make from 2 to 3 wiper strokes. The operating lever remains in position Activating / deactivating of the automatic windscreen wiping with rain Automatic windscreen wiping in rain can be activated or deactivated in the In- fotainment »...

  • Page 81: Rear Mirror

    To ensure the correct functioning of the system, even in winter, this needs to Interior mirror dimming be regularly cleared of snow and ice, e.g. free with a de-icing spray. Rear mirror  Introduction This chapter contains information on the following subjects: Interior mirror dimming Exterior mirrors WARNING...
  • Page 82 Automatic folding in / back of both mirror housings Exterior mirrors The exterior mirrors are automatically collapsed after locking the vehicle in the park position. Fig. 71 The exterior mirrors are folded back to the driving position after unlocking the Exterior mirror operation vehicle.

  • Page 83: Seats And Head Restraints

    CAUTION Seats and head restraints Never adjust retractable exterior mirrors  by hand - risk of damaging the ■ electric mirror actuator! Front seats When the mirror is swung by external influences (due to impact during ma- ■ noeuvring, for example), then first fold-in the mirror by turning the knob and ...

  • Page 84: Manually Adjusting Seats

    Control elements on the seat » Fig. 73 Manually adjusting seats seat adjustment ▶ 1 - Move in the longitudinal direction Fig. 72 ▶ 2 - Change in inclination Control elements on the seat ▶ 3 - Change in height Adjusting the seat backrest ▶...

  • Page 85: Memory Function Of The Electrically Adjustable Seat

    Retrieving the saved setting Memory Function of the electrically adjustable seat Press the required memory button Ignition Driver's door » Fig. 75 Fig. 75 Open Short Memory buttons and SET button Switched off Closed Long Open Long Activated Closed Long Stopping the ongoing adjustment ▶...

  • Page 86: Folding Front Passenger Seat

     When the vehicle is next unlocked using the same key, the driver's seat and Read and observe on page 81 first. the external mirrors assume the positions stored in the memory of this key. The front passenger seat can be folded forward into a horizontal position. Saving front passenger mirror settings when reversing Folding forward The function of lowering the passenger mirror surface when reversing must be...

  • Page 87: Rear Seats

    Armrest setting Seat backrests Fig. 77 Raise armrest  Read and observe on page 81 first. Fig. 78 Fold the backrest forward from the interior The armrest is adjustable in height. Fig. 79 Raise Fold the backrest forward from › Lift the armrest in the direction of arrow into one of the six locking positions the luggage compartment »...
  • Page 88 There is a lever on the right side of the luggage compartment for unlocking Armrest adjustment the right and the middle rear seat backrests. Before folding the seat backrest forward, check that there are no objects on Fig. 80 the rear seat. Fold down armrest On vehicles with a net partition, the left and then the right and middle rear seat backrest must first be unlocked.

  • Page 89: Head Restraints

    Opening from the boot › Push the unlock button in the direction of the arrow » Fig. 81 and fold the cover including the armrest forwards. Closing › Fold the cover and rear armrest upwards to the stop - the cover must click into place.

  • Page 90: Seat Heating And Ventilation

    Removing › Pull the head restraint out of the seat backrest as far as the stop. › Press down the locking button in the direction of arrow » Fig. 84, while at the same time using a flat screwdriver with a max. width of 5 mm to press the locking button in opening in the direction of arrow ›...
  • Page 91 When the ignition is switched off, the seat heating and seat ventilation is also Front seats with heating and ventilation switched off. If the engine is started again within 10 minutes, the driver's seat heating and seat ventilation is automatically turned on again at the last set- Fig.

  • Page 92: Transporting And Practical Equipment

    The setting of the heating / ventilation level by pressing the keys  and is Transporting and practical equipment not possible. Useful equipment Rear seats with seat heating  Introduction Fig. 88 This chapter contains information on the following subjects: The seat heating is switched on at maximum heat Car park ticket holder...

  • Page 93: Storage Compartment With Bottle Storage

    In the storage compartment there is a holder for credit and other cards Car park ticket holder » Fig. 90 - . Fig. 89 WARNING Parking ticket holder The storage compartment must always be closed when driving for safety reasons. stowage compartments in the doors ...

  • Page 94: Storage Compartment In The Front Centre Console

    Phone box Storage compartment in the front centre console When the telephone is inserted into the Phone box, the telephone signal in- creases in strength by about 20%. This reduces the level of phone battery dis- charge and the electromagnetic radiation inside the vehicle. ›...

  • Page 95: Waste Container

    Waste container Fig. 95 Rear armrest: Open cup holder / cup holder Fig. 96 Waste container: inserting and moving/opening  Read and observe on page 90 first. The cup holder is located in the front centre console » Fig. The cup holder is located in the rear armrest »...

  • Page 96: Storage Compartment Under The Front Arm Rest

     Closing takes place in reverse order. Read and observe on page 90 first. Replace bags The storage compartment is equipped with an interior light which illuminates › Remove the waste container from the slot. when the parking or dipped head lights are on. ›...

  • Page 97: Glasses Compartment

    Glasses compartment Storage compartment on the front passenger side Fig. 100 Opening the glasses storage box  Read and observe on page 90 first. Fig. 101 Open storage compartment / close storage compartment and open air supply The maximum permissible load of the glasses compartment is 250 g. ...

  • Page 98: Storage Compartment Under Passenger Seat

    WARNING Clothes hook The storage compartment must always be closed when driving for safety reasons. Fig. 103 Clothes hooks Note If not using the air supply in the storage compartment we recommend that you leave the air supply closed. Storage compartment under passenger seat Fig.

  • Page 99: Storage Pockets On The Backs Of The Front Seats

    The storage pockets are used for storage of small and light objects, such as Storage pockets on the backs of the front seats mobile phones and the like. The maximum permissible load of each of the pockets is 150 g. Fig.

  • Page 100: Storage Compartment In The Rear Centre Console

     Read and observe on page 90 first. Storage compartment in the rear centre console In the storage compartment there is a cup holder , storage compartment for Fig. 107 the multimedia holder as well as a pen holder » Fig. 108.

  • Page 101: Electrical Sockets And Cigarette Lighter

    › Guide the securing strap through the opening in the seat backrest around Fig. 111 the upper part of the seat backrest. Installation location if the AUX › Then push the seat backrest back into the upright position until the unlock- input ing button clicks into place - check by pulling on the seat backrest.

  • Page 102: 12 Volt Socket In Front Centre Console

    WARNING 12 volt socket in the rear centre console When using the 12 volt power outlets the following notes are to be ob- served. The socket also works if the ignition is switched off. When leaving the ve- ■ hicle, never leave persons who are not completely independent, such as children, unattended in the vehicle.

  • Page 103: 12 Volt Socket In Luggage Compartment

    When plugging in the connector the child safety lock is unlocked and the out- 12 volt socket in luggage compartment let is activated. The outlet works in the following cases Fig. 115 ▶ The engine is running. Cover of the 12 volt power outlet ▶...

  • Page 104: Cigarette Lighter

    CAUTION The power socket can only be used for connecting approved electrical acces- ■ sories with a two-pin 230V plug, with a total power uptake of up to 150 watt. Place the connector on the electrical device into the power socket as far as it ■...

  • Page 105: Ashtrays

    Note The cigarette lighter socket can also be used as a 12 volt socket. Ashtrays  Introduction This chapter contains information on the following subjects: Ashtray Removable ashtray Fig. 120 Centre console at rear: Open storage compartment / removing ashtray The ashtray can be used for discarding ash, cigarettes, cigars and the like »...

  • Page 106: Tablet Holder

    Removable ashtray Attach behind the head restraint Fig. 121 Removing ashtray  Read and observe on page 103 first. Fig. 122 Positioning the adapter/installing the holder Removing/inserting › When removing, do not hold the ashtray on the cover. › Pull out the ashtray in the direction of the arrow »...

  • Page 107: Luggage Compartment And Transport Of Cargo

    Mount in the storage compartment in the rear armrest Fig. 126 Adjusting the holder size  Read and observe on page 104 first. Fig. 124 Open storage compartment / room for holder / holder removal Tilting and rotating the holder The holder may be tilted 30°...
  • Page 108 When transporting cargo the following the instructions must be adhered to CAUTION ▶ When transporting heavy objects, the driving characteristics change due to Never exceed the maximum permissible load of the respective fasteners, ■ the shift in centre-of-gravity. The speed and style of driving must be adjus- nets, hooks etc.

  • Page 109: Fixing Nets

    Fixing nets Foldable hook Fig. 129 Fold-down hooks: variant 1 / variant 2  Read and observe on page 106 first. Fold-down hooks for attaching small items of luggage, such as bags etc., are provided on both sides of the luggage compartment. The maximum permissible load of the hook is 7.5 kg.

  • Page 110: Floor Covering

    One side of the double-sided floor covering is made of fabric, the other side is Floor covering washable (easy to maintain). The washable side is used to transport wet or dirty items. Note For easier turning of the covering, use the loop attached. Luggage net Fig.

  • Page 111: Roll-Up Cover

    CAUTION Fig. 133 When closing the boot lid, jamming and damage to the cover or the side trim ■ Luggage compartment cover panel can occur if handled incorrectly. The following guidelines must be ob- stowed behind the rear seats served. The fixtures »...

  • Page 112: Roll-Up Cover - Automatic Rolling-Up

    › Stow the roll-up cover in the direction of the arrow » › Reinsert the left side cover in the opposite direction to the arrow › Close the side trays on both sides of the luggage compartment. › Fold out the variable loading floor to the upper position. WARNING No objects should be placed on the foldable boot cover.

  • Page 113: Fig

    Removal and fitting Multi-function pocket › Fold down the front hooks on both sides of the luggage compartment in the direction of arrow » Fig. 136. › Grasp the rear bar with both hands and withdraw the pocket in arrow di- rection ›...

  • Page 114: Side Storage Compartment And Trays

    CAUTION CAUTION If you want to stow the roll-up luggage compartment cover and the multifunc- When using the side tray, take care not to damage it or the luggage compart- ■ tion tray at the same time, then it is necessary that the rear part of the roll-up ment lining.

  • Page 115: Storage Compartments Under The Floor Covering

    Usage of Cargo elements Transport of cargo - Version 1 › › Open the storage compartment » Fig. 138 on page 112 - . Remove the fog floor covering in the direction of the arrow » Fig. 141. › › Remove the cargo elements in direction of arrow »...

  • Page 116: Removable Light

    The warning light turns off when the tailgate is closed. Removable light Removed from the holder › Grasp the lamp and swivel in the direction of the arrow » Fig. 144. Fig. 143 Removable lamp Use of removed light › Press the button »...

  • Page 117: Variable Loading Floor In The Luggage Compartment (Estate)

    The variable loading floor can be set to the upper or lower position. Variable loading floor in the luggage compartment (Estate) Set to the upper position  Introduction › Grasp the rear of the variable loading floor by the handle »...

  • Page 118: Net Partition

    › Fold up the variable loading floor by moving it in the direction of the arrow Using the net partition Dividing the luggage compartment Fig. 148 Dividing the boot with variable loading floor Fig. 149 Open part of the roll-up luggage compartment cover / release lever The luggage compartment can be divided with the variable loading floor in the lower and upper position.

  • Page 119: Roof Rack

    › Fold back part of the roll-up luggage compartment cover in the opposite Roof rack direction of the arrow » Fig. 149.  Introduction Using the net partition behind the rear seats › Fold out part of the roll-up luggage compartment cover in the direction of This chapter contains information on the following subjects: the arrow...

  • Page 120: Heating And Ventilation

    fixing points for base support Heating and ventilation Heating, manual air conditioning system, Climatronic  Introduction This chapter contains information on the following subjects: Heating and manual air conditioning Climatronic (automatic air conditioning) Climatronic - automatic operation Air distribution control Air outlet vents Fig.

  • Page 121: Heating And Manual Air Conditioning

    WARNING For your own safety and that of other road users, ensure that all the win- ■ dows are free of ice, snow and misting. The blower should always be on to prevent the windows from misting up. Under certain circumstances, air at a temperature of about 5 °C can flow ■...

  • Page 122: Climatronic (Automatic Air Conditioning)

    Information on the cooling system Fig. 156 The cooling system operates only if the following conditions are met Rear operating elements » page 118. The warning light below the button  » Fig. 154 illuminates after activation, even if not all of the conditions for the function of the cooling system have been met.

  • Page 123: Climatronic - Automatic Operation

    Depending on equipment fitted: There is no automatic temperature control in the two end positions. ▶  Auxiliary heating and ventilation on / switch off » page 124 WARNING ▶  Residual heat function on/off - after switching off the Ignition, the Do not switch off the Climatronic system for longer than necessary.

  • Page 124: Air Distribution Control

    Note WARNING Climatronic is set to the medium setting at the factory. The recirculation system cannot be switched on for a longer period of time, because there is no supply of fresh air from the outside. “Stale air” may re- Air distribution control sult in fatigue in the driver and occupants, reduce attention levels and also cause the windows to mist up.

  • Page 125: Auxiliary Heating (Auxiliary Heating And Ventilation)

    Set the direction of the air Active air outlet nozzles » Fig. 157 outlet » Fig. 158  4, 5, 7  3, 4, 5, 6, 7 CAUTION To ensure that the heating, the manual air conditioning and the Climatronic systems work properly, do not block up the air outlet vents with any objects.
  • Page 126 WARNING Switching on/off The auxiliary heating (auxiliary heating and ventilation) (following as aux. ■ heating) must never be operated in closed rooms (e.g. garages) – risk of poisoning! The auxiliary heating must not be allowed to run during refuelling – risk ■...
  • Page 127 Programming the auxiliary heating in the Infotainment The auxiliary heating can only be switched on/off safely using the radio re- For vehicles with Climatronic: on the front panel of the Climatronic button  mote control, if the distance between the radio remote control and the vehicle →...

  • Page 128: Driving

    WARNING Driving Never (e.g. in garages) run the engine in a closed place - there is the dan- ■ ger of poisoning and death! Starting-off and Driving Do not leave any items (e.g. cloths or tools) in the engine compartment. ■...
  • Page 129 The ignition is switched off. Steering lock locking / unlocking Starting the engine  Read and observe on page 126 first. › The parking brake switch. › For vehicles with manual transmission, shift gear stick to neutral, depress The steering lock (steering lock) deters any attempted theft of your vehicle. the clutch pedal and hold it there until the engine starts.

  • Page 130: Starting And Stopping The Engine At The Push Of The Button

    Note WARNING After switching off the ignition, the radiator fan may intermittently continue to Never (e.g. in garages) run the engine in a closed place - there is the danger operate for approx. 10 minutes. of poisoning and death! CAUTION Starting and stopping the engine at the push of the button The system can recognize the valid key, even if it has been accidentally left ■...
  • Page 131 Under certain circumstances (e.g. after switching off the ignition and opening In vehicles with diesel engines after pressing the button, the glow plug warn- the driver's door), the steering is enabled only when the ignition is switched on ing light illuminates.

  • Page 132: Start-Stopsystem

    CAUTION Problems starting the engine The key can only be verified if it is in the vehicle. It is therefore not always nec- essary to know where the key is. Fig. 163 Engine start - hold key on button Note With a start attempt the rear must be pointed towards the button »...
  • Page 133 Reasons for the engine running Operation It may be essential for the engine to keep running when the vehicle comes to a halt, for the following reasons. Fig. 164 ▶ The engine temperature for the proper function of the system has not yet Display been reached.

  • Page 134: Brakes And Parking

    Manually deactivating/activating the system Brakes and parking  Introduction Fig. 165 Button for the START-STOP sys- This chapter contains information on the following subjects: Information on braking Electric parking brake Parking WARNING Greater physical effort is required for braking when the engine is switch- ■...
  • Page 135 Wet roads or road salt WARNING The performance of the brakes can be delayed as the brake discs and brake Only apply the brakes for the purpose of drying and cleaning the brake pads may be moist or have a coating of ice or layer of salt on them in winter. discs if the traffic conditions permit this.
  • Page 136 Manual shut-down WARNING › With the ignition switched on press the brake pedal and at the same time The emergency brake is to be used only in an emergency when the vehi- ■ push the symbol key  in the direction of arrow »...

  • Page 137: Manual Gear Changing And Pedals

    CAUTION Manual gear changing and pedals If not in the process of changing gear, do not leave your hand on the gear ■  Introduction shift lever while driving. The pressure from the hand can cause the gear shift mechanism to wear excessively. This chapter contains information on the following subjects: When stopping on a slope, never try to hold the vehicle using the accelerator ■...
  • Page 138 – Parking mode WARNING (Continued) The driven wheels are locked mechanically in this mode. If the vehicle is in the D, S, R or Tiptronic mode and comes to a standstill ■ while at idle the engine stops, then prevent the vehicle from rolling away The parking mode must only be selected when the vehicle is stationary.
  • Page 139 Selector lever lock Manual gear shifting (Tiptronic) Fig. 170 Shift lock button  Read and observe on page 135 first. Fig. 171 Selector lever/multi function steering wheel The selector lever is locked in mode P and N to prevent that the forward driv- ...

  • Page 140: Running-In And Economical Driving

    › Select the driving mode Eco or Individual (Drive - Eco) » page 171, Selection Note of the driving mode(Driving Mode Selection). It may be beneficial, for example, when travelling downhill, to use manual ■ › Remove your foot from the accelerator pedal (the speed is higher than 20 shifting of gears.
  • Page 141 DriveGreen function Reducing idling If the vehicle is fitted with the START - STOP system there is an automatic re- Radiator blind duction of the idling. If the engine is stopped on vehicles without START-STOP The fuel consumption, degree of pollution and vehicle wear depend on driving system, such as when waiting in a traffic jam, the fuel economy is already style, road condition, weather conditions and the like.
  • Page 142 If the trip from the start, takes less than 30 minutes, then the assessment DriveGreen function takes in information from the previous trip (the bars are shown in dark green). Average fuel consumption Fig. 172 In the function key, the average fuel consumption from the start is displayed. Shown in the infotainment dis- play When you press the function key a detailed overview of the average fuel con-...

  • Page 143: Avoiding Damage To Your Vehicle

    If the functioning of the blinds is impaired and the vehicle reaches a speed of CAUTION about 150 km/h, the following message appears in the display of the instru- Pay attention to the ground clearance of the vehicle! When driving over ob- ■...

  • Page 144: Assist Systems

    Oncoming vehicles can generate water waves which can exceed the permis- ■ Assist systems sible water level for your vehicle. Potholes, mud or rocks can be hidden under the water, making it difficult or ■ General information impossible to drive through the body of water. Do not drive through salt water, as the salt can cause corrosion.

  • Page 145: Braking And Stabilisation Systems

    WARNING Radar sensor If you suspect that the sensor has been damaged, deactivate the ACC ■ » page 163 und Front Assist » page 168 system. Have the sensor checked Fig. 174 by a specialist garage. Mounting location of the radar The sensor can become misaligned by collisions or by damage to the front ■...
  • Page 146 Upon deactivation, in the instrument cluster the indicator light comes on and WARNING  the display shows the following message. The general information relating to the use of assistance systems must be ESC sport: directional stabil. restricted. observed » page 142, in section Introduction.
  • Page 147 Upon deactivation, in the instrument cluster the indicator light illuminates  Driver Steering Recommendation (DSR) and the display shows the following message.  Read and observe on page 144 first. Traction control (ASR) deactivated.  ASR OFF  In critical situations, the DSR provides the driver with a steering recommenda- Upon activation, in the instrument cluster the indicator turns and the display tion in order to stabilise the vehicle.
  • Page 148  The automatic brake interventions can take place only if the following condi- Read and observe on page 144 first. tions are met. The Auto Hold function (hereinafter referred to only as system) prevents the There was a front, side and rear-end collision of a certain severity. ...

  • Page 149: Parking Aid (Parkpilot)

    WARNING WARNING (Continued) The increased stopping and starting comfort brought by the system must External noise sources may affect the signals of the system sensors. Un- ■ not tempt you to take any safety risks. der adverse conditions, this may cause objects or people not to be recog- The system is not able to stop the vehicle under all circumstances, such nised by the system.
  • Page 150 Note Fig. 178 If with Version 3 vehicles not all fields around the vehicle are active after ac- ■ Sampled areas and range of the tivation the vehicle should be moved forwards or backwards. sensors The signal tones for front obstacle recognition are factory-set to be higher ■...

  • Page 151: Rear Traffic Alert

    The road ahead is displayed when a forward gear or Neutral is engaged or the Seek help from a specialist garage. selector lever is in mode D/S or position N is set. Note The road behind the vehicle is displayed when reverse gear is engaged or the The system can only be activated with the symbol key ...
  • Page 152 The Rear Traffic Alert (hereinafter referred to as system) warns when leaving a Warning - vehicles with parking aid parking space from a transverse parking space about any approaching vehi- You will hear a continuous tone and the following appears »...

  • Page 153: Rear View Camera

    Activation / deactivation Rear View Camera  Read and observe on page 150 first.  Introduction The activation or deactivation of the system can be carried out in one of two This chapter contains information on the following subjects: ways. Operation ▶...

  • Page 154: Operation

    It is only a two-dimensional display. Therefore, protruding objects or roadway The vehicle is not travelling at more than about 15 km/h. ■  depressions, for example, may not be recognised due to lack of space depth. The area behind the vehicle is clearly visible. ...

  • Page 155: Function Keys

     Read and observe on page 151 first. Function keys In the mode for transverse and parallel parking guidance for the assessment of Fig. 186 distance and lane lines are displayed. Function keys Display » Fig. 187 The distance is about 40 cm (safety distance limit) The distance is approximately 100 cm The distance is approximately 200 cm Lane lines...

  • Page 156: Mode - Traverse Parking

    Mode - traverse parking Mode - parallel parking Fig. 188 Display Fig. 189 Display   Read and observe on page 151 first. Read and observe on page 151 first. This mode supports the driver when reverse parking in a parking space that is This mode supports the driver when reverse parking in a parking space that is transverse to the roadway.

  • Page 157: Park Assist

    › Stop the vehicle and steer opposite until the yellow lines the red line Vehicles without towing hitch fade into each other (required roadway alignment). Hold the steering wheel If your vehicle is not factory equipped with a towing device, a red line for moni- in this position.

  • Page 158: Functioning

    WARNING Functioning The general information relating to the use of assistance systems must ■ be observed » page 142, in section Introduction. Fig. 191 During the parking process, the system automatically performs rapid ■ System button steering movements. While it is doing so, do not place your hands between the steering wheel –...

  • Page 159: Parking Space Search

     When the system is activated, the symbol  illuminates. Read and observe on page 156 first. While the parking space search is going on and before the start of the parking, Parking space search a menu may appear showing other suitable parking modes. ...

  • Page 160: Park Forward

    › Depress the brake pedal and wait until the steering wheel automatically ro- tates into the required position, the symbol  goes out. › Carefully drive forwards. › If the backwards arrow is flashing in the display - , select reverse gear again or move the selector lever into position R.

  • Page 161: Departing From A Parallel Parking Space

    As soon as the parking procedure is completed, an audible signal sounds and Automatic brake assist the following message appears in the display: Park Assist stopped. Take over steer-  ing! Read and observe on page 156 first. Parking space found by the driver Automatic brake assist when speeding The system activation is also possible if the vehicle has already been partially If a velocity of 7 km / h is exceeded during the parking manoeuvre for the first...

  • Page 162: Cruise Control System

    The parking process cannot be performed with a trailer or when another ac- WARNING cessory is connected to the trailer socket. The general information relating to the use of assistance systems must ■ be observed » page 142, in section Introduction. Time limit exceeded.
  • Page 163 Operating Description Fig. 198 Cruise control system controls Fig. 197 Segment display: Examples of status displays the CCS  Read and observe on page 160 first.  Read and observe on page 160 first. Overview of the CCS controls » Fig. 198 CCS status displays »...

  • Page 164: Speed Limiter

    Note During control, speed can be increased by pressing the accelerator pedal. Re- ■ leasing the accelerator pedal will cause the speed to drop again to the set speed. By pressing the button » Fig. 198 during the regulation this is cancelled ■...

  • Page 165: Adaptive Cruise Control (Acc)

    CAUTION Operation description When driving downhill, exceeding the set speed limit may occur. When exceed- ing the limit, an acoustic signal sounds and the warning light in the instru- Fig. 201 ment cluster flashes. Operating elements of the speed limiter Note By pressing the button »...

  • Page 166: Operation

    WARNING (Continued) Operation The ACC does not react when approaching a stationary obstacle, such as ■ traffic jams, vehicle breakdowns or vehicles waiting at a traffic light. The ACC does not respond to crossing or oncoming objects. ■ If the ACC does not decelerate fast enough, immediately apply the vehi- ■...

  • Page 167: Automatic Stop-Start

    Set distance to the vehicle ahead. Starting to drive again after a holding period As soon as the vehicle ahead starts moving again after a holding period, your Vehicle detected (control deactivated). vehicle will also move and the speed will continue to be regulated. ACC status indications »...

  • Page 168: Start Control

    Start control Stop/resume control   Read and observe on page 163 first. Read and observe on page 163 first. Basic requirements for start of control Stop control › Set the lever into the sprung position  » Fig. 204 on page 165 Set.

  • Page 169: Set The Clearance Level

    Changing the speed by adopting the current speed () - requirements Special driving conditions The ACC is activated.  The vehicle is moving at a speed other than that which is stored.  Note If during control the speed is increased by pressing the accelerator, control is ■...

  • Page 170: Front Assist

    Narrow vehicles or vehicles travelling side by side Information messages Narrow vehicles or vehicles travelling side by side are not detected by the ra-  dar sensor until they are within the sensor's range » Fig. 205 - . Read and observe on page 163 first.
  • Page 171 The Front Assist (hereinafter referred to as the system) warns you of the dan- Distance warning (dangerous distance) ger of a collision with a vehicle or another obstacle in front of the vehicle, and tries to avoid a collision or mitigate its consequences by automatically applying Fig.
  • Page 172 With automatic braking the symbol appears » Fig. 208 in the display. Disable/enable Advance warning If the system detects a risk of collision, the symbol » Fig. 208 appears in the display and you will hear an acoustic signal. At the same time, the braking system is prepared for possible emergency brak- ing.

  • Page 173: Selection Of The Driving Mode(Driving Mode Selection)

    f the distance-warning function was deactivated before the ignition was Normal switched off, it remains deactivated after the ignition is switched on again. Sportmode Ecomode WARNING Individualmode In the following situations, Front Assist should be switched off for safety Mode selection and Infotainment display reasons.
  • Page 174 The recommended gear is controlled such to achieve the lowest possible fuel Normal consumption » page  Read and observe on page 171 first. When the START-STOP system was deactivated manually » page 130, it is au- tomatically activated. This mode is suitable for a conventional driving. The automatic gearbox is set automatically to mode E »...

  • Page 175: Proactive Passenger Protection (Crew Protect Assist)

    Mode selection and Infotainment display Mode settingsIndividual  Read and observe on page 171 first. In mode Individual the vehicle systems can be set as follows. ■ DCC: - Set the shock characteristics Comfort - Comfortable ■ Normal - Normal ■...

  • Page 176: Lane Departure Warning (Lane Assist)

    ProActive passenger protection (following known as system) increases pas- The second level of protection senger protection in the front seats in situations that could lead to vehicle im- The system intervenes only if the situation is evaluated as critical, such as in pact or overturning.
  • Page 177 When the vehicle approaches a detected line between lanes, the system Operation makes a light movement of the steering wheel in the opposite direction to the boundary line. This corrective steering intervention can be manually overrid- den at any time. WARNING Please take note of the general points relating to the use of assistance ■...
  • Page 178 The system can intervene when the following basic conditions are present. Activation / deactivation The system is activated.   Read and observe on page 175 first. The vehicle is travelling at more than about 65 km/h  The boundary lines are clearly visible (appropriate longitudinal markings). ...

  • Page 179: Assistant For "Blind Spot Monitoring

     Read and observe on page 177 first. Assistant for “blind spot monitoring” Using radar sensors and when the speed is above 15 km / h the system moni-  Introduction tors the area next to and behind the vehicle. At the same time, the distance and the difference in speed between your vehicle and the other vehicles in the This chapter contains information on the following subjects: monitored area can be measured.
  • Page 180 The time at which the warning light indicates a vehicle in the “blind spot” Driving conditions and warnings » Fig. 215 is dependent on the speed difference between the two vehicles. The larger the speed difference, the earlier the warning is given by means of the indicator light.

  • Page 181: Traffic Jam Assistant

    WARNING Information messages Please take note of the general points relating to the use of assistance ■  Read and observe on page 177 first. systems » page 142, in section Introduction. The driver must always have hands on the steering wheel and be ready to ■...

  • Page 182: Traffic Sign Recognition

    The assistant for emergencies (following known as system) detects inactivity Operating conditions of the driver, which for example can be caused by a sudden loss of conscious-  ness. The system then performs measures as safely as possible to decelerate Read and observe on page 180 first.
  • Page 183 Data from the camera is supplemented by information from the Infotainment Function Navigation. This is the reason why traffic signs with maximum speeds can also be shown on sections of roads which do not have any traffic signs. Fig. 217 Warning when exceeding the speed limit Camera viewing range for traffic The warning when exceeding the permissible speed can be activated and set...

  • Page 184: Fatigue Detection

    Note Information messages In some situations, the system may evaluate the driving incorrectly and thus ■  Read and observe on page 180 first. mistakenly recommend a break (e.g. sporty driving, adverse weather condi- tions or poor road conditions). The warning symbols are shown in the instrument cluster display. The system is designed primarily for use on motorways.

  • Page 185: Tyre Pressure Monitoring

    › Switch-on the ignition. Tyre pressure monitoring › The Infotainment switches on. › Press the key in the Infotainment and then in the display the function  Introduction  keys one after the other  → Vehicle status. › This chapter contains information on the following subjects: By using the function keys ...

  • Page 186: Hitch And Trailer

     Read and observe on page 184 first. Hitch and trailer The tow bar is located in the rear bumper of the vehicle. Hitch In addition to the handle » Fig. 220 there is a warning light that indicates whether the tow bar is locked - lit green, or is not locked - flashes red. ...

  • Page 187: Trailer

    WARNING Distance of the centre of gravity of Permissible total weight of the ac- the load from the ball head cessories, including load Take care with the towing device - it may cause injury. ■ Do not use the towing device, if the warning light is not green. ■...
  • Page 188 The power supply works with ignition on or off. Coupling / uncoupling trainer With the ignition off, the battery of the towing vehicle is discharged by activa- ted consumers. Fig. 222 Housing of the 13 pin socket, At low charge state of the vehicle battery power to the trailer is interrupted. safety eyelet WARNING Improperly connected trailer electrical installations may cause accidents...
  • Page 189 WARNING Sliding cargo can significantly adversely affect stability and driving safety - risk of accident! Trailer load The permissible trailer load must not be exceeded under any circumstances. Permissible trailer load - Superb Permissible trailer load, braked (kg) Engine Gearbox Permissible trailer load, unbraked (kg) Gradients of up to 12 % Gradients of up to 8 %...
  • Page 190 Permissible trailer load - Superb Estate Permissible trailer load, braked (kg) Engine Gearbox Permissible trailer load, unbraked (kg) Gradients of up to 12 % Gradients of up to 8 % 1.4 l/92 kW TSI 1600 1800 1600 1900 1.4 l/110 kW TSI ACT MG 4x4 1800 2000...
  • Page 191 On downhill sections shift down a gear in good time to also use the engine as a brake. WARNING Always drive particularly carefully with the trailer. CAUTION If you tow a trailer frequently, you should also have your vehicle inspected be- tween service intervals.

  • Page 192: General Maintenance

    For the sake of the environment General Maintenance Technical documents regarding alterations carried out on the vehicle must be kept by the vehicle user in order to be handed over to the recyclers at a later Care and maintenance date. This ensures that the vehicle is recycled in an environmentally sound manner.
  • Page 193 The ŠKODA Service Partners are up-to-date on the legally required tests and ŠKODA AUTO a.s. is able to vouch for the safety, suitability and long service life will prepare the vehicle for the tests as part of a service operation if required, of these products.
  • Page 194 ŠKODA Service Partners are liable for any defects of ŠKODA Genuine Accesso- Component protection ries for a period of 2 years after installation or delivery in accordance with the  materials defect liability, unless agreed otherwise in the purchase agreement Read and observe on page 190 first.

  • Page 195: Washing Vehicle

    WARNING Washing vehicle No modifications of any kind must be made to parts of the airbag system. ■  Introduction Any work on the airbag system including the installation and removal of ■ system components due to other repair work (e.g. removal of the steering This chapter contains information on the following subjects: wheel) must only be carried out by a specialist garage.

  • Page 196: Cleaning Vehicle Exterior

    Clean wheels, door sills and similar parts last. Use a second sponge for such Maintain a sufficiently large distance to the parking aid sensors and soft mate- areas. rials such as rubber hoses or insulation material. Give the vehicle a good rinse after washing it and dry it off using a chamois CAUTION leather.
  • Page 197 WARNING CAUTION Vehicle care products may be harmful to your health if not used according Paint damage is to be repaired immediately. ■ ■ to the instructions. Never apply wax to the windows. ■ Mat painted or plastic parts must not be treated with polishing products or Always keep the vehicle care products safe from people who are not com- ■...
  • Page 198 Plastic parts Windows and external mirrors  Read and observe on page 195 first. Fig. 223 Fuel filler flap: Remove ice scra- Clean plastic parts with a damp cloth. If this method does not completely clean the plastic parts, use cleaning prod- ucts specially designed for this purpose.
  • Page 199 CAUTION Door closing cylinder Information for cleaning windows  Read and observe on page 195 first. Do not clean the inside of the windows with sharp-edged objects or corro- ■ sive and acidic cleaning agents – there is a risk of damaging the heating ele- Specific products must be used for de-icing door lock cylinders.

  • Page 200: Interior Care

    Regularly remove salt and brake abrasion, otherwise the rim material will be Wiper blades corroded.  Read and observe on page 195 first. Light alloy wheel trims After washing thoroughly and treat the wheel rims with a protective product Clean the wiper blades regularly with a glass cleaner. The wiper blades should for light alloy wheels.
  • Page 201 Do not attach any stickers to the filaments or glass antenna - there is risk of Some clothing materials, e.g. dark denim, do not have sufficient colour fast- ■ ■ damage. ness. This can cause damage or clearly visible discolouration to seat covers, Do not clean the roof panelling with a brush –...
  • Page 202 CAUTION Safety belts ® For Alcantara seat covers, do not use any solvents, floor wax, shoe cream, ■  Read and observe on page 198 first. stain remover, leather cleaners or similar agents. Avoid leaving the vehicle in bright sunlight for long periods of time in order ■...

  • Page 203: Inspecting And Replenishing

    Inspecting and replenishing Petrol and diesel refuelling Fuel  Introduction This chapter contains information on the following subjects: Petrol and diesel refuelling Lead-free petrol Diesel fuel The correct fuel grades for your vehicle are specified on the inside of the fuel Fig.
  • Page 204 › Remove the pump nozzle from the fuel filler neck and put it back in the Lead-free petrol pump. › The correct fuel grades for your vehicle are specified on the inside of the fuel Place the filler cap onto the fuel filler neck and turn it in the opposite direc- filler flap.
  • Page 205 Fuel additives Note Unleaded petrol in accordance with the EN 228 standard meets all the condi- Unleaded petrol that has a higher octane number than that required by the ■ tions for a smooth-running engine. We therefore recommend that no fuel ad- engine can be used without limitations.

  • Page 206: Adblue ® And Its Refilling

    ® Preheating fuel For vehicles with the AdBlue injection system there is a note on the inside of ® The vehicle is fitted with a fuel filter preheating system. This secures opera- the fuel filler flap referring to the location of the AdBlue filler neck and the ®...
  • Page 207 Note ® AdBlue replenish ® The AdBlue solution freezes at a temperature of -11° C and lower. The sys- ■ tem has a heater to ensure the operability at low temperatures. ® We recommend purchasing AdBlue refill bottles from the ŠKODA original ■...

  • Page 208: Engine Compartment

    After refilling WARNING (Continued) › ® After refilling AdBlue put the cap on the fuel filler neck and turn in the oppo- For vehicles with manual transmission the lever into the neutral position. ■ site direction of the arrow until it engages. On vehicles with automatic transmission, shift the selector lever into the ■...
  • Page 209  Read and observe on page 206 first. WARNING Read and observe the information and warning instructions on the fluid ■ Open flap containers. › Open the driver door. Keep the working fluids in sealed original containers and safe from peo- ■...
  • Page 210 Engine compartment overview Windscreen washer system Fig. 229 Windscreen washer fluid reservoir  Read and observe on page 206 first. Fig. 228 Principle sketch: Engine compartment Depending on the engine the windshield washer fluid container is lo- cated in the engine compartment of the vehicle »...

  • Page 211: Engine Oil

    CAUTION Note Under no circumstances must radiator antifreeze or other additives be added Before a long drive we recommend that you purchase and carry with you en- ■ ■ to the windscreen washer fluid. gine oil which complies with the specification for your vehicle. If the vehicle is fitted with a headlight cleaning system, only cleaning prod- We recommend that you use oils from ŠKODA Original Accessories.

  • Page 212: Coolant

    The engine consumes a little oil. The oil consumption may be as much as 0.5 CAUTION l/1 000 km depending on your style of driving and the conditions under which In an emergency, another engine oil to be refilled. To prevent damage to the ■...
  • Page 213 The proportion of coolant additive in the mixture must be at least 40%. Any faults resulting from corrosion may cause a loss of coolant and can con- ■ sequently result in major engine damage. The coolant additive may be increased to a maximum of 60%. Do not fill the coolant above the mark »...

  • Page 214: Brake Fluid

    Checking the level WARNING › Check the coolant level in the coolant expansion tank » Fig. 231. The engine compartment of your car is a hazardous area. The following ■ warning instructions must be followed at all times when working in the en- If the engine is warm, the test result may be inaccurate.

  • Page 215: Vehicle Battery

    A slight drop in the fluid level results when driving due to normal wear-and- Warning symbols on the vehicle battery tear and automatic adjustment of the brake pads. Symbol Meaning There may be an indication of a leak in the brake system, however, if the fluid ...
  • Page 216  Read and observe on page 213 first. WARNING The use of open flames and light should be avoided. ■ The battery is located in the engine compartment. For some equipment var- Smoking and radio triggering activities should be avoided. ■...
  • Page 217 Winter time The vent plugs of the vehicle battery should not be opened for charging. The vehicle battery only has a proportion of the starting power in lower tem- WARNING peratures. A discharged vehicle battery may already freeze at temperatures When you charge a battery, hydrogen is released, and a highly explosive just below 0 °C.
  • Page 218 › First, disconnect the negative terminal  first, then the positive terminal  CAUTION of the battery. Despite such intervention by the vehicle electric system management, the ■ vehicle battery may be drained. For example, when the ignition is switched on Connecting ›...

  • Page 219: Wheels

    Always store wheels or tyres in a cool, dry place that is as dark as possible. Wheels Tyres which are not fixed to a wheel trim should be stored upright. Tyres and wheel rims Tyre age Tyres age and lose their original characteristics, even if they are not being ...
  • Page 220 Tyre diameter in inches Tyre wear These details are intended only as information for the specified tyre pres-  sure and does not list approved tyre sizes for your vehicle. Read and observe on page 217 first. The approved tyre sizes for your vehicle are listed in the vehicle's technical Tyre wear depends on the pressure, driving style, and other circumstances.
  • Page 221 Tyre wear indicator and wheel replacement Tyre damage  Read and observe on page 217 first. We recommend checking your tyres and wheel rims for damage (punctures, cuts, splits and bulges, etc.) on a regular basis. Remove any foreign objects in the tyre tread immediately (e.g. small stones). Foreign bodies which have penetrated into the tyre (e.g.

  • Page 222: Winter Operation

    Please note the following if you intend to use the temporary spare wheel. The date of manufacture is stated on the tyre wall (possibly on the inside). ▶ The warning label must not be covered after installing the wheel. For example DOT ... 10 15... means, for example, that the tyre was manufac- ▶...
  • Page 223 CAUTION Winter tyres The chains must be removed when driving on snow-free paths. They would The handling of your vehicle will be significantly improved when driving on otherwise cause loss of performance and damage the tyres. wintry roads if you fit winter tyres (labelled M+S). To obtain the best possible handling, winter tyres must be fitted to all four wheels.

  • Page 224: Emergency Equipment And Self-Help

    The following information applies for the first aid kit and warning triangle from Do-it-yourself the ŠKODA Original Accessories. The storage compartments may be too small for other first aid kits and warn- Emergency equipment and self-help ing triangles. Emergency equipment First-aid box The first-aid box can be attached by a strap to the right-hand side of the boot ...
  • Page 225 WARNING reflective vest The fire extinguisher must always be secured safely so that they do not come loose when making an emergency braking or in a vehicle collision Fig. 239 which could cause injuries to occupants. Front door: Storage compart- ment for the reflective vest Note The fire extinguisher is part of the scope of delivery in certain countries only.

  • Page 226: Changing A Wheel

    Tyres with increased puncture resistance WARNING Some vehicles may be fitted with tyres at the factory that have increased The factory-supplied lifting jack is only intended for your model of vehicle. puncture resistance (so-called “SEAL” tyres). Under no circumstances attempt to lift heavier vehicles or other loads. These vehicles are delivered without a puncture repair kit, spare wheel and CAUTION appropriate hand tools.

  • Page 227: Full Wheel Trim

    Store wheel away Wheel bolts › Place the wheel into the wheel well with the wheel rim pointing downward. › Pull the fixing band through the opposite holes in the wheel rim. › Fig. 243 Screw on the special screw in the opposite direction to the arrow »...

  • Page 228: Loosening/Tightening Wheel Bolts

    › Replace the wheel trim or the caps. Use the appropriate adapter for tightening the anti-theft wheel bolts » page 225. To be equipped for a possible wheel change, the adapter for the anti-theft › Grasp the end of the wrench and turn the bolt against the direction of the wheel bolts must always be kept in the vehicle.

  • Page 229: Remove The Wheel / Fix

    › The mounting points are located on the metal bar » Fig. 246. Remove the wheel carefully. › Attach the wheel and slightly screw on the wheel bolts. › Insert the crank into the mount on the jack » page 223.

  • Page 230: Puncture Repair Kit

    WARNING Components of the puncture repair kits If the wheel bolts are tightened to a too low tightening torque, the rim ■ can come loose when the car is moving. A tightening torque which is too high can damage the bolts and threads and this can result in permanent deformation of the contact surfaces on the rim.
  • Page 231 General information Sealing and inflating the tyre   Read and observe on page 228 first. Read and observe on page 228 first. For your own safety and the safety of your passengers, the following instruc- Sealing › tions must be observed before carrying out a wheel repair on the road. Forcefully shake the tyre inflation bottle »...

  • Page 232: Jump-Starting

    The battery of another vehicle can be used to jump-start your vehicle if the en- WARNING gine will not start because the battery is flat. If the tire does not inflate to at least 2.0 bar, the damage is too great. The ■...

  • Page 233: Towing The Vehicle

    WARNING Fig. 250 Do not clamp the jump-start cable to the negative terminal of the dis- ■ Engine earth: START-STOP sys- charged battery. There is the risk of detonating gas seeping out the battery being ignited by the strong spark which results from the engine being star- ted.
  • Page 234 Vehicles with automatic transmission may be towed in with a tow bar or a tow WARNING rope or with the front wheels raised. If the vehicle is raised at rear, the auto- When towing, exercise increased caution. ■ matic gearbox is damaged! If possible, the vehicle should be towed with the Do not use spiral rope for towing »...

  • Page 235: Remote Control And Removable Light

    Removing/installing the towing eye For tightening purposes, we recommend, for example, using the wheel › Manually screw the towing eye as far as it will go in the direction of the ar- wrench, towing eye from another vehicle or a similar object that can be pushed »...
  • Page 236 CAUTION Replace battery in KESSY key We recommend having faulty rechargeable batteries or batteries replaced by ■ a ŠKODA service partner. The replacement battery or the replacement rechargeable battery should ■ have the specifications of the original battery or original rechargeable battery. Pay attention to the correct polarity when changing the rechargeable batter- ■...

  • Page 237: Emergency Unlocking/Locking

    Synchronising the remote control Change batteries of the removable lamps  Read and observe on page 234 first. Fig. 258 Locking clip If the vehicle does not unlock when pressing the remote control, the key may not be synchronised. This can occur when the buttons on the remote control key are actuated a number of times outside of the operative range of the equipment or the battery in the remote control key has been replaced.
  • Page 238 › Replace the cap in its original position. Unlocking/locking the driver's door CAUTION Make sure you do not damage the paint when performing an emergency lock- ing/unlocking. Locking the door without a locking cylinder Fig. 259 Driver's door handle: masked lock cylinder / key rotations for un- locking and locking Fig.

  • Page 239: Replacing Windscreen Wiper Blades

    › Fold the rear seat backrest forward » page WARNING › Insert a screwdriver or similar tool into the recess or the opening in the trim Replace the windscreen wiper blades once or twice a year for safety rea- » Fig. 262 as far as the stop.

  • Page 240: Fuses And Light Bulbs

    › Turn on the ignition and press the lever into position » page 78, Wind- Fuses and light bulbs screen wipers and washers. Move the windscreen wiper arms into the home position. Fuses  Introduction Replacing the rear window wiper blade This chapter contains information on the following subjects: Fuses in the dash panel –...
  • Page 241 › Remove the plastic clip under the cover of the fuse box in the engine room WARNING » Fig. 269 on page 241 . Always read and observe the warnings before completing any work in the › Place the clip on the respective fuse and pull this fuse out. engine compartment »...
  • Page 242 Installing the storage compartment Consumer › Raise the storage compartment in the direction of the arrow Air blower for air conditioning,heating › Overcome the resistance of the detents › Electric steering lock Insert the brake control linkage in the opposite direction to arrow ›...
  • Page 243  Read and observe on page 239 first. Consumer Boot lid, headlight washers, windscreen washer system Replacing fuses › Visor for gas discharge bulbs, interior lighting Press together the interlocks of the cover simultaneously in the direction of the arrow »...

  • Page 244: Bulbs

    A stowage compartment for replacement bulbs is located in a plastic box in Consumer the spare wheel or underneath the floor covering in the luggage compartment. Databus, battery data module We recommend having the headlight settings checked by a specialist garage Windscreen wipers after replacing a bulb in the low, high or fog beam.
  • Page 245 › Remove the bulb from the holder in the direction of the arrow Bulb arrangement in the headlights › Insert a new bulb into the connector so that the lug on the connector snaps into the groove on the bulb. Fig.
  • Page 246 Refit the headlight and grille Replacing the bulb for the fog light › Replace the fog light by inserting it in the opposite direction of the arrow » Fig. 274 and tighten. › Insert the protective grille and carefully press it in. The protective grille must engage firmly.
  • Page 247 ›  Carefully remove the connector from the lamp assembly in the direction of Read and observe on page 242 first. the arrow › Turn the holder with the bulb » Fig. 276 in the direction of the arrow Fitting ›...

  • Page 248: Technical Data

    Technical data Vehicle characteristics Technical data Basic vehicle data  Introduction This chapter contains information on the following subjects: Vehicle characteristics Operating weight Payload Fig. 277 Vehicle data sticker/type plate Measurement of fuel consumption and CO emissions according to ECE Vehicle data sticker Regulations and EU Directives The vehicle data sticker...
  • Page 249 Maximum permissible front axle load Operating weight - Superb Maximum permissible rear axle load Engine Transmission Operating weight (kg) Vehicle identification number (VIN) 1.4 l/92 kW TSI 1375 The vehicle identification number - VIN (vehicle body number) is stamped into 1395 the engine compartment on the right hand suspension strut dome.
  • Page 250 The data on fuel consumption and CO emissions are given on the ŠKODA Engine Transmission Operating weight (kg) websites or in the sales and technical vehicle documentation. 1485 1.8 l/132 kW TSI The measurement of the intra-urban cycle begins with a cold start of the en- 1505 gine.
  • Page 251 Dimensions - Superb Fig. 278 Vehicle dimensions Vehicle dimensions for operating weight without driver (in mm) » Fig. 278 Specification Value Basic dimension 1468 Vehicles with the off-road package 1483 Height Vehicles with the SPORT package 1453 Vehicles with DCC 1458 Basic dimension 1584...
  • Page 252 Dimensions - Superb estate Fig. 279 Vehicle dimensions Vehicle dimensions for operating weight without driver (in mm) » Fig. 279 Specification Value Basic dimension 1477 Vehicles with the off-road package 1492 Height Vehicles with the SPORT package 1462 Vehicles with DCC 1467 Basic dimension 1584...
  • Page 253 Overhang angle (°) - Superb Estate Overhang angle » Fig. 280 Basic dimension 14.0/14.1 12.2/12.0 Vehicles with the off-road package 15.1/15.2 12.4/12.1 Vehicles with the SPORT package 12.7/13.0 12.4/12.2 Vehicles with DCC 13.2 12.4/12.3 Does not apply to Superb Estate 4 x 4 vehicles. Fig.

  • Page 254: Vehicle-Specific Information Depending On Engine Type

    Vehicle-specific information depending on engine type  Introduction This chapter contains information on the following subjects: 2.0 l/206 kW TSI engine 1.6 l/88 kW TDI CR engine 1.4 l/92 kW TSI engine 2.0 l/110 kW TDI CR engine 1.4 l/110 kW TSI ACT engine 2.0 l/130 kW TDI CR engine 1.4 l/110 kW TSI engine 2.0 l/140 kW TDI CR engine...
  • Page 255 1.4 l/110 kW TSI engine Output (kW/rpm) 110/5000-6000 Maximum torque (Nm/rpm) 250/1500-3500 Number of cylinders/displacement (cm 4/1395 Body Superb Superb Estate Transmission Top speed (km/h) Acceleration 0-100 km/h (s) 1.8 l/132 kW TSI engine 132/4000-6200 Output (kW/rpm) 132/5100-6200 320/1450-3900 Maximum torque (Nm/rpm) 250/1250-5000 Number of cylinders/displacement (cm 4/1798...
  • Page 256 2.0 l/206 kW TSI engine Output (kW/rpm) 206/5600-6500 Maximum torque (Nm/rpm) 350/1700-5600 Number of cylinders/displacement (cm 4/1984 Body Superb Superb Estate Transmission DSG 4x4 DSG 4x4 Top speed (km/h) Acceleration 0-100 km/h (s) 1.6 l/88 kW TDI CR engine Output (kW/rpm) 88/3600-4000 Maximum torque (Nm/rpm) 250/1600-3250...
  • Page 257 2.0 l/130 kW TDI CR engine Output (kW/rpm) 130/3700-4000 Maximum torque (Nm/rpm) 380/1750-3400 Number of cylinders/displacement (cm 4/1968 Body Superb Superb Estate Transmission Top speed (km/h) Acceleration 0-100 km/h (s) 2.0 l/140 kW TDI CR engine Output (kW/rpm) 140/3500-4000 Maximum torque (Nm/rpm) 400/1750-3250 Number of cylinders/displacement (cm 4/1968...
  • Page 258 Adjusting Anodized parts Index Exterior mirrors Refer to vehicle maintenance Steering wheel Anti-lock braking system (ABS) Adjusting the seats Anti-theft alarm system abroad Adjustment Enable/disable lead-free petrol Front seats Trailer Abroad Headlight beam Anti-theft wheel bolts Headlights Headrests Armrest Seats Front Operation Advance warning / emergency braking...
  • Page 259 automatic transmission Brake Carrier selector lever lock defect Information messages Roof rack Warning light Automatic transmission Cavity protection Kick down Brake Assist (HBA) Central locking Launch control Brake booster Problems Malfunctions brake fluid Central locking button Selector lever lock specification Change Warning light Brake fluid...
  • Page 260 TOP TETHER Plastic parts Correct seated position Use of child safety seats i-Size Rubber seals Front passenger Use of ISOFIX child seats Vehicle paint work Rear seats Wiper blades Chrome parts Correct seat position Refer to vehicle maintenance Clean interior Driver Safety belt Cigarette lighter...
  • Page 261 Fuel supply Emissions Gear changes Electrical boot lid Engine Service interval set the top position of the lid Information messages Disposal Running-in Electrical power windows Acceptance and recycling of used vehicles Buttons in the driver's door Engine compartment Distance driven Brake fluid Electric boot lid Overview...
  • Page 262 Footmats see footmats Hill Start Assist (HHC) Gear change Force limit Hitch Gear recommendation Electric boot lid Drawback load Information on the selected gear Power windows Hook Gear changing Sliding/tilting roof Horn Gear stick Front airbag General view Front Assist Cockpit Disable/enable i-Size...
  • Page 263 Interior light Lamps Main beam Front Warning light Parking lights 67, 72 Switching on and off Interior lighting Lane Assist Turn signal Ambient lighting see Lane Departure Warning Warning lights Warning light Interior monitor Load Lane Departure Warning iPad holder Activation / deactivation Locking behind the head restraint...
  • Page 264 Luggage compartment cover Mirror Roll-up cover Exterior mirrors Interior mirror Luggage compartment lid See Engine oil Make-up Luggage net Warning messages MODE button Luggage storage Oil pressure see driving mode selection Multi-function pocket Warning messages Modifications On-board computer Modifications and technical alterations see multifunction display Airbags Main beam...
  • Page 265 Parking assistance Proactive passenger protection Rear view mirror Activation / deactivation Warning light Interior mirror Display in the Infotainment display ProActive passenger protection Rear window - heater Parking brake Function Refuelling Warning light Protective films Fuel Parking brake - Auto Hold function Puncture repair kit Remote control Warning light...
  • Page 266 Reversing camera Seat belts Selector lever lock Lens care Belt tensioners Warning light fastening and unfastening Revolutions counter Service Seatbelts Service interval display Roller blind Inertia reels Warning light Luggage compartment cover Seat belts Setting Roof reversible Positions of the variable loading floor Load The physical principle of a head-on collision Seat belt height...
  • Page 267 Spare wheel Start the engine Switch Removal Lamp batteries Stowage Steering column lock locking Switching lights on and off Speed limiter Starter button Switching off the engine Operation Steering column lock unlocking Starter button Operation description Starter button Switch off TCS Warning light Steering lock locking Warning light...
  • Page 268 Towing device Turn signal system Used vehicles Accessories Warning light Acceptance and recycling Towing eye Tyre Useful equipment front Damage 230-volt socket Rear Explanation of the label Ashtray see wheels Car park ticket holder Towing protection Cigarette lighter Tyre load-bearing capacity Towing the vehicle Clothes hook see Wheels...
  • Page 269 Materials Washing Wi-Fi Direct Natural leather Automatic car wash system Connection Plastic parts by hand Password change Polishing vehicle paint work High-pressure cleaner Setting Rubber seals Washing vehicles Window operation Safety belt Button in the passenger door Waste container Seat covers Button in the rear doors Water in the fuel filter Under-body protections...
  • Page 270 WLAN see Infotainment Xenon headlight Index...
  • Page 271 Index...
  • Page 272 Index...
  • Page 273 Reprinting, duplicating, translating and any other use, either in whole or in Issued by: ŠKODA AUTO a.s. part, is not permitted without the written consent of ŠKODA AUTO a.s. © ŠKODA AUTO a.s. 2015 ŠKODA AUTO a.s. expressly reserves all rights relating to copyright laws. Subject to change.
  • Page 276 Návod k obsluze Superb anglicky 11.2015...

Table of Contents
